MAINTENANCE

This product does not contain any parts that can be repaired
by the consumer. Contact an authorised service centre or a
similarly qualified person to have it checked and repaired.
Replacing the spool
NOTE: Before replace the spool, make sure the mains plug is
disconnected from the unit.
i. Press together both locking device tabs on the spool cover
and remove the cover.
ii. Remove the old spool from the spool cover
iii. Clean out any dirt or grass residue.
iv. Put the new spool in the spool housing, thread the line into
the hole.
Winding the line
NOTE: Should you wish to wind the line yourself, the instructions are
provided below:
Self-winding, however, is NOT recommended because if the line is not
wound properly it can cause the trimmer's feed system to malfunction.
For this reason, users are strongly urged to purchase the pre-wound
spool.
