WebGUI Control Page
All functions of this unit are controllable via the built in WebGUI which
is accessed by connecting your web browser to LAN 2's IP address or by
connecting an HDMI display to the unit's HDMI output and attaching a
USB mouse and keyboard to the unit's USB port. This control is presented
across a number of separate tabs, including Monitor & Control, Preset
Recall, System, Setting, Transmitter, and Receiver. A setup wizard is also
provided to help simplify first-time setup. The individual functions will be
introduced in the following sections.
When no user is logged in, a limited selection of tabs are available (Monitor
& Control, Preset Recall, and System). This allows for easy user access to
routing selection and presets while still protecting the more sensitive
and critical setup and configuration controls. To log in to the WebGUI,
switch to the System tab and click on the "Login" button. By default,
both the Username and Password are set to "admin" for the WebGUI. The
administrator password can be changed within the System tab of the
WebGUI if desired.
i
If you are unsure of the unit's current LAN 2 IP address, please check the
unit's HDMI status display.
19
