Technical Data
Model Navigator X2 C

Firmware upgrade

Upgrade through the Type-C USB port
Memory function
Settings will be stored 2 seconds after last operation and
recover after a restart
Wireless Flash
Transmission range (approx.) 0-100m
Built-in wireless 2.4G
Modulation mode MSK
Channel 32
Wireless ID 01-99
Group 16
Other
Display Large LCD panel, backlighting ON or OFF
Dimension/Weight 90x58x50mm/80g

Restore Factory Settings

Synchronously press the two function button in the middle, and the restore factory
settings are finished until the "RESET" is displayed on the LCD panel.
Firmware Upgrade
This flash trigger supports firmware upgrade through the Type-CUSB port. Update
information will be released on www.quadralite.eu/firmware
USB connection line is not included in this product. As the USB port is a Type-C
USB socket, please use Type-C USB connection line.
- 26 -

Troubleshooting

1. Unable to trigger flash or camera shutter. Make sure batteries are installed correctly
and Power Switch is turned on. Check if the transmitter and the receiver are set to
the same channel, if the hotshoe mount or connection cable is well connected, or if
the flash triggers are set to the correct mode.
2. Camera shoots but does not focus. Check if the focus mode of the camera or lens is
set to MF. If so, set it to AF.
3. Signal disturbance or shooting interference. Change a different channel on the
device.
4. Operating distance limited or flash missing. Check if batteries are exhausted. If so,
change them.

Maintenance

Avoid sudden drops. The device may fail to work after strong shocks, impacts, or
excess stress.
Keep dry. The product isn't water-proof. Malfunction, rust, and corrosion may occur
and go beyond repair if soaked in water or exposed to high humidity.
Avoid sudden temperature changes. Condensation happens if sudden
temperature changes such as the circumstance when taking the transceiver out of a
building with higher temperature to outside in winter. Please put the transceiver in a
handbag or plastic bag beforehand.
Keep away from strong magnetic field. The strong static or magnetic field
produced by devices such as radio transmitters leads to malfunction.
- 27 -
