FEATURES :
Measurement of Current, Voltage, Active, Reactive and Apparent Power, Power factor,
Line Frequency, Active & Reactive Energy, Harmonic, & Maximum Demand.
( 54 parameters ).
High - brightness LED display
High accuracy up to 0.25 %
Programmable adjustment for current and voltage transformers ratio
With RS 485 or RS 232 output
SPECIFICATION :
Local Display
Total
L- L Voltage
L- N Voltage
Line current
Neutral current
Active power
Reactive power
Apparent power
Power factor
Frequency
Active energy +
Reactive energy +
Active energy -
Reactive energy -
Total Harmonic - I(1)
Total Harmonic - V(1)
(1) up to 31 st harmonic
* Average Value
®
MULTIFUNCTIONAL DIGITAL TRMS POWER METER
C
E
M
k
C
E
M
k
v
C
E
M
k
v A r w h z
Phase1
Phase2
Phase3 Accuracy
**Full scale of ranges
%
v
A r
w
h
%
A
r
w
h
Enter
%
Set
Neutral current can be indicated
Dual relay contacts for energy or alarm output
Setting protected by password
Memory of all setting value and energy data over ten years.
Outside dimension compatible for DIN standard 144 x 144 mm
Optional Harmonic Display
Optional Dual current loop output.
Accuracy Performance Range
Current range..................................................................2 ~ 120 %
Voltage range .....................................................................2 ~ 120 %
0.25%
Power range............................Current, 2 ~ 120 %, Voltage, 2~120 %
Power factor range.............................................Cos (sin )0.5 ~ 1
0.25%
Frequency range............................................................45 ~ 70 Hz
Distortion level from...................................................10 % to 120 %
0.25%
1%
Input Voltage
Voltage range (line to line).................................................8 ~ 500 V
0.5%
Voltage range (line to neutral).............................................5 ~ 290 V
Maximum overload...............................................................750 V
0.5%
Input impedance............................................................ 200.K.
0.5%
Input Current.
Current range....................................................................5 A or 1 A
0.5%
Maximum overload...................................6 A, continuous, 50 A 5 sec.
0.05%
Input burden....................................................................... 1VA
Isolation............................................................Each phase, 600 V
0.5%
Starting current.................................................................1 %, F.S.
0.5%
Power Supply
Nominal voltage ..........................AC 110 V / 220 V ± 15 %, 50 / 60 Hz
0.5%
Burden.......................................................(AC) 5 VA, (DC) 5 W
0.5%
Display
2%
Type.........................................................High-brightness RED LED
Digital height................... .....................................0.56", 14.2 mm
2%
Digital format....................................................... 3 rows of 4 digits
Digits for Wh, Varh, Vah........................................8 digits (two rows )
All Specifications are subject to change without prior notice
Model KM - 6300
. 15 A, continuous, 250 A 1 sec. (Option)
or DC 110 V, 24 V ± 10 %

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM-6300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kusam-meco KM-6300

  • Page 1 ® MULTIFUNCTIONAL DIGITAL TRMS POWER METER An ISO 9001:2008 Company Model KM - 6300 Accuracy Class 0.25% Enter v A r w h z FEATURES : Neutral current can be indicated Measurement of Current, Voltage, Active, Reactive and Apparent Power, Power factor, Line Frequency, Active &...
