Dynojet POWER COMMANDER V Installation Instructions page 3

FIG.A
FIG.B
FIG.C
ground wire
20-023 www.powercommander.com
unplug
Ground wire
1 Remove the main seat and the passenger seat.
2 Hold the front of the fuel tank up using the prop rod located in the trunk area.
3 Locate the connector from the main wiring harness to the injector rail and
unplug this connector as shown in Figure A.
Note: This connector is white in color.
4 Attach the connectors from the PCV to the stock wiring harness connectors as
shown in Figure B.
5 Route the PCV wiring along the inside of the frame towards the battery.
6 Attach the ground wire from the PCV to the negative side of the battery as
shown in Figure C.
2002-2007 Suzuki Hayabusa - PCV - 3
