prowarm Pro Digital Remote User Manual

DIGITAL THERMOSTAT
LCD Symbols
Turning on/off the
thermostat
The buttons are locked
Heating is turned on
RT
RT
Room temperature
FT
FT
Floor temperature
Automatic mode,
AUTO
AUTO
executes the
programmed schedules
Decrease

General Settings

Press buttton to Turn on/off the thermostat. When thermostat is turned off, the LCD will only display current temperature reading. When the thermostat is turned off,
press and hold button M for 3 seconds to bring up a confi guration menu. In this mode, press button M to select different features' setting.
Menu # Features description
01 Model (Model Selection)
02 Sd (switching differential)
03 ATC (air temp calibrate)
04 FTC (fl oor temp calibrate)
05 Maximum fl oor temperature
06 TR-AF (AF model only)
(TR=Temperature readout)
07 MAXFT (set maximum
fl oor temp in AF model)
08 Clock format
09 TF (temperature format)
10 Clock
11 FP (Frost protection)
12 SC (setpoint confi guration)
Please Note: one of the following error messages will appear if one of these problems occur:
LO - This error means that the room or fl oor temperature is below 0°C
HI - This error means that the room or fl oor temperature is greater than 50°C
If the fl oor sensor is short-circuit or broken, the LCD will display "ERR" and the thermostat
will cut off output.
This product should be installed by a qualifi ed electrician.
prowarm
www.
O/RIDE
O/RIDE
Temporary temperature
Frost protection
activated
Comfort temperature
mode
Economy temperature
mode
Vacation temperature
mode
+ Increase
Program
Program
The program number
1,2,3,4
1,2,3,4
Features Explanation
This thermostat is a combination model allowing you to choose between
3 different models. A, AF and F model. A model: air only, with built in
sensor AF model: air & fl oor, with both built in and remote sensor F
model: fl oor only, with remote sensor
The numbers of degree difference before switching. The default is 1°C
which means the thermostat will switch the heating on 0.5°C below the
set temperature and will turn it off 0.5°C above the set temperature. With
a 2°C differential, the heating will switch on 1°C below the set temperature
and will switch off 1°C above the set temperature.
This is to calibrate air temperature if required.
This is to calibrate fl oor temperature if required.
This is to protect the fl oor surface by limit the fl oor temp. (AF model only)
This gives option to choose to show air temperature,fl oor temperature or
to show both fl oor & air in interval.
This is to protect the fl oor surface.
This is to set the backlight turning-on time. User can also set the backlight
always on or off.
This alows users to select between °C or °F.
12/24-hour clock system selection
This is to avoid room temperature goes below 5°C
This allows user to select between 2 sets of default programmed set points.
SEE OVERLEAF FOR FURTHER SETTING UP INFORMATION
.com
USER MANUAL ver 1.3
Optional Remote
Controller Buttons
Optional Remote Controller
(Remote control model only)
1. Turn on/off thermostat
2. Confi rm setting
3. Program button
4. Lock or unlock buttons
5. Menu (in OFF mode)
6. Set Day
7. Set time
8. Auto / Manual selection
9. View fl oor temp (AF model only)
10. Cancel override
11. Vacation mode
12. Decrease the set value
13. Increase the set value
Adjustment
A, AF, F
1 = 1 degree(default), 2 =2 degrees
-1 = decrease 1 degree, 1 = increase 1 degree...
-1 = decrease 1 degree, 1 = increase 1 degree...
5s, 10s, 15s, 20s (default), 25s, 30s.
A=to show air temperature, F=to show fl oor
temperature, A-F = to show both in 5 second intervals
40 degree (default)
30 seconds (default) On= always on, OFF= always off
°C or °F.
24 (default), 12- hour or 24-hour clock system
on= activated, off= deactivated
"4" means the 4 programmes will have 4 independent set
temperatures. Each set temperature can be different to the
others. program 3 ; set temperature in program 2 equals
the set temperature in program 4; If set temp in program
1 is changed, set temp in program 3temp in program 2 is
changed, set temp in program 4 will be changed will be
changed automatically to the same set temp as program 1.
If set automatically to the same set temp as program 2.
support
ENTER
ENTER
1. 2.
PROG MENU
PROG MENU
3. 4. 5.
auto
auto
DAY TIME
DAY TIME
6. 7. 8.
Run Run
FT
FT
Schedule
Schedule
9. 10. 11.
+
12. 13.
(press up or down button to adjust)
0843 770 4597
