Elevation Motor/Belt Replacement
Instructions for TracVision
These instructions explain how to replace an elevation motor and/or elevation motor belt in a
TracVision M9 antenna.
Installation Steps
1. Remove the Radome, 2
2. Mark the Current Belt Tension, 2
3. Remove the Belt, 3
4. Remove and Replace the Elevation
Motor (if required), 3
Tools Required
This procedure requires the following tools:
• Phillips screwdrivers
• Tension meter (30 lb/13.06 Kg or
greater)
Technical Support
If you need technical assistance, please contact KVH Technical Support:
N. America, S. America, Australia:
Phone: +1 401 847-3327
E-mail: techs@kvh.com
KVH, TracVision, and the unique light-colored dome with contrasting baseplate are registered trademarks of KVH Industries, Inc.
All other trademarks are property of their respective companies. The information in this document is subject to change without notice.
No company shall be liable for errors contained herein. © 2008 KVH Industries, Inc., All rights reserved. 54-0532 Rev. A
®
5. Replace the Belt, 3
6. Set the Belt Tension, 4
• Needle-nose pliers
• Scribe or pencil
Europe, Middle East, Asia:
Phone: +45 45 160 180
E-mail: support@kvh.dk
M9
1
