Charging Battery - Maxcom MM916 User Manual

After inserting the battery, 2 screws should
be placed or, if such a need arises, pushed
into the battery cover openings; then, place
the battery cover onto the phone, and screw 2
screws, slightly pressing.

2.2 Charging Battery

Note! Use only the original battery included in the
set. Using other batteries might damage the
phone and will void the warranty.
Never plug in the charger when the back cover is
not in place.
To charge the phone:
1. Plug the charger into a power outlet,
2. Remove the rubber, and plug the charger
jack into a slot located in the bottom of the
phone. A message will appear on the LCD
informing you that the phone has been
plugged in, and battery indicator bars will blink
while charging.
3. As soon as the battery is fully charged
(battery indicator bars stop blinking) unplug
the battery, and disconnect the cable from the
phone.
14
