These instructions explain how to install the TracVision C3 on a vessel. Complete instructions
on how to use the system are provided in the User's Guide.
Installation Steps
1.
2.
Plan the Installation.......................... 4
3.
4.
5.
Drill the Mounting Holes ................ 7
6.
Mount the Antenna .......................... 8
7.
8.
Wire the Antenna ........................... 10
9.
Who Should Install the System?
To ensure a safe and effective installation, KVH recommends that a KVH-authorized technician
install the system. To find a technician near you, please visit www.kvh.com/wheretogetservice.
Linear vs. Circular Systems
The installation process differs, depending on the type of LNB (low noise block) installed in the
antenna (linear or circular). These differences are noted throughout this guide. In general, North
American satellites require a circular LNB, while European satellites require a linear LNB.
Technical Support
If you need technical assistance, please contact KVH Technical Support:
N. America, S. America, Australia:
Phone: +1 401 847-3327
E-mail: techs@kvh.com
(Mon.-Fri., 9 am-6 pm ET, -5 GMT)
(Sat., 9 am-2 pm ET, -5 GMT)
KVH, TracVision, and the unique light-colored dome with dark contrasting baseplate are registered trademarks of KVH Industries, Inc.
All other trademarks are property of their respective companies. The information in this document is subject to change without notice.
No company shall be liable for errors contained herein. © 2008-2010 KVH Industries, Inc., All rights reserved. 54-0361 Rev. C
C3 Installation Guide
®
Europe, Middle East, Asia:
Phone: +45 45 160 180
E-mail: support@kvh.dk
(Mon.-Fri., 8am-4:30 pm, +1 GMT)
10.
Wire the Receiver(s) ....................... 12
11.
Wire the Switchplate...................... 14
12.
Install Service Key(s)...................... 15
13.
Mount the Switchplate................... 16
14.
Install Satellites ............................... 17
15.
Find the Skew Angle...................... 18
16.
Set the Skew Angle......................... 19
17.
18.
Educate the Customer.................... 21
