Boyo VTB46M User Manual

1
Brief Introduction
Thank you for purchasing the Bluetooth rearview mirror monitor, please read
this user's guide to get start.The following is the introduction of the monitor.
High sensitive external
High sensitive
microphone
ambient light sensor
4.3" ultra high brightness
automatically adjustable LCD screen
2
Checking the accessories
Make sure that you have the following items with your Bluetooth rearview
mirror: user manual, microphone, cover, wire.
3
Starting up
The first time you use the rearview mirror, it will automatically start up
when the car is started. You need to wait for 1 minute to connect your
phone with the mirror. Because at the first minute, the mirror keeps
searching last paired cell phone.
4
Connecting to new phone
You need to wait for more 2 minutes after the flash of the Bluetooth
device completely disappear, and then connect your mobile phone or
other device to rearview mirror.
15:27
Rearview mirror
General Pair
PIN:1234
1 2 3
4 5 6
7 8 9
0
X
5
Successfully connected
After the password has been set, a bluetooth icon will appear on the
monitor. It means the connection is successful. 5 seconds later, the
monitor will automatically shut off and then becomes completely
invisible. The Bluetooth system enters standby state.
Green indicator
Multi-function button
6
Making a call
Using the phone's keypad
Dial number on the keypad or select the contact name from the contact
list of your mobile phone.
Press phone's "send/call" key.
491540 15:27
+
1 2 3
4 5 6
7 8 9
0 #
*
7
Voice dialing
Please ensure your mobile phone supports voice dialing function.
When the rearview mirror is in the standby state, to short press the
button is to activate voice control function. In 3 seconds, you can hear
a beep sound. Please speak out the phone number you want to call or
other commands, and then the phone will deal with it.
8
Answering a call
Shortly press the button to answer the call, when you are receiving an
incoming call.
Short press
Short press
Answering
