ANFIM AE 65 V Instruction Manual

Single espresso grinder solida
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
Original instruc on manual
Single Espresso Grinder Solida
AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC | AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC
*example Fig.
Standard variant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AE 65 V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ANFIM AE 65 V

Summary of Contents for ANFIM AE 65 V

  • Page 1 Single Espresso Grinder Solida AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC | AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC *example Fig.

  • Page 2: Overview

    SINGLE ESPRESSO GRINDER Overview AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC...
  • Page 3 Solida | EN AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC...
  • Page 4 SINGLE ESPRESSO GRINDER AE 65 V SC | AE 65 V Stp SC AE 65 VT SC | AE 65 VT Stp SC...
  • Page 5 Solida | EN AE 65 V Stp | AE 65 V Stp SC AE 65 VT Stp | AE 65 VT Stp SC...
  • Page 6 SINGLE ESPRESSO GRINDER...
  • Page 7 Solida | EN...
  • Page 8 SINGLE ESPRESSO GRINDER AE 65 V | AE 65 V Stp | AE 65 V SC | AE 65 V Stp SC AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC...
  • Page 9 Solida | EN AE 65 VT | AE 65 VT Stp | AE 65 VT SC | AE 65 VT Stp SC...

  • Page 10: Scope Of Delivery

    SINGLE ESPRESSO GRINDER Scope of delivery No. Name Bean container (incl. lid) Bean container intake Dispensing chamber (with lid) Grinding degree lock On/Off switch Release bu on (thermal overcurrent circuit-breaker) Power cable (with power plug) Start button Dispensing lever Drip tray Portafi...

  • Page 11: Table Of Contents

    Solida | EN Solida Contents Overview ......2 Cleaning ......24 Cleaning the surface on which Scope of delivery ....10 the grinder stands ....... 25 General informa on ..12 Cleaning the casing ..... 25 Reading and storing the Cleaning the dispensing instruc on manual ......

  • Page 12: General Informa On

    SINGLE ESPRESSO GRINDER General informa on Reading and storing the instruc on manual Before you start using the Solida Espresso Grinder, carefully read through this original instruc on manual and the safety informa- on. Only then will you be able to use the Single Espresso Grinder safely and without danger.
  • Page 13 Solida | EN This symbol provides you with useful informa on about opera- on or handling. Declara on of Conformity (see “Declara on of Conformity” sec on): Products marked with this symbol fulfi ll all applicable community provisions of the European Economic Area. ETL Listed seal of approval: Products marked with this symbol meet the requirements for electrical product safety in the United States of America.

  • Page 14: Safety

    SINGLE ESPRESSO GRINDER Safety Intended use The grinder is suitable only for grinding whole roasted espresso beans. Do not use the grinder to grind other products or objects. It is intended for com- mercial use and may only be serviced by trained personnel. It may, however, be operated by other persons in a place where its use is supervised.
  • Page 15 Solida | EN – Do not operate the grinder above an al tude of 2,000 meters. – Do not immerse the grinder, the power cable or the power plug in water or any other liquids. – Do not clean the grinder with a water jet. –...
  • Page 16 SINGLE ESPRESSO GRINDER WARNING! Danger for children and persons with reduced physical, sensory or mental capaci es (e.g. par ally disabled persons, elderly persons with limited physical and mental capaci es) or a lack of experience and knowledge (e.g. older children). –...

  • Page 17: Before Using For The Fi Rst Me

    Solida | EN Before using for the fi rst me Func oning and grinder variants The Solida grinder is available in various designs. The following applies to all grinder variants: The espresso beans in the bean container (1) fall into the grinding mecha- nism as soon as the sliding valve (20) has been opened (see Fig.

  • Page 18: Checking The Grinder And Scope Of Delivery

    SINGLE ESPRESSO GRINDER Checking the grinder and scope of delivery NOTE! Risk of damage! The grinder can be damaged if the packaging is opened carelessly with a sharp knife or other pointed object. – Be very careful when opening. 1. Remove the grinder from its packaging. 2.

  • Page 19: Opera On

    Solida | EN If the bean container cannot be fi xed in place by rota ng it, it may not be posi oned correctly. Align the bean container correctly (see step 5) and try again to fi x it in place by rota ng it (see also “Troubleshoo ng” sec on).

  • Page 20: Adding Espresso Beans

    SINGLE ESPRESSO GRINDER NOTE! Risk of damage! The operator cannot adjust the thermal overcurrent circuit-breaker. If the circuit-breaker has been triggered several mes, a service partner must be contacted for advice as the motor winding may be damaged. Adding espresso beans 1.

  • Page 21: Se Ng The Grinding Degree

    Solida | EN Se ng the grinding degree • The lock for the grinding degree adjuster locks the grinding degree slider to prevent accidental adjustment of the grind- ing degree. • When the grinding degree lock is open, the grinding degree slide can be moved con nuously along the grinding degree scale.

  • Page 22: Removing The Grounds

    SINGLE ESPRESSO GRINDER Removing the grounds 1. Slide the portafi lter into the portafi lter support (11) un l it reaches the stop. 2. Pull the dispensing lever (9) as far forward as possible to dispense the coff ee grounds into the portafi lter (see Fig. J/K). 3.

  • Page 23: Changing The Type Of Espresso Beans

    Solida | EN Changing the type of espresso beans 1. Close the bean container (1) by pushing in the sliding valve (20). 2. Grind the espresso beans that remain in the grinding mechanism un l the grinder runs idle. 3. Actuate the dispensing lever (9) to remove the remaining grounds from the dispensing chamber (3).

  • Page 24: Cleaning

    SINGLE ESPRESSO GRINDER Cleaning CAUTION! Risk of injury! The grinder can fall over and cause injury when moved. – Place the grinder on a stable surface that will not lt. – Ask another person for help if the grinder is too heavy. NOTE! Risk of short-circuit! Water penetra ng the grinder can cause a short-circuit.

  • Page 25: Cleaning The Surface On Which The Grinder Stands

    Solida | EN Cleaning the surface on which the grinder stands 1. Switch off the grinder (start bu on (8) and On/Off switch (5) to posi on 0) and remove the power plug from the socket. 2. Li the grinder by the casing with both hands and place on a clean sur- face.

  • Page 26: Cleaning The Dispensing Chamber

    SINGLE ESPRESSO GRINDER Cleaning the dispensing chamber CAUTION! Risk of injury! If you accidentally actuate the dispensing lever when cleaning the dispensing chamber, your fi ngers can become trapped. – Be very careful when cleaning the dispensing chamber. – Use a tool (brush) to clean the dispensing chamber and the dispensing insert.

  • Page 27: Cleaning The Grinding Mechanism

    Solida | EN 4. Rotate the bean container counterclockwise to loosen it from the grinder, and remove it from the grinder by li ing upwards. 5. Temporarily transfer the espresso beans into another container if neces- sary. 6. Clean the bean container inside and outside with a damp cloth and then dry it.
  • Page 28 SINGLE ESPRESSO GRINDER 4. Pour the grinder cleaner into the bean container. Adhere to the quan - es indicated by the manufacturer of the grinder cleaner you are using. 5. Place a bowl underneath the dispensing chamber (3) to collect the grinder cleaner.

  • Page 29: Troubleshoo Ng

    Solida | EN Troubleshoo ng Problem Cause Remedy  Insert the bean container (see “Se ng The grinder • The bean is not container is up the grinder and inser ng the bean grinding or not inserted. container” sec on). buzzing.
  • Page 30 SINGLE ESPRESSO GRINDER Problem Cause Remedy  Release the lock on the grinding The grinder • The outlet is is humming clogged. degree adjuster and set the grinding but not degree to “8”. grinding. Start the grinding process. The grinder will clear itself. Then adjust the grinding degree se ng to the grinding degree required during opera on.
  • Page 31 Solida | EN Problem Cause Remedy  Contact your supplier The grinder • The grinding is not discs are (see “Maintenance and service” sec on). grinding worn out or fi nely need to be enough. readjusted.  Contact your supplier The grinder •...

  • Page 32: Technical Data

    Model: Solida Model variants: AE 65 V; AE 65 V Stp; AE 65 V SC; AE 65 V Stp SC; AE 65 VT; AE 65 VT Stp; AE 65 VT SC; AE 65 VT Stp SC Voltage / frequency: 100 V; 50 Hz 100 V;...
  • Page 33 Solida | EN Sound emission values (during grinding): 80 dBA Grinding capacity (fi ne–coarse): 4–10 g/s* Max. permi ed opera ng cycle: Grinder variants with “Automa c Filling” func on: 220-240 V; 50 Hz: 10 s ON/40 s OFF 220-240 V; 60 Hz: 10 s ON/40 s OFF 100 V;...

  • Page 34: Disposal

    SINGLE ESPRESSO GRINDER Disposal Disposing of the packaging Dispose of the packaging by correctly sor ng the recyclable mate- rials. Dispose of cardboard as waste paper and fi lm as recyclable materials. Disposing of the grinder Used appliances may not be thrown into commercial/domes c waste! If you can no longer use your grinder, you are legally obliged as a consumer to dispose of used appliances separately from commer-...
  • Page 36 info@hemrogroup.com HEMRO INTERNATIONAL AG +41 44 864 18 00 Länggenstrasse 34 CH 8184 Bachenbülach, Switzerland...

This manual is also suitable for:

Ae 65 v stpAe 65 v stp scAe 65 vtAe 65 vt stpAe 65 vt stp sc
