R
INSTRUCTION MANUAL
MANUAL INFLATION
BLOOD PRESSURE MONITOR
HEM-432C
Model

Advertisement

Table of Contents
loading

Related Manuals for Omron HEM-432C

Summary of Contents for Omron HEM-432C

  • Page 1 INSTRUCTION MANUAL MANUAL INFLATION BLOOD PRESSURE MONITOR HEM-432C Model...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction …………………………………………………………… 3 Important Safety Notes ……………………………………………… 4 Know Your Unit ……………………………………………………… 5 Quick Reference Guide ……………………………………………… 6 Battery Installation/Replacement …………………………………… 7 Care and Maintenance ……………………………………………… 8 How To Apply The Arm Cuff …………………………………… 9-10 How To Take A Measurement …………………………………...

  • Page 3: Introduction

    Thank you for purchasing the Omron HEM-432C Manual Inflation Blood Pressure Monitor. Fill-in for future reference DATE PURCHASED: ______________ SERIAL NUMBER: ________________ Staple your purchase receipt here. The monitor features an easy-to-squeeze inflation bulb that allows you to quickly inflate the cuff. The measurement reading is clearly displayed on a large digital panel.

  • Page 4: Important Safety Notes

    Do not use on infants. Do not use a cellular phone near the unit. It may result in operational failure. Changes or modifications not approved by Omron Healthcare will void the user warranty. Do not disassemble or attempt to repair the unit or components.

  • Page 5: Know Your Unit

    Systolic Blood Pressure Display Diastolic Blood Pressure / Pulse rate Display Arm Cuff Air Tube Air Tube (Connects to the air plug) KNOW YOUR UNIT Air Plug MEMORY Button ON/Off Button Air Release Button Inflation Bulb Air Tube (Connects to the air plug) Air Plug...

  • Page 6: Quick Reference Guide

    QUICK REFERENCE GUIDE 1. Avoid eating, smoking, and exercising for at least 30 minutes before taking a measurement. 2. Put your left arm through the cuff loop. The bottom of the cuff should be about 1/2 inch above the elbow. The cuff tab should lie over the brachial artery on the inside of the arm.

  • Page 7: Battery Installation/Replacement

    BATTERY INSTALLATION / REPLACEMENT 1. Slide the battery cover off in the direction of the arrow. 2. Install 4 “AA” size batteries so + (positive) and – (negative) polarities match the polarities of the battery compartment as indicated. 3. Replace the battery cover. NOTE: If the Low Battery Indicator appears on the display, replace all four batteries.

  • Page 8: Care And Maintenance

    CARE AND MAINTENANCE To keep your digital blood pressure monitor in the best condition and protect the unit from damage follow the directions listed below: Clean the monitor with a soft dry cloth. Do not use any abrasive or volatile cleaners. Do not attempt to clean the cuff. Never immerse the monitor or any components in water.

  • Page 9: How To Apply The Arm Cuff

    HOW TO APPLY THE ARM CUFF 1. If the cuff is assembled correctly, the sewn hook material will be on the outside of the cuff loop and the metal D-ring will not touch your skin. 2. Pass the end of the cuff furthest from the tubing through the metal D-ring to form a loop.

  • Page 10: How To Apply The Arm Cuff

    HOW TO APPLY THE ARM CUFF 4. Pull the cuff so that the top and bottom edges are tightened evenly around your arm. 5. When the cuff is positioned correctly, press the sewn hook material FIRMLY against the pile side of the cuff. 6.

  • Page 11: How To Take A Measurement

    HOW TO TAKE A MEASUREMENT Please read “How To Apply The Arm Cuff” before taking a reading. 1. Press the ON/OFF Button. a) All display symbols appear for about one second. This is the initial LCD Test. b) The display symbols disappear and the Deflation Indication Symbol ( ) starts to flash.
  • Page 12 HOW TO TAKE A MEASUREMENT 3. Remain still. The cuff will begin to deflate automatically. 4. As the cuff deflates, decreasing numbers appear on the display. The Heart Symbol ) flashes at every heartbeat. 5. When measurement is complete, the Heart Symbol ( ) stops flashing and your blood pressure and pulse rate are displayed alternately.

  • Page 13: How To Use The Memory Function

    HOW TO USE THE MEMORY FUNCTION This monitor has a memory capable of storing fourteen (14) sets of readings. Every time you complete the measurement, the monitor automatically stores blood pressure and pulse rate. • Press the ON/Off Button. • Press the MEMORY Button to recall stored readings while the Heart Symbol ( ) is displayed.

  • Page 14: Error Indicators

    ERROR INDICATORS Error Symbol Cause Cuff under-inflated. Movement during Measurement No pulse or blood pressure reading due to very weak artery pulse. Residual air pressure in cuff. Cuff over-inflated (more than 300 mmHg). Batteries have run down. Correction Wait 2-3 minutes and take another measurement.

  • Page 15: Fcc Statement

    FCC STATEMENT Note: POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 16: Warranty Information

    WARRANTY INFORMATION Your HEM-432C Manual Blood Pressure Monitor, excluding the monitor cuff, is warranted to be free from defects in materials and workmanship appearing within 1 year, when used in accordance with the instructions provided with the monitor. The monitor cuff is warranted to be free from defects in materials and workmanship appearing within one year, when the monitor is used in accordance with the instructions provided with the monitor.

  • Page 17: Specifications

    Arm Circumference Range: Accessories: UPC Code: NOTE: These specifications, to improve performance, are subject to change without notice. SPECIFICATIONS HEM-432C LCD Digital Display Pressure: 0 to 280 mmHg Pulse: 40-180/min. Pressure: ±3mmHg or 2% of reading Pulse: ±5% of reading...

  • Page 18: Notes

    NOTES...
  • Page 19 NOTES...
  • Page 20 Made in China Manufactured by: OMRON HEALTHCARE, INC. 300 Lakeview Parkway Vernon Hills, Illinois 60061 www.omronhealthcare.com Copyright © 2003 Omron Healthcare, Inc. 432CINST Rev A...
