Summary of Contents for prowarm ProTouch Wifi

  • Page 1 Smart Thermostat...
  • Page 2: Display Symbols

    Smart Thermostat DISPLAY SYMBOLS Day indicator Period indicator Frost symbol Holiday left Key lock indicator MON TUE HOLIDAY WAKE LEAVE RETURN SLEEP HOLD LEFT Hold left WiFi Clock Floor Temp FLOOR TEMP Degrees Celsius Room Temp ROOM TEMP Fahrenheit HIGH Floor limit symbol Flame symbol TEMP...
  • Page 3: Main Functions

    THERMOSTAT DESCRIPTION The new ProTouch WiFi is a smart thermostat used to control your electric floor heating system or water heating system. It will keep your home at comfortable temperature whilst minimizing energy use. Install the app on your smart phone to control your heating system remotely with the WiFi thermostat.
  • Page 4: Installation And Wiring Instructions

    INSTALLATION AND WIRING INSTRUCTIONS Loosen fixing screw Connect the located in the bottom of thermostat the thermostat to get the according to the front panel. Wiring Instruction. Insert the back Align top part of front panel into wall box panel and back panel to with provided fit these two parts.
  • Page 5 WIFI CONNECTION Step 1 Scan the QR code through mobile browser or download the App from APP Store or Google Play Step 2 Step 3 Step 4 Log in or sign up the Click “Add Home”, Click “+” on the top-right corner of APP through Phone No.
  • Page 6: Wiring Instructions

    WIRING INSTRUCTIONS POWER FLOOR SENEOR SENSOR POWER 85V-265V FLOOR 50/60Hz SENSOR MAX LOAD: IP 21 Suggestion: Please keep the max load around 90% of 16A to prolong the lifetime. Ensure power is disconnected when wiring!
  • Page 7 ‘ProTouch WiFi’ app available from..Step 5 Step 6 Step 7 Step 8 Set the thermostat Log in WiFi password When connection is You can check the based on APP’s and click the button to done, Click “Done” actual temp, change instruction.
  • Page 8: Function & User Operation

    FUNCTION & USER OPERATION Press to turn on/off Note: When frost protection mode is active, the thermostat will maintain the frost protection temperature when in power ‘off’ mode. Set the Time Temporarily override temperature In normal timed power ‘on’ mode, Press In normal timed power ‘on’...
  • Page 9 Hold mode Holiday mode The thermostat will maintain frost protection The thermostat will maintain the ‘hold temperature’ temperature until the holiday days ends. until the hold time ends. In normal timed power ‘on’ mode, press O to In normal timed power ‘on’ mode, press O to enter enter setting.
  • Page 10 Timer setting Each day of the week has 4 time periods,you should allot a temperature to each time period. Set the temperature above room ambient temperature and the heating will come on until the desired temperature is reached, or, set the temperature low and the heating will not come on during that time period. The default settings are shown in the table below.
  • Page 11: Dimensions (Mm)

    DIMENSIONS (mm)
  • Page 12 Name Default value Ranges 0°C Room temperature calibration - 5°C -- 5°C Floor temperature calibration 0°C - 5°C -- 5°C Frost protection mode OFF/ON Frost protection temperature 5°C 5°C -- 15°C 00: Built-in sensor Sensor selection 01: Floor sensor 01: Floor sensor 02: Both sensors Floor temperature limit(both sensors) 30°C...
  • Page 13: Advanced Setting

    ADVANCED SETTING 1. Room temp calibration: Calibrate the temp detected by room sensor. 2. Floor temp calibration: Calibrate the temp detected by floor sensor. 3-4. Frost Protection Mode: Frost protection allows the thermostat to turn on if the temperature drops below 5 degrees even when it is not programmed to.
  • Page 14: Troubleshooting

    ADVANCED SETTING (Please refer to table above) Caution: These are normally set by technicians during initial installation. In normal timed power ‘on’ mode, press O to enter setting. Press △ or ▽ to select SETUP . Press O to enter advanced setting. Each parameter can be accessed by pressing O and adjust the values as required using the arrow keys.
  • Page 15 Smart Thermostat ‘ProTouch WiFi’ app available from Support: www.prowarm.com 01268 567019...
