14.6. Rate

The Rate command allows you to define the maximum rate mode for SPRs/IDRs
and BSR, and other rate options for the BSR. This command is similar to the Rate
command described in Section 11.8, "Rate" and Section 17.8, "Rate" for BSR and
SPR respectively.
Note: The maximum rate mode (i.e. Max Mode field) must be identical for all
the SPRs/IDRs and the BSR.
The path for this command is as follows:
Menu bar: MultiDevices > Rate
The Multi Rate dialog box is displayed below.
24020311-08
B S R Z o o m W i n d o w - M u l t i D e vi c e s M e n u
Figure 14-13: Multi Rate dialog box
