CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 15-1350B
STAMINA PRODUCTS
MADE IN CHINA
© 2016 Stamina Products, Inc.
2017, 08
Advertisement
Table of Contents
Related Manuals for Stamina 1350
Summary of Contents for Stamina 1350
- Page 1 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Care © 2016 Stamina Products, Inc. 1 (800) 375-7520 2017, 08 www.staminaproducts.com...
-
Page 2: Table Of Contents
4. We recommend that two people be available for assembly of this product. 5. Keep children away from the Magnetic Recumbent 1350 Bike. Do not allow children to use or play on the Magnetic Recumbent 1350 Bike. Keep children and pets away from the Magnetic Recumbent 1350 Bike when it is in use. - Page 3 1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.
-
Page 4: Before You Begin
T h a n k y o u f o r c h o o s i n g t h e M a g n e t i c Although Stamina constructs its products with Recumbent 1350 Bike. We take great pride in the finest materials and uses the highest standards... -
Page 5: Equipment Warning, Caution & Notice Labels
EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the Magnetic Recumbent 1350 Bike . Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. -
Page 6: Hardware Identification Chart
HARDWARE IDENTIFICATION CHART This chart is provided to help identify the fasteners used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed. - Page 8 ASSEMBLY INSTRUCTIONS STEP 4 NOTE: Install the HEX BOLTS(M6x1x37mm)(50) as shown in the illustration below. This allows the head of the bolts to fit inside the hex shape holes in the SEAT FRAMES(5, 6). Attach the RIGHT HANDRAIL(8) to the RIGHT SEAT FRAME(6) with HEX BOLTS(M6x1x37mm)(50), ARC WASHERS(M6)(64), LOCK WASHERS(M6)(66), and ACORN NUTS(M6x1)(60).
- Page 9 ASSEMBLY INSTRUCTIONS STEP 6 Refer to illustration A. There are two straps attached inside of the METER POST(26) to assist when pulling the SENSOR WIRE(28) and the TENSION CABLE(24) through the METER POST(26). Tie STRAP A to the plug end of the SENSOR WIRE(28). Tie STRAP B to the BRACKET of the TENSION CABLE(24). Pull the STRAP A from the top of the METER POST(26) until the SENSOR WIRE(28) is pulled through and extends out of the top of the METER POST(26).
- Page 10 ASSEMBLY INSTRUCTIONS STEP 8 NOTE: The RIGHT PEDAL(35) has R stamped on the end of the pedal shaft. The RIGHT PEDAL(35) has right hand threads and is tightened by turning clockwise. The LEFT PEDAL(34) has L stamped on the end of the pedal shaft. The LEFT PEDAL(34) has left hand threads and is tightened by turning counterclockwise.
-
Page 11: Set Up Instructions
SET UP INSTRUCTIONS Place the Magnetic Recumbent 1350 Bike in the area where it will be used. It is recommended that the Magnetic Recumbent 1350 Bike be placed on an equipment mat. The Magnetic Recumbent 1350 Bike is approximately 61 3/4 inches long (max.) x 27 1/2 inches wide x 36 inches tall. (These dimensions may vary up to one inch.) An area 4 feet wide x 7 feet long is required for safe operation of the Magnetic... -
Page 12: Operational Instructions
CAUTION: Do not attempt to adjust the seat while you are on the Magnetic Recumbent 1350 Bike. 2. Always tighten the ADJUSTMENT KNOB(37) after adjusting the seat to a new position. CAUTION: Do not use the HANDRAIL(7, 8) to raise or lower your full body weight. - Page 13 OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON : Pedal movement or press the button. POWER OFF : A u t o m a t i c a l l y s h u t s o ff a f t e r f o u r minutes of inactivity.
-
Page 14: Storage
2. Adjust the REAR FRAME(3) and FRONT FRAME(1) to the shortest position. The Magnetic Recumbent 1350 Bike is approximately 39 3/4 inches long x 27 1/4 inches wide x 32 1/4 inches tall. These dimensions will vary. Please measure your Magnetic Recumbent 1350 Bike if exact dimensions are needed. -
Page 15: Conditioning Guidelines
CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs. -
Page 16: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place. -
Page 17: Warranty
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520. -
Page 18: Product Parts Drawing
PRODUCT PARTS DRAWING FRONT Strap A Strap B BACK... -
Page 19: Parts List
PARTS LIST PART# PART NAME Front Frame Front Stabilizer Rear Frame Rear Stabilizer Left Seat Frame Right Seat Frame Left Handrail Right Handrail Pulley w/ Crank Bearing Housing Ball Bearing Inside Bearing Collar Outside Bearing Collar Bearing Washer Bearing Snap Washer Bearing Nut V-Ribbed Belt Idler Arm... - Page 20 PARTS LIST PART# PART NAME Bolt, Button Head (M10 x 1.5 x 122mm) Bolt, Hex Head (M6 x 1 x 37mm) Bolt, Round Head (M6 x 1 x 35mm) Bolt, Flat Head (M10 x 1.5 x 20mm) Bolt, Flat Head (M10 x 1.5 x 35mm) Screw, Round Head (M5 x 0.8 x 15mm) Screw, Flat Head (M5 x 0.8 x 10mm) Screw, Flat Head (M4 x 15mm)
-
Page 21: Notes
NOTES... -
Page 22: Fax/Mail Ordering Form
P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
