- Page 1 ONE-TOUCH WIRELESS HEALTH TRACKER BODY LIFE TRACKER User Manual Model: VA 01 Document No : AMI-PRD-UM-B-VA01 Version : 4.0 Date : 08.03.2018...
- Page 2 B.O.L.T User Manual Model No: VA 01 Legal Disclaimer This publication/content contains proprietary information which is protected by copyright. No part of this publication may be reproduced, transcribed, stored in a retrieval system, translated into any language or computer language, or transmitted in any form whatsoever without the prior written consent of the publisher.
-
Page 3: Document History
B.O.L.T User Manual Model No: VA 01 Document History Version Date Comment 31-12-2015 Initial Release 23-03-2015 Added battery care section 31-12-2015 Included FCC statement 08-03-2018 Updated the Images and related contents © Copyright 2018, All Rights Reserved. American Megatrends India Private Ltd. -
Page 4: Table Of Contents
Model No: VA 01 Table of Contents 1. Intended Use ..................5 2. Product Description ................5 3. Package Contents of BOLT VA 01 ............. 6 4. Product Quality, Reliability and Safety ............7 Warning ..................7 Caution ..................9 Care and Maintenance .............. -
Page 5: Intended Use
2. Product Description The B.O.L.T VA 01 device is a medical gadget with NiBP (Non-invasive Blood Pressure), Pulse Oximeter (SpO2) and Infrared Thermometer (IRT) that gets controlled from a smartphone/ tablet. The B.O.L.T device is a cloud-enabled solution, where your health vitals can be stored in your personal health cloud. -
Page 6: Package Contents Of Bolt Va 01
B.O.L.T User Manual Model No: VA 01 3. Package Contents of BOLT VA 01 S. No Packing List Quantity Base Unit Cuff IR Thermometer (IRT) Probe Dust Cover 1 pack SpO2 probe Power Adapter USB Cable Warranty Card Quick Reference Guide... -
Page 7: Product Quality, Reliability And Safety
B.O.L.T User Manual Model No: VA 01 4. Product Quality, Reliability and Safety The device has been designed with an emphasis on quality, reliability and safety, but AMI can only accept responsibility for these aspects, provided the following conditions are met ... - Page 8 B.O.L.T User Manual Model No: VA 01 Removing USB Plug Zoomed View The user can remove the USB Plug while charging the device. The user is recommended to insert the given lemo connector plug in the accessory connector port when accessories are not connected.
-
Page 9: Caution
B.O.L.T User Manual Model No: VA 01 4.2 Caution Do not use the gadget while moving in a vehicle as this may result in erroneous readings. Do not use any other branded cuffs as this may result in inaccurate measurements. -
Page 10: Contraindications
Safe and convenient to use. 7. Operating Environment The B.O.L.T device has been designed for use in the hospitals, clinics or directly by the patient at home to monitor the health conditions. The user or the physician is responsible for ensuring that the device is stored and used in appropriate environmental conditions. -
Page 11: Using B.o.l.t Application
1. Download and Install B.O.L.T application from the Play store/Application store/Windows application market. 2. On successful installation, launch the B.O.L.T application on the mobile device. 3. Create a User Name with your Email ID or use Facebook Credentials for login. -
Page 12: Blood Pressure Measurement With B.o.l.t
5. Login with the User Name and Password which was used for the registration or use Guest login. Measuring BP with B.O.L.T 6. On successful login of the B.O.L.T application, Select “How is my health” option to perform Master Health checkup or select “Check Vitals” option to perform the individual test and continue. -
Page 13: Blood Pressure Classification For Adults
B.O.L.T User Manual Model No: VA 01 14. On successful measurement, the Blood Pressure and Pulse rate are displayed and a copy of reading will be mailed to your Near & Dear mail IDs on saving the data. 15. Multiple BP readings can be taken with 1-minute interval by selecting the auto- reading option. -
Page 14: Blood Oxygen Level Measurement Procedures
Place the index finger properly inside the SpO2 probe. 11.1 Blood Oxygen Level measurement with B.O.L.T B.O.L.T enables connecting a SpO2 probe through which the blood oxygen level is measured. Connecting SpO2 probe with the gadget Insert the SpO2 connector into the socket firmly as shown below. -
Page 15: Blood Oxygen Level Classification
B.O.L.T User Manual Model No: VA 01 6. On successful measurement, the SpO2 value and Pulse rate will be displayed and a copy of reading will be mailed to your Near & Dear mail IDs on saving the data. Note: Ensure to clean your hands before taking a SpO2 measurement. For some readings, fluctuations may occur below 85% of SpO2 for certain ethnicity group. -
Page 16: Temperature Measurement Procedures
Remain stable during the measurement. Wait until the application displays the measured temperature. 12.1 Body Temperature measurement with B.O.L.T B.O.L.T enables connecting an IR Thermometer probe through which the temperature is measured. Connecting IR Thermometer probe with the gadget Insert the IR Thermometer connector into the socket firmly as shown below. -
Page 17: Temperature Classification
B.O.L.T User Manual Model No: VA 01 7. Kindly dispose the dust cover in the disposable container. 12.2 Temperature Classification Please note that this table can give only a generic view. Consult with your physician for accurate assessment. Temperature Classification... -
Page 18: Battery Care
B.O.L.T User Manual Model No: VA 01 14. Battery Care The power adapter is included in the pack and the specifications are mentioned below. AC input: 100-240V, Frequency: 50Hz to 60Hz, 0.35A Max, DC output: +5V @ 2A Connect the power adapter to the power source and micro USB port to the base unit`s USB Power Socket. - Page 19 B.O.L.T User Manual Model No: VA 01 3. Press and remove the battery cover in the recommended direction as shown below. 4. Disconnect the battery pack from the connector and replace with new one. 5. Install the battery cover and fasten with the screw.
-
Page 20: Troubleshooting
B.O.L.T User Manual Model No: VA 01 15. Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION 1. Check your Internet Application not installing from connectivity the App store/Play 1. Internet/Data store/Windows market disconnection 2. Move some of the 2. Memory space application from... - Page 21 B.O.L.T User Manual Model No: VA 01 Connect the respective No charge in the power adaptor to the battery B.O.L.T device switched ON, but B.O.L.T device and charge. no LED is glowing Then power ON, if still the LED is not glowing kindly...
-
Page 22: Explanation Of Indicators/Symbols
B.O.L.T User Manual Model No: VA 01 Click Near & Dear option in Readings are not received in Mail Entries in Near & settings panel and verify mail Dear section the mail IDs and retry 16. Explanation of Indicators/Symbols Indicators/Symbols... - Page 23 B.O.L.T User Manual Model No: VA 01 Symbol for “EUROPEAN REPRESENTATIVE” Symbol for “EUROPEAN CONFORMITY” Symbol for “Federal Communication Commission” Symbol for “Read the documentation” Symbol for “Warning” Symbol for “Temperature limitation” Symbol for “Symbol for “TYPE BF APPLIED PARTS” (Cuff only) Symbol for “Fragile”...
-
Page 24: Technical Specifications
B.O.L.T User Manual Model No: VA 01 17. Technical Specifications Product Name B.O.L.T Model VA 01 Base Unit Base Unit Dimensions 130 (L) X 40.3 (H) X 75 (D) mm Base Unit Weight 220 grams (Including Battery) Power Source DC 5V 2A Battery 3.7V Li-Polymer 850mAH... -
Page 25: Certifications
B.O.L.T User Manual Model No: VA 01 Environmental Specifications Operating Temperature +10° to +40° C (+50 ° F to +104 ° F) Storage Temperature -10° to +55° C (14° F to +149° F) Operating Humidity 15 to 85% non-condensing Storage Humidity 15 to 85% non-condensing 18. - Page 26 B.O.L.T User Manual Model No: VA 01 FCC compliance statements This device complies with Part 15 of the FCC Rules. Its operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including Interference that may cause undesired operation.
-
Page 27: Warranty Information
Model No: VA 01 Warranty Information The B.O.L.T is warranted to be free from defects in materials and workmanship within one year from the date of purchase when used in accordance with the provided instructions. The warranty is extended only to the end user. The company will repair free of charge any part or parts of the product if the defect is due to the faulty material or workmanship. - Page 28 B.O.L.T User Manual Model No: VA 01 European Representative American Megatrends International GmbH Truderingerstraße (Truderinger Strasse) 283 81825 München (Munich), Deutschland (Germany) Tel: [49] 89 969995-10 europesales@ami.com Email: © Copyright 2018, All Rights Reserved. American Megatrends India Private Ltd.
