Omron JPN600 Instruction Manual

• When handling the power cord, observe the following:
Do not damage.
Do not tamper with it.
Do not twist.
Do not pinch.
• Wipe the dust off from the power plug.
• Disconnect the power plug if the product will not be used for a long period of
Automatic Blood
time.
• Disconnect the power plug before starting maintenance.
Pressure Monitor
• Use only the original AC adapter designed for this unit. Use of unsupported
adapters may damage and/or may be hazardous to the unit.
Model JPN600
Instruction Manual General Precautions
• Do not forcibly bend the arm cuff or bend the air tube excessively.
• To unplug the air plug, pull on the air plug at the connection with the main
3100085-2A
unit, not the tube itself.
• Do not apply strong shocks and vibrations to or drop the unit and arm cuff.
• Do not inflate the arm cuff when it is not wrapped around your arm.
Introduction
• Read and follow the "Important information regarding Electro Magnetic
Compatibility (EMC)" in the EMC information provided with this unit.
Thank you for purchasing the OMRON JPN600 Automatic Blood Pressure
• Do not use the device outside the specified environment. It may cause an
Monitor.
inaccurate reading.
The OMRON JPN600 is a compact, fully automatic blood pressure monitor,
• Dispose of the device, components and optional accessories according to
operating on the oscillometric principle. It measures your blood pressure and
applicable local regulations. Unlawful disposal may cause environmental
pulse rate simply and quickly. For comfortable controlled inflation without the
pollution.
need of pressure pre-setting or re-inflation the device uses its advanced
"IntelliSense" technology.
1. Overview
Intended Use
Main unit:
This product is designed to measure the blood pressure and pulse rate of
people within the range of the designated arm cuff, following the instructions in
A
this instruction manual.
It is mainly designed for general household use. Please read the Important
Safety Information in this instruction manual before using the unit.
Please follow this instruction manual thoroughly. D F
Please keep for future reference.
E
For specific information about your own blood pressure, CONSULT
D D
YOUR DOCTOR.
A. Display
Important Safety Information
B. Memory button
Please read this section carefully before using the unit. C. START/STOP button
D. Date/Time setting ( ) button
Warning: Indicates a potentially hazardous situation which, if not avoided,
E. Cuff wrapping guide lamp
could result in death or serious injury.
Arm cuff:
(General Usage)
• DO NOT adjust medication based on measurement results from this blood
pressure monitor. Take medication as prescribed by your doctor. Only a M
doctor is qualified to diagnose and treat High Blood Pressure.
• Consult your doctor before using the device for any of the following
conditions: common arrhythmias such as atrial or ventricular premature beats
or atrial fibrillation, arterial sclerosis, poor perfusion, diabetes, age,
pregnancy, pre-eclampsia, renal diseases.
Note that PATIENT motion, trembling, shivering may affect the measurement
reading.
Display:
• Do not use the device on the injured arm or the arm under medical treatment.
• Do not apply the arm cuff on the arm while being on an intravenous drip or
N
blood transfusion.
O
• Consult your doctor before using the device on the arm with an arterio-
venous (A-V) shunt. P
• Do not use the device with other medical electrical (ME) equipment simulta-
Q
neously.
• Do not use the device in the area the HF surgical equipment, MRI, or CT
R
scanner exists, or in the oxygen rich environment.
S
• The air tube or the AC adapter cable may cause accidental strangulation in
infants.
T
• Contains small parts that may cause a choking hazard if swallowed by
U
infants.
• Stop using the unit and consult your doctor if you experience skin irritation or N. Average value symbol
other troubles. O. Memory symbol
P. Irregular heartbeat symbol
(AC Adapter (optional) Usage) Q. Systolic blood pressure
• Do not use the AC adapter if the unit or the power cord is damaged. Turn off R. Diastolic blood pressure
the power and unplug the power cord immediately. S. Low battery symbol
• Plug the AC adapter into the appropriate voltage outlet. Do not use a T. Cuff wrapping guide
multiple-tap.
• Never plug in or unplug the power cord from the electric outlet with wet
hands.
2. Preparation
Caution: Indicates a potentially hazardous situation which, if not avoided,
2.1 Installing/Replacing the Batteries
may result in minor or moderate injury to the user or patient or
damage to the equipment or other property.
1.
Remove the battery cover.
(General Usage)
2.
• Always consult your doctor. Self-diagnosis of measurement results and Insert four "AA" batteries
self-treatment are dangerous.
as indicated in the battery
• Consult your doctor before using the device for any of the following
compartment and then
conditions:
replace the battery cover.
- If you have had a mastectomy.
- People with severe blood flow problems or blood disorders as cuff inflation
can cause bruising. Notes:
• Do not take measurements more than necessary. It may cause bruising due • If the low battery symbol (
to blood flow interference. monitor off then replace all batteries at the same time.
• If there are any abnormalities during the measurement, remove the arm cuff. • The measurement values continue to be stored in memory even after
• Do not use this device on infants or persons who cannot express their the batteries are replaced.
intentions. • The supplied batteries may have a shorter life.
• Do not inflate the arm cuff more than necessary. • Dispose of the device, components and optional accessories
• Do not use the unit for any purpose other than measuring blood pressure. according to applicable local regulations. Unlawful disposal may
• Use only the approved arm cuff for this device. Use of other arm cuffs may cause environmental pollution.
result in incorrect measurement results.
2.2 Setting the Date and Time
• Do not use a mobile phone or other devices that emit electromagnetic fields,
near the device. This may result in incorrect operation of the device.
1.
Press the button.
• Do not disassemble the monitor or arm cuff. This may cause an inaccurate
reading.
2. Set the monitor to the correct date and time before
• Do not use in a location with moisture, or a location where water may splash
on the device. This may damage the device.
taking a measurement for the first time.
• Do not use the device in a moving vehicle (car, airplane).
(Battery Usage)
• Do not insert the batteries with their polarities incorrectly aligned.
• Use only four "AA" alkaline or manganese batteries with this unit. Do not use
other types of batteries. Do not use new and used batteries together.
• Remove the batteries if the unit will not be used for 3 months or more.
(AC Adapter (optional) Usage)
• Fully insert the power plug.
• When disconnecting the power plug, do not pull the power cord. Be sure to
Year
hold the power plug.
3.
Press the START/STOP button to store the setting.
Do not break it.
Notes:
Do not forcibly bend or pull.
• If the batteries have been replaced, the date and time setting will
Do not bundle during use.
need to be reset.
Do not place under heavy objects.
• If the date and time are not set, "-:--" appears during or after
measurement.
3. Using the Unit
3.1 Applying the Arm Cuff
Remove tight-fitting clothing or tight rolled up sleeve from your
upper arm. Do not place the arm cuff over thick clothes.
1.
Insert the air plug into the air jack
securely.
2.
Put your arm through the cuff
loop.
G
H
The bottom edge of the arm
I
B cuff should be 1 to 2 cm
above the elbow. Marker
C
(arrow under the air tube) is
F. Up/Down ( ) buttons centred on the middle of
G. Battery compartment your inner arm.
H. AC adapter jack (for optional
AC adapter)
I. Air jack
3.
Close the fabric fastener
FIRMLY.
J
J. Arm cuff (Arm circumference
22 - 32 cm)
K. Air plug
L. Air tube
K
M. Marker
L
Notes:
• When you take a measurement on the right
arm, the air tube will be at the side of your
elbow. Be careful not to rest your arm on
V
the air tube.
W
• The blood pressure can differ between the right arm and the left arm,
and therefore also the measured blood pressure values can be
different. OMRON recommends to always use the same arm for
X
measurement. If the values between both arms differ substantially,
please check with your doctor which arm to use for your
Y
measurement.
Z
3.2 How to Sit Correctly
U. Heartbeat symbol
To take a measurement, you need to be
• Flashes during measurement.
relaxed and comfortably seated, under
V. Date/Time display
comfortable room temperature. Avoid
W. Movement error symbol
bathing, drinking alcohol or caffeine,
X. Blood pressure level indicator
Y. Deflation symbol smoking, exercising or eating 30 minutes
Z. Pulse display and Memory before taking a measurement. Also avoid
number
taking measurements during stressful
time. Stress raises blood pressure.
• Sit on a chair with your legs uncrossed and
your feet flat on the floor.
• Sit upright with your back straight.
• Sit with your back and arm being supported.
• The arm cuff should be placed on your arm
at the same level as your heart.
3.3 Taking a Reading
Notes:
• To cancel a measurement, press the START/STOP button to release
the air in the arm cuff.
• Remain still while taking a measurement.
) appears on the display, turn the
1.
Press the START/STOP button.
The arm cuff will start to inflate automatically.
START INFLATE DEFLATE
Cuff Wrapping Guide Lamp
1) Push or buttons to
change.
2) Push the button to confirm. If your systolic pressure is more than 210 mmHg
Next setting appears.
After the arm cuff starts to inflate, press and hold the START/STOP
button until the monitor inflates 30 to 40 mmHg higher than your
expected systolic pressure.
Notes:
• The monitor will not inflate above 299 mmHg.
Month
Day • Do not apply more pressure than necessary.
Hour
Minute
Note: Wait 2-3 minutes before taking another blood pressure
measurement. Waiting between readings allows the arteries to
return to the condition prior to taking the blood pressure
measurement.
Always consult your doctor. Self-diagnosis of measurement
results and self-treatment are dangerous.
Cuff Wrapping Guide Lamp:
The cuff wrapping guide lamp lights in green, the cuff is correctly
wrapped tightly enough on the arm and the reading is accurate and
reliable. If it does not light, the reading is not reliable due to the
incorrect wrapping of the cuff. Please wrap the cuff again, taking care
to wrap it correctly and take the measurement again.
2.
Remove the arm cuff.
3.
Press the START/STOP button to turn the monitor off.
The monitor automatically stores the measurement in its memory.
It will automatically turn off after 2 minutes.
Important:
• Recent research suggests that the following
values can be used as a guide to high blood
pressure for measurements taken at home. 4.1 Error Messages
Systolic Blood Pressure ≥ 135 mmHg
Diastolic Blood Pressure ≥ 85 mmHg
This criteria is for home blood pressure measurement.
• Your blood pressure monitor includes an
irregular heartbeat feature. Irregular heartbeats
1 to 2 cm can influence the results of the measurement.
The irregular heartbeat algorithm automatically
determines if the measurement is usable or
needs to be repeated. If the measurement
results are affected by irregular heartbeats but the result is valid, the
result is shown together with the irregular heartbeat symbol ( ). If
the irregular heartbeats cause the measurement to be invalid, no
result is shown. If the irregular heartbeat symbol ( ) is shown after
you have taken a measurement, repeat the measurement. If the
irregular heartbeat symbol ( ) is shown frequently, please make
your doctor aware of it.
• If you move during measurement, the movement
error symbol ( ) will appear on the display.
Keep still and repeat the measurement.
Using the Guest Mode
The monitor stores measurement values for one user in the memory.
The guest mode can be used to take a single measurement for
another user. No measurement values are stored in the memory when
the guest mode is selected.
1.
Press and hold the START/STOP
button for more than 3 seconds.
The date/time display will disappear.
2.
Release the START/STOP button when the date/time
display turns off.
The arm cuff will start to inflate automatically.
3.4 Using the Memory Function
The monitor automatically stores the result up to 90 sets. It can also
calculate an average reading based on the measurements from the
last three readings taken within 10 minutes. If there are only two
readings in memory for that period, the average will be based on two
readings. If there is one reading in memory for that period, the average
will be based on one reading.
Notes:
• If the memory is full, the monitor will delete the oldest reading.
• When viewing the reading taken without setting the date and time,
"-:--" is displayed instead of the date and time.
To View the Readings Stored in Memory

4.2 Troubleshooting

1. Press the button.
The Memory number appears for a second before the pulse rate is
displayed. The newest set is numbered "1".
Alternating date/time display
COMPLETE
Note: The cuff wrapping guide result appears
on the display with the measurement
values. The cuff wrapping guide lamp will
not light.
: The arm cuff was correctly wrapped tightly enough.
: The arm cuff was loose or not wrapped correctly.
2.
Press the or button to view the readings stored in
memory.
: To the older readings
: To the more recent readings
To View the Average Value
1.
Press and hold the button for
more than 3 seconds.
Notes:
Problem
• If the previous reading was taken without setting
the date and time, the average value is not
calculated.
Cannot measure or The arm cuff has not
• If there are no measurements results stored in
readings are too low been inflated
the memory, the screen to the right is displayed.
or too high. sufficiently.
The batteries are
To Delete All the Values Stored in Memory empty.
Nothing happens
When the memory symbol ( ) appears, first press the Memory when you press the
The batteries have
button. Then while holding it down, press the START/STOP buttons.
been inserted
button simultaneously for more than 3 seconds.
incorrectly.
• Press the START/STOP button and repeat
measurement.
• If the problem continues, try replacing the
Other problems.
batteries with new ones.
If this still does not solve the problem, contact
your local OMRON representative.
Note: You cannot partially delete the stored readings.
4.3 Maintenance
4. Troubleshooting and Maintenance
To protect your unit from damage, please observe the following:
• Do not subject the main unit and the cuff to extreme
Error Display Cause Remedy temperatures, humidity, moisture or direct sunlight.
• Do not fold the cuff or tubing tightly.
Remove the arm cuff. Wait
• Do not disassemble the unit.
2 - 3 minutes and then take
Irregular heartbeats are another measurement. • Do not subject the unit to strong shocks or vibrations
detected. Repeat the steps in section
(for example, dropping the unit on the floor).
3.3. If this error continues to
• Do not use volatile liquids to clean the main unit.
appear, contact your doctor.
• Do not wash the arm cuff or immerse it in water.
Movement during Carefully read and repeat
• Do not use petrol, thinners or similar solvents to clean
measurement. the steps in section 3.3.
the arm cuff.
Apply the arm cuff correctly. • Do not carry out repairs of any kind yourself. If a defect
Cuff is not applied correctly.
Refer to section 3.1.
occurs, consult your local OMRON representative.
You should replace them
with new ones ahead of
The batteries are low.
time.
Refer to section 2.1.
You should replace them
The batteries are
with new ones at once.
exhausted.
Refer to section 2.1.
Insert the plug securely.
Air plug disconnected.
Refer to section 3.1.
Arm cuff not applied Apply the arm cuff correctly.
correctly. Refer to section 3.1.
Replace the cuff with the
Air is leaking from the arm
new one. • The unit should be cleaned with a soft, dry cloth.
cuff.
Refer to Chapter 5.
• Use a soft, moistened cloth and neutral soap to clean
the arm cuff.
Repeat measurement.
Remain still and do not talk
during measurement.
Note: Read and follow the "Correct Disposal of This Product" in the
Refer to section 3.3.
Movement during Technical Data Section when disposing of the device and any
measurement and the arm used accessories or optional parts.
If "E2" appears repeatedly,
cuff has not been inflated
inflate the cuff manually
sufficiently.
Calibration and Service
until it is 30 to 40 mmHg
above your previous • The accuracy of this blood pressure monitor has been
measurement result.
carefully tested and is designed for a long service life.
Refer to section 3.3.
• It is generally recommended to have the unit inspected
every two years to ensure correct functioning and
The arm cuff was inflated
Do not inflate the cuff above
above 299 mmHg accuracy. Please consult your local OMRON
299 mmHg.
when inflating the cuff
Refer to section 3.3. representative.
manually.
Repeat measurement.
4.4 Storage
Movement during Remain still and do not talk
measurement. during measurement.
• Keep the unit in its storage case when not in use.
Refer to section 3.3.
• Store the device and the components in a clean, safe location.
Remove any clothing
1.
Unplug the air plug from the air jack.
Clothing is interfering with
interfering with the arm cuff.
the arm cuff.
Refer to section 3.1.
2.
Gently fold the air tube into the arm cuff.
Contact your local OMRON
Device error.
representative . Note: Do not bend the air tube excessively.
3.
Place the arm cuff and main unit in
the storage case.
Problem Cause Remedy
Apply the arm cuff
Arm cuff not applied
correctly.
Do not store the unit in the following situations:
correctly.
Refer to section 3.1.
• If the unit is wet.
Remain still and do not • Locations exposed to extreme temperatures,
The reading is talk during humidity, direct sunlight, dust or corrosive
Movement or talking
extremely low (or measurement. vapors such as bleach.
during measurement.
high). Refer to section 3.3. • Locations exposed to vibrations, shocks or
where it will be at an angle.
Remove any clothing
Clothing is interfering interfering with the arm
5. Optional Parts
with the arm cuff. cuff.
Refer to section 3.1.
Small Cuff Medium Cuff
Make sure that the air
The air tube is not HEM-CS24 HEM-CR24
tube is connected
securely connected Arm circumference Arm circumference
securely.
into the main unit.
Arm cuff pressure 17 - 22 cm 22 - 32 cm
Refer to section 3.1.
does not rise.
Replace the arm cuff
Air is leaking from the
with a new one.
arm cuff.
Refer to Chapter 5.
Apply the cuff correctly
AC Adapter S
Arm cuff deflates too so that it is firmly
The arm cuff is loose.
soon. wrapped around the arm.
Refer to section 3.1.
Notes:
Cause Remedy
• Please use Adapter [60110HW5SW] in Taiwan, Adapter
[6V06ASW-KA] in Korea.
Inflate the cuff so that it
• Please check with your local OMRON representatives for the
is 30 to 40 mmHg above
appropriate optional parts.
your previous
measurement result.
Using the Optional AC Adapter
Refer to section 3.3.
Replace the batteries 1.
Insert the AC adapter plug
with new ones.
into the AC adapter jack on
Refer to section 2.1.
the rear side of the main
Insert the batteries with
unit.
the correct (+/-) polarity.
Refer to section 2.1. 2.
Plug the AC adapter into an
electrical outlet.
To disconnect the AC adapter, unplug the AC adapter from the
electrical outlet first and then remove the AC adapter plug from the
main unit.
6. Technical Data
Product Description Automatic Blood Pressure Monitor
Model JPN600
Display LCD Digital Display
Measurement Method Oscillometric method
Measurement Range Pressure: 0 to 299 mmHg
Pulse: 40 to 180 beats/ min.
Accuracy Pressure: ±3 mmHg
Pulse: ±5% of display reading
Inflation Fuzzy-logic controlled by electric pump
Deflation Automatic pressure release valve
Memory 90 measurements with date and time
IP classification IP 20
Rating
DC6V 4W
Power Source
4 "AA" batteries 1.5V
or AC adapter (optional, INPUT AC100-240V
50/60Hz 0.12A)
Battery Life
Approx. 1000 measurements
(using new alkaline batteries)
Durable Period
Main Unit: 5 years
Cuff: 1 year (when used 6 times a day)
Applied Part
= Type BF
Protection Against
Internally powered ME equipment (When using only
Electric Shock
the batteries)
= Class II ME equipment (Optional AC adapter)
Operating
+10 to +40°C / 30 to 85% RH / 700 to 1060 hPa
temperature/ Humidity
/ Air Pressure
Storage temperature/ -20 to +60°C / 10 to 95% RH / 700 to 1060 hPa
Humidity/ Air pressure
Console Weight Approx. 280g without batteries
Cuff Weight Approx. 130g
Outer Dimensions Approx. 107 (w) mm × 79 (h) mm × 141(l) mm
Cuff Dimensions Approx. 145 mm × 466 mm
(Cuff: arm circumference 22 to 32 cm)
Cuff/ Tube Material Nylon, polyester, polyvinyl chloride
Package Contents Main unit, arm cuff, instruction manual, battery set,
storage case, EMC information
Notes:
• Subject to technical modification without prior notice.
• This device is clinically investigated according to the requirements of ISO
81060-2:2013.
• IP classification is degrees of protection provided by enclosures in
accordance with IEC 60529. This device is protected against solid foreign
objects of diameter 12 mm such as a finger and greater.
• This device fulfils the provisions of EC directive 93/42/EEC (Medical Device
Directive).
• This blood pressure monitor is designed according to the European Standard
EN1060, Non-invasive sphygmomanometers Part 1: General Requirements
and Part 3: Supplementary requirements for electromechanical blood
pressure measuring systems.
• This OMRON product is produced under the strict quality system of OMRON
HEALTHCARE Co., Ltd., Japan. The core component for OMRON blood
pressure monitors, which is the Pressure Sensor, is produced in Japan.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it
should not be disposed of, with other household wastes at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate
this product from other types of wastes and recycle it responsibly to
promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can
return this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions
of the purchase contract. This product should not be mixed with other commercial
wastes for disposal.
Manufacturer OMRON HEALTHCARE Co., Ltd.
53, Kunotsubo, Terado-cho, Muko, KYOTO,
617-0002 JAPAN
OMRON HEALTHCARE EUROPE B.V.
Wide Range Soft Cuff Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS
HEM-RML31
Arm circumference
Asia Pacific HQ OMRON HEALTHCARE SINGAPORE PTE LTD.
22 - 42 cm
438A Alexandra Road, #05-05/08,
Alexandra Technopark, Singapore 119967
www.omronhealthcare-ap.com
Production facility OMRON HEALTHCARE Co., Ltd.
Matsusaka Factory
Mie, JAPAN
Made in Japan
