Quadralite Stroboss 60evo II Instruction Manual

Foreword
Thank You for purchasing this product.
This Stroboss 60evo II KIT camera flash applies to camera compatible with i-TTL* autoflash. With this
E-TTL II compatible flash, your shooting will become simpler. You can easily achieve a correct flash
exposure even in complex light-changing environments. This camera flash features:
Approx. GN60 (ISO 100,@200mm), 81 steps from 1/1 to 1/256.
•
Fully support Canon E-TTL II camera flash. Workable as Transmitter or Receiver unit in a
•
wireless flash group.
Use dot-matrix LCD panel to make clear and convenient operations.
•
With built-in 2.4GHz wireless remote system to support transmitting and receiving.
•
Provided multiple functions, include HSS (up to 1/8000s), FEC, FEB, etc.
•
Stable consistency and color temperature with good even lighting.
•
LED modeling lamp.
•
Support with firmware upgrade.
•
Warning
Always keep this product dry. Do not use in rain or in damp conditions.
•
Do not disassemble. Should repairs become necessary, this product must be sent to an
•
authorized maintenance center.
Keep out of reach of children.
•
Stop using this product if it breaks open due to extrusion, falling or strong hit. Otherwise,
electric shock may occur if you touch the electonic parts inside it.
Do not fire the flash directly into the eyes (especially those of babies) within short
•
distances. Otherwise cisual impairment may occur.
Do not use the flash unit in the presence of flammable gases, chemicals and other
•
similar materials. In certain circumstance, these materials may be sensitive to the strong
light emitting from this flash unit and fire or electromagnetic interference may result.
Do not leave or store the flash unit if the ambient temperature reads over 50°C.
•
Otherwise the electronic parts may be damaged.
Turn off the flash unit immediately in the event of malfunction.
•
Conventions used in this Manual
This manual is based on the assumption that both the camera and camera flash's power
•
switches are powered on.
The automatic light measurement system is marked in this manual with the i-TTL, which
•
is the correct abbreviation for the Nikon brand, for other brands these are ETTL (Canon),
TTL (Sony), etc.
The following alert symbols are used in this manual:
•
The Caution symbol indicates a warning to prevent shooting problem.
The Note symbol gives supplemental information.
