CYP DS-MSC Operation Manual

Digital signage multi-screen video wall controller

Advertisement

Quick Links

DS-MSC
Digital Signage Multi-Screen
Video Wall Controller
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-MSC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CYP DS-MSC

  • Page 1 DS-MSC Digital Signage Multi-Screen Video Wall Controller OPERATION MANUAL...
  • Page 2 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment:  Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
  • Page 3: Table Of Contents

    Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… OSD Menu .…………………………………..……..…...….… Remote Control .......…..……………..…..…..…... RS-232 Protocol ................Pin Definition ................Command ................
  • Page 4: Introduction

    1. Introduction To capture the public ’ s attention, the Multi-Screen Video Wall control system is ideal for advertising, entertaining and displaying information. The device allows users to display HDMI or PC sources to multiple LCD monitors, while thanks to the built-in RS-232 you are able to fully customize the LCD panels giving you complete control over 2x2, 3x3, 4x4 and 5x5 video walls.
  • Page 5: Features

    5. Features Supports 6 or more video wall combinations of HxV: 2x2(four monitors),  3x2(sis monitors), 3x3(nine monitors), 4x3(12 monitors),4x4(16 monitors) and 5x5 (25 monitors) Supports both HDMI and PC (with audio) input sources  Resolution support up to 1080p full HD ...
  • Page 6: Specifications

    6. Specifications Input Ports 1xHDMI, 1xPC, 1xRS-232 (female jack), 1xIR, 1xL/R (3.5Ø phone jack) Output Ports 1xHDMI, 1xRS-232 (male jack), 1xL/R (RCA jack) IR Frequency 38Hz IR Cable Length Input Resolution Supports PC: VGA ~ SXGA HDMI: 48op~1080p Output Resolution HDMI: 720p &...
  • Page 7: Operation Controls And Functions

    7. Operation Controls and Functions 7.1 Front Panel HDMI IN AUDIO IN PC IN RS 232 IN RS 232 OUT IR IN DS-MSC Video Wall Controller ① ② ③ ④ ⑤ ⑥ ① HDMI IN: This slot is to connect from HDMI splitter or matrix with input source signal.
  • Page 8: Osd Menu

    7.3 OSD Menu STANDARD ON/OFF R OFFSET 0~255 (118) G OFFSET 0~255 (116) B OFFSET 0~255 (118) PICTURE R GAIN 0~255 (098) MENU*1 G GAIN 0~255 (098) B GAIN 0~255 (098) CONTRAST 0~63 (50) BRIGHTNESS 0~63 (40) MAIN MENU LANGUAGE ENG / T.CHINESE (ENG) HDMI SOUND ON/OFF (ON)
  • Page 9: Remote Control

    Setup H/V Position Start: These functions are to set the total value of the vertical and horizontal value of the TV wall. Setup H/V Zoom Size: These functions are to set the total value of the vertical and horizontal zoom in and zoom out size of the TV wall. Setup H/V Blanking Edit: These functions are to set the total value of the vertical and horizontal value of the blanking area of the TV wall.
  • Page 10: Rs-232 Protocol

    9. RS-232 Protocol 9.1 Pin Definition RS-232 IN RS-232 OUT Pin 1 Pin 1 Pin 2 Pin 2 Pin 3 Pin 3 Pin 4 Pin 4 Pin 5 Pin 5 Pin 6 Pin 6 Pin 7 Connect to Pin 8 Pin 7 Connect to Pin 8 Pin 8...
  • Page 11: Connection And Installation

    ① ② ④ ③ ④ ③ ① ② ③ ④ DS-MSC DS-MSC DS-MSC DS-MSC IR Cable CHDMI-4 (HDMI Splitter) Blu-ray Laptop NOTE: Display sequence is from top left to right and from second right to left and so on sequence.
  • Page 12: Acronyms

    Acronyms Acronym Complete Term HDMI High-Definition Multimedia Interface...
  • Page 15 www.cypeurope.com...
