Summary of Contents for AirTurn PEDpro
- Page 1 PEDpro HANDS-FREE BLUETOOTH CONTROLLER for Bluetooth 4 Tablets AND Computers Operating Manual V2...
-
Page 3: Table Of Contents
CONTENTS Before Turning on Your PEDpro ..........5 Power ..................6 MODES ................... 7 Changing the MODE ............8 Connecting and Pairing ............9 Open and Closed Pairing ............. 9 Open Pairing ..............9 Closed Pairing ............... 10 Reset Pairiing ..............10 Switching Between Pairing Methods ........ - Page 4 Care of Your PEDpro ............. 15 Warranty ................15 Radio Information..............16 Recycling and Disposal ............18 Trademarks ................18...
-
Page 5: Before Turning On Your Pedpro
PEDpro provides a myriad of uses. BEFORE TURNING ON YOUR PEDpro The PEDpro works with most Bluetooth 4 devices. This includes iPad 3 and later, iPhone 4S and later, and most devices running Android 4.3 or later with Bluetooth 4. -
Page 6: Power
ON - Press and hold the Power Button for one second and the LED’s flash. The blue LED will begin to blink 2 times per second until pairing is started. OFF - Press and hold the Power Button on the PEDpro until the red and blue LEDs turn off. -
Page 7: Modes
MODES There are seven modes available on your PEDpro. Each mode sends a different signal for each pedal. The PEDpro is set to MODE 2 by default. (You can also customize MODES 2-6 with the AirTurn Manager.) MODE 1: AirDirect This mode is app specific. -
Page 8: Changing The Mode
MIDI control for sending basic MIDI commands to your app. Support for Bluetooth MIDI required and special setup for your tablet or computer may be required. MIDI commands may be setup using the AirTurn Manager. More detailed instructions available online. CHANGING THE MODE Turn on the PEDpro. -
Page 9: Connecting And Pairing
OPEN PAIRING This is the new way in which PEDpro devices pair and is the same way that almost all Bluetooth devices pair. In Open Pairing you do not need to delete the pairing to connect to another device so you can easily connect your PEDpro to your iPad, smartphone or computer. -
Page 10: Closed Pairing
If you connect to more than 8 devices, the next pairing will delete the earliest pairing. If you delete or “forget” the pairing of the PEDpro on a device, restart the Bluetooth and attempt to re-pair with the PEDpro. CLOSED PAIRING This method locks one PEDpro to one tablet, phone or computer. -
Page 11: Switching Between Pairing Methods
Open your devices’ Bluetooth Setup dialog: iOS – Select Settings>Bluetooth and turn on the Bluetooth if it is off. When the PEDpro is discovered, it will appear in the list of devices. Tap on the selection. A dialog box will then appear. Tap... -
Page 12: Power Consumption
Android – Select Settings>Bluetooth and turn it on if it is off. Make sure your device is set to discoverable. Then tap the SCAN button. When the PEDpro appears, tap to pair. (If you are asked to verify the passcode, click on OK). -
Page 13: Recharging The Battery
Solid blue Pedal pressed AIRTURN MANAGER To change the configuration of your PEDpro and update its firmware to the latest available, download the AirTurn Manager App from the Apple App Store or Google Play Store. It is available for iPad, iPhone, most Android devices and Mac computers. -
Page 14: Unit Identification
V2.1.0 refers to the firmware number. ABCD refers to the MAC address. This is helpful if there are many PEDpro units in the same location. Your MAC address will always be the same so you can easily identify your unit. You will find your specific MAC address labeled on the bottom of your PEDpro at the end of the serial number. -
Page 15: Care Of Your Pedpro
Be careful not to use sharp tools or extreme pressure on the pedal area as this will reduce the life of the membrane switches. • Do not get the PEDpro wet or place in direct sunlight for extended periods of time. -
Page 16: Radio Information
Product and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall AirTurn be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs... - Page 17 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 18: Recycling And Disposal
AirTurn also holds unintended emissions testing on file for FCC/CE RECYCLING AND DISPOSAL Electronic components and construction comply with RoHS and REACH standards. Packaging is recyclable. Please recycle. Contains Lithium Ion Battery. Battery should be disposed of according to local law. AirTurn will recycle returned batteries and electronics. - Page 19 Check out other great products from AirTurn including tablet holders, portable tablet stands and accessories.
- Page 21 888-247-1223...
Need help?
Do you have a question about the PEDpro and is the answer not in the manual?
Questions and answers
I have managed to hook up my pedpro but when I go to my sheet music (pdf) nothing works. Could you steer me through this? I **** running an android tablet
To set up the AirTurn PEDpro with an Android tablet for controlling PDF sheet music, follow these steps:
1. Turn on the PEDpro by pressing the power button.
2. Ensure the PEDpro is in the correct mode for keyboard or mouse input (Mode 2-6). You can change the mode by holding the MODE button until the red light blinks the correct number of times.
3. Enable Bluetooth on your Android tablet:
- Go to Settings > Bluetooth and turn it on.
- Ensure your device is set to discoverable.
4. Pair the PEDpro:
- Tap the SCAN button in Bluetooth settings.
- When the PEDpro appears in the list, tap to pair.
- If prompted to verify a passcode, tap OK.
5. Open your PDF sheet music app and configure it to respond to Bluetooth input.
Your PEDpro should now be ready to control page turns in your PDF sheet music app.
This answer is automatically generated
