Temporary Temperature Override - prowarm Pro Digital Remote User Manual

Auto / Manual
Press button M to select Auto/Manual mode. In Manual mode, the thermostat maintains a constant set temperature manually set by the user.
In Auto mode, the thermostat executes the pre-programmed schedules. To adjust these schedules, follow the easy steps below.
Mode
Program your thermostat
1. Press and hold button M for 5 seconds until "PROG" is shown with the Day
fl ashing. Use up or down button adjust the day
(hold up or down button for 5 seconds to set all days the same).
2. Press button M to bring up the program 1. Use up or down button
to set the start time (default 07:00). (Hold up or down button to
change by 15 minutes each time.)
3. Press button M again and use up or down button to set the desired temperature
to be maintained for program 1.
(default 22°C)
4. Press button M to bring up the program 2. Use up
or down button to set the start time (default 09:30). (Hold up
or down button to change by 15 minutes each time.)
5. Press button M again and use up or down button to set the desired temperature
to be maintained for program 2. (default 16°C)
Please Note: It is faster to program the same schedule for the entire week and then to adjust the exceptional days. To erase program 2 and 3 for Saturday and Sunday,see below,
In step 1, select Saturday or Sunday. In step 4, instead of using up or down button , using button
In step 6, instead of using up or down button , using button
Set the
This thermostat is fi tted with a real time clock. It
is essential that the clock time and day are set
Time and Day
accurately if you require your programmed events
to start on time. Follow the easy steps below.
Step 1. Press the button
Step 2. Use up or down button to change the time
(Hold up or down button to change by 15 minutes each time.)
Step 3. Press button
Step 4. Use up or down button to change the day of the week
Step 5. Press button
Resetting factory defaults
Your thermostat has the ability to reset all settings to the factory defaults. If you
are certain you want to do this: In standby mode
(when thermostat is turned off), press and hold button M and
seconds until "RESET" is shown for 5 seconds on LCD.
Lock the buttons
+
Press and hold the and
lock icon appearing, to unlock, repeat the steps above.
Installation & Wiring
STEP 1 1
STEP 1
STEP 1
Wiring Diagram
will erase the time.(--:--).
and the time will fl ash
again, the day of the week will fl ash
again to accept and exit
for 5
buttons for 3 seconds until you see a
Carefully separate the front half of
the thermostat from the back plate
by placing a small fl at head terminal
driver into the slots on the bottom face
of the thermostat.
Carefully unplug the ribbon
connector which is plugged in to
the front half of the thermostat
Place the thermostat front half
somewhere safe Terminate the
thermostat as shown in the diagrams
below
This product should be
installed by a qualifi ed
electrician.
6. Press button M to bring up the program 3. Use up
or down button to set the start time (default 16:30).
(Hold up or down button to change by 15 minutes each time.)
7. Press button M again and use up or down button to set the desired temperature
to be maintained for program 3.
(default 22°C)
8. Press button M to bring up the program 4. Use up or down
button to set the start time (default 22:30).
(Hold up or down button to change by 15 minutes each time.)
9. Press button M again and use up or down button to set the desired temperature
to be maintained for program 4.(default 16°C)
10. Press button M to accept and exit.
will erase the time.(--:--).
View fl oor temperature
If thermostat is set in AF model, and set to show air temperature only, press
and hold the down button for 3 seconds, fl oor temperature will show and it will
automatically revert back to air temperature in 5 seconds.

Temporary temperature override

To temporary override the current set temperature,
+
1. Press or button once, the set temperature starts fl ashing
2. Press or button again to adjust the set temperature
+
3. Wait for 5 seconds to confi rm the setting with "OVERRIDE" shown on LCD
Now your thermostat will maintain the new set temperature until the next setpoint.
To cancel the override setting, press and hold button
until "OVERRIDE" disappear.
Vacation mode
To set vacation mode press and hold the
until appears. Use same procedure to exit this mode.
Vacation mode will maintain a set temperature(default 10°C) all the time.
Press or button to change the set point and wait for
+
5 seconds to accept and exit.
STEP 1
STEP 1
Dimensions
86mm
Rear View
5 0 m m
for 5 seconds
button for 3 seconds
+
Screw the thermostat back plate on to
the back box
Re-connect the thermostat ribbon
cable and clip the two halves together
13mm
Side View
28 mm
