Nexcom NANO 1190 User Manual

Mobile computing solutions
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NEXCOM International Co., Ltd.
Mobile Computing Solutions
MVS 5200/5210/5210-R & NANO 1190
NVR User Manual
NEXCOM International Co., Ltd.
www.nexcom.com
Published December 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO 1190 and is the answer not in the manual?

Questions and answers

Related Manuals for Nexcom NANO 1190

Summary of Contents for Nexcom NANO 1190

  • Page 1 NEXCOM International Co., Ltd. Mobile Computing Solutions MVS 5200/5210/5210-R & NANO 1190 NVR User Manual NEXCOM International Co., Ltd. www.nexcom.com Published December 2016...

  • Page 2: Table Of Contents

    8.2 Modify Existing Event Schedule or Action: ......39 8.3 Delete Existing Event Schedule or Action: ......39 8.4 Action Types: ................40 9. Log Viewer: ................42 Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 3 4.5.1 Convert file dialog: ............67 4.5.2 Select a day to convert history file(s): ......67 4.5.3 Assign time slice to convert job: ........68 Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 4 5.2 Schedule Setting: ..............85 5.3 Network Setting: ..............87 5.4 System Setting: ..............89 5.5 User Setting: ................91 5.6 Motion Config: ..............93 Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 5 7.3 Delete Existing Event Schedule or Action: ......100 7.4 Action Types: ..............100 Chapter 4: Utility ..........103 1. Event File Viewer ..............103 Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 6: Preface: Quick Installation Guide

    System Configuration: 1. Power on the MVS 52 series/NANO 1190 and wait until the system boots. 2. Login to the NVR system, default username is “admin” without password. 3. Click to enter system setting pages. 4. Click “Auto Setting” button at Camera’s setting page, the system will automatically insert camera from the intranet or camera connected to the NVR’s switch.
  • Page 7 6. Configure each camera’s recording schedule at “Recording” page. 7. Click the “OK” button to save settings and start recording jobs. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 8: Playback

    5. Click the “OK” button to prepare playback data and return to the playback main page. 6. Click to start playback. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 9: Chapter 1: Main Console

    PTZ controls. System information Function buttons Display preview Divide buttons Login/ Logout buttons Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 10: System Information

    Switch to Division 4 Switch to Division 9 Switch to full screen. Right click the mouse button to cancel full screen mode. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 11: Sub-Screen

    5. Audio Volume Control: Click to switch between mute or unmute. Status Description System is on unmute mode. System is on mute mode. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 12: System Setting

    Click setup button and select “System Setting” from the pop-up menu to enter the System Setting dialog. 6.1 Camera Page at System Setup Dialog: Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 13: Auto Setting

    IP or subnet mask parameters, you only need to click “Auto Setting“ button to add IP cameras. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 14: Template Setting

    “Max”, camera will use the maximum resolution, or you could select another resolution, in which the system will choose the next closest supported resolution of the camera. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 15: Camera List

    If the camera is disabled, NVR will not connect to it. This will keep the camera settings stored in the system without using any system performance and won’t add any error messages. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 16: Camera Setting

    Select camera’s vendor or use ONVIF protocol. Detect: Check available cameras and respective model names. Camera Name: Key in camera name here. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 17: Http Port

    Select connect to camera with WSSE authentication or without authentication. User Name: Set the Username for camera login. Password: Set the Password for camera login. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 18 3. Preview live stream video at the preview window to confirm current camera. 4. Click “Add” to add selected camera into system. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 19: Search Camera

    “Search List”, you can click on each row to preview live video stream. You can click on the header column to sort the current row data. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 20: Recording Page At System Setup Dialog

    3. Configure time period: Add new period: Drag the mouse cursor on a blank area, or click the “Insert” button. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 21 Select a period from then weekday bar or list, then click the “Copy” button, system will copy the selected weekday’s periods to all weekdays. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 22: Network Page At System Setup Dialog

    IP address in the text box. PPPOE Setting: Enable / Disable: Check or uncheck the checkbox to enable or disable PPPoE function. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 23 Set RTSP service port here. RTSP over HTTP: Enable RTSP over HTTP function, the remote live stream will use HTTP protocol and HTTP port. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 24: System Page At System Setup Dialog

    Key in device title here. Software version: Display current firmware version. Date Time: Server Date & Time: Display current system date-time. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 25: Manual Setting

    Daylight saving Offset: Configure daylight saving offset time with current time, it works with daylight saving mode enabled. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 26 Display device DIPS ID. Click the “Test” button to test connection with DIPS server. Recycle Days: Select log keep days. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 27: User Page At System Setup Dialog

    Select user’s login group. Description: Key in description of this user. Monitor: Select which camera live streams that the current user can preview. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 28 “Modify” button to make the changes take effect. Delete User: Select a user first then click the “Delete” button to remove the selected user from the system. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 29: Motion Detection Page At System Setup Dialog

    Click on the motion window or window’s name to select the window, then click the “Delete” button to remove it. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 30 Sensitivity: Set motion detection sensitivity value between 0 and 100, bigger value means motion alarm will be easier to trigger. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 31: System Management

    Click the setup button and select “System Management” from the pop-up menu to enter the System Management dialog. 7.1 System Management: Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 32 Style: Select Main page display style, the style will change after clicking the “OK” button. Normal Style: User-friendly GUI interface. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 33 Display and control local and camera’s DO status, if the camera does not have DO, it will not be added to the DO list. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 34: Ptz Control Buttons

    Click PTZ direction buttons to control camera pan, tilt and home positions. Group Preview: Switch current live division to a specific group division. E-Map: Display camera’s position. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 35: Auto Switch

    Button Description Switch division buttons Reset division to default Full Screen Auto Switch Snapshot Change display ratio Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 36: Start Time

    Key: Display event Key string. System Log: Time: Log Time. Log Type: Log type string. Remark: Extra log description. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 37: Default Setting

    “Firmware Upgrade” to begin firmware update. System Restart: Restart the NVR system. Audio: Adjust audio input or output gain value. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 38: Disk Management

    Display all the partitions of selected device and their information. Click the “Format” button to format selected partition to “ext4” format, all data will be lost. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 39: Snapshot

    3. Select a snapshot file name, the snapshot image will be displayed on the right. Delete: Click the “Delete” button to delete selected snapshot file. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 40: Event Snapshot

    Event Type: Triggered Event Type. Input: Event DI port number, if it is not a DI event -1 will be displayed. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 41: Snapshot Viewer

    Backup button: Click the “Backup” button to backup this event video to a removable device. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 42: Event Setting

    3. Select an Event from the table. Motion Alarm: Camera’s motion detection, you must set the camera motion first. Disconnect Alarm: The camera connected is disconnected. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 43: Audio Detection

    B. Select Post-Alarm seconds. C. Merge seconds is set for merging two same alarms between setting seconds. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 44: Modify Existing Event Schedule Or Action

    8.3 Delete Existing Event Schedule or Action: Delete Event: 1. Select an Event from “Event List”. 2. Click the “Delete” button below the “Event List”. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 45: Action Types

    You can search them in the “Event Snapshot” page in “System Management”. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 46 System will upload the file to FTP server when event is triggered. Navigation: Go to camera’s preset position. Popup: Switch live division to a specific group division. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 47: Log Viewer

    Setup the maximum number of records of search result. Click the “Search” button to start search, the search result will be displayed in the table below it. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 48: Event Log

    Select an event log from the log table, event image will be displayed in the window, you can click the play control buttons to preview event images. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 49: Bit-Rate Log

    Click on the days in the calendar with blue background. Bit-rate table: The system will display the bit-rate log in the table. Blue: Bit-rate is very low. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 50: Schedule Monitor

    Move the thumb to left to make volume lower, or right to make volume higher. 10.3 PTZ Control: Pan/Tilt Move the PTZ camera direction by clicking the direction buttons. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 51 IRIS: Adjust camera’s IRIS setting, or set it to auto. Focus: Adjust camera’s focus setting, or set it to auto. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 52: E-Map

    Double click on the camera icon, live preview division will switch to selected camera. E-Map Setting: Click “Setup” button on upper left corner to launch the E-Map setting dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 53 Rotate Camera: Click the right mouse button on the camera icon. Switch Live Preview: Double click on the camera icon. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 54: Chapter 2: Playback

    When you enter the playback page, the system will automatically playback recent video history. You can drag the time bar to change current playback time. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 55: Search History Record Data

    4. Begin playback: Confirm the playback camera and period then click the “OK” button to begin playback. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 56: Simple Search

    Select playback period from date controls directly, and select which cameras will be played back. Click the “OK” button when you finish setting the search rules. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 57: Playback Control Button(S)

    Stop playing video. Play video backward. Seek to previous frame when on pause mode. Seek to next frame when on pause mode. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 58: Button Description

    The mini control pad can move to any position that you need in the screen. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 59: Convert To Avi File

    2. Select backup cameras and time periods as playback search steps. 3. Select destination folder for backup. 4. Wait till the convert finishes or abort by clicking the cancel button. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 60: Playback Status

    Right click on the playback channel, and select “Sequential Search” from the pop-up menu, the system will enter the Sequential search dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 61 Search images within the selected period. Seek To: Seek all channels to the selected image’s time. Cancel: Cancel Sequential search. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 62: Chapter 3: Remote Service

    Once you have connected to the remote service, IE will pop up a login window. Please key in valid username account and password. Each user account’s privilege is defined at MVS 52/NANO 1190. Please make sure to login with the correct account.

  • Page 63: Live Preview

    Show Live Camera: Select the display of live preview camera on this window. Remove Camera display: Remove display at this window. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 64: Digital Zoom

    Enter the snapshot dialog to adjust and save images. Full Screen: Switch display mode between normal and full screen. Restore division default: Reset division mode to default. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 65: Playback

    Click the Exit button to return to live preview page. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 66: Search History Recorded File(S)

    Click the Search button on the Playback page. 4.1.1 Search history file(s) dialog: Select the time period and camera(s) within the search dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 67: Select A Day To Search History File(S)

    You can define display color for each record mode and event through the color select dialog. Click button to enter the color select dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 68: Start Search

    2. Choose a time period by setting the begin time and end time manually. The selected time period will be displayed as blue section on the list control. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 69: Select The Camera(S) To Playback

    Click the “OK” button to finish the search procedure and start playback, or click the “Cancel” button to abort and return to the Playback main page. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 70: Playback Control Button(S)

    8X: 8X normal speed. 16X: 16X normal speed. 32X: 32X normal speed. 1/2X: Half of normal speed. 1/4X: Quarter of normal speed. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 71: Division Control Buttons

    Divide to 16 Screen(s) Full screen mode. 4.5 Convert to AVI file: Click the Convert file button to enter the Convert file dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 72: Convert File Dialog

    Click on the date to choose a day to convert file(s). Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 73: Assign Time Slice To Convert Job

    DD: Execute convert day. HH: Execute convert hour. mm: Execute convert minute. ss: Execute convert second. nnn: Execute convert million-second. CH00220090914140253150.avi Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 74: Backup

    PC. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 75: Select A Day To Backup

    • Do not modify the filename or placement in the backup files folder, if the files are modified, the playback application will fail to playback. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 76: Switch Audio Play Mode

    Display Time: Displays the time of the recorded file on the image. Display camera name: Displays the camera name on the image. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 77: Snapshot Dialog

    The dialog displays all snapshot images with the camera ID, resolution, and camera name. Tick the checkbox if you want to save this image. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 78: Select Snapshot Folder

    The image’s minute of time. ss: The image’s second of time. nnn: The image’s million-second of time. Cam000_AM3220 192.168.0.143_20090908111559901.jpg Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 79: Playback Status

    2. To switch current sub-window to another camera, click the right mouse button on the sub-screen, and then choose the preferred playback camera. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 80: Digital Zoom At Sub-Screen

    2. Configure the image in the Snapshot dialog. 3. Click the “Save” button and choose the folder which you want to save the snapshot. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 81 Click Print to print out image to printer. Save: Click Save and then choose the folder and filename to save the snapshot. Exit: Close Snapshot dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 82: Motion Search

    Check the “Show Search Image” option to display the searching video sequence or uncheck this box to show only the image once the event has been found. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 83: Sequential Search

    Click the right mouse button on the channel which you want to do sequential search, and then select the “Sequential Search” option from the pop-up menu. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 84: Define Search Time Period

    We can define time period in two ways and the selected time period will be displayed on the upper left corner. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 85: Start Search And Rollback

    After defining search time period, click the “Search” button to display the next search result. Click the “Pre search” button to rollback to previous search result. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 86: Detail Window For Snapshots

    In cases where the search result can not be displayed within one page, then these buttons will be enabled. Click these buttons to switch the pages of snapshot. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 87: Remote System Setting

    List all the cameras that was added, select a camera from the list to modify the camera’s information. Camera Config: Vendor: Select camera’s Vendor ID. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 88 Config Detail Button: Connect to camera’s web page for detailed configuration. Camera Parameter Button: Enter the camera’s parameter setting page. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 89: Video Setting

    Define the RTSP streaming port of the camera. Audio Setting: Enable Audio: Enable audio streaming from the camera. Enable Audio Record: Enable recording of audio data. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 90: Schedule Setting

    3. Or enter the start time and end time then click Add. Edit a exist schedule: Double click on a schedule window, or click on a schedule window then click Edit. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 91 If you select “Motion Detection” or “Alarm Record”, you can define the Pre-Alarm and Post-Alarm record seconds when alarm is triggered. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 92: Network Setting

    IP address in the text box. PPPOE Setting: Enable / Disable: Check or uncheck the checkbox to enable or disable PPPoE function. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 93 Set RTSP service port here. RTSP over HTTP: Enable RTSP over HTTP function, the remote live stream will use HTTP protocol and HTTP port. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 94: System Setting

    “OK” to change system time or click “Cancel” button to abort configuration. Synchronize with NTP: Enable date-time synchronization with NTP service. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 95 Enable auto login mode to login with the defined user name and password when system boots up. User: Key in auto login username. Password: Key in auto login password. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 96: User Setting

    5.5 User Setting: User: Edit username here. Password / Confirm Password: Edit user login password here. Group: Select user’s login group. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 97 “Modify” button to make the changes take effect. Delete User: Select a user first then click the “Delete” button to remove the selected user from the system. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 98: Motion Config

    3. Move the motion window to the place where you need to detect. 4. Modify the motion window name. 5. Select detect area as “include” or “exclude” motion window. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 99 2. Select a motion window from the motion window list. 3. Click the “Delete” button to remove the selected motion window. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 100: Remote System Management

    Select the NVR’s resolution from the combo list. Maintenance: Backup Setting: Export backup setting file to a removable storage device. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 101 Select a firmware file from a removable storage device, then click “Firmware Upgrade” to begin firmware update. System Restart: Restart the NVR system. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 102: Remote Event Setting

    Manage all events from the “Event Setting” page, including add, modify, remove events, event’s schedule and the actions to take when event is triggered. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 103: Add A New Event

    4. Click the “Add” button below Event Schedule List table. 5. Select the weekdays and time period to monitor for the event. 6. Set Alarm detailed parameters. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 104: Modify Existing Event Schedule Or Action

    4. Click the “Modify” button. 5. Modify setting values from each Action setting dialog. 6. Click the “OK” button to close dialog. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 105: Delete Existing Event Schedule Or Action

    “True”, DO will change to “Close” status when alarmed. When output is set to “False”, DO will change to “Open” status when alarmed. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 106 You can search them in the “Event Snapshot” page in “System Management”. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
  • Page 107 3. Setup Pre-Alarm seconds and Post-Alarm seconds for record file. System will upload the file to FTP server when event is triggered. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 108: Chapter 4: Utility

    Each event file includes event’s information and images group, you can use the viewer to preview, convert to AVI or snapshot a single JPEG file. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 109: Playback Control

    Seek to next frame when on pause mode. You can move the slider bar thumb to change the current playback time. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...

  • Page 110: Event Information

    NVR’s DIPS ID. Function buttons: Button Description Convert the event file to AVI format. Snapshot current image to JPEG file. Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved. MVS 5200/5210/MVS 5210-R Series & NANO 1190 NVR User Manual...
