Installation instruction for
Digital Line Amplifier
DPA 1.2500
Subwoofer Amplifier
1 x 2500 watt
art.no.: 271023
Please read carefully the installation instructions before you start installing the amplifier!
Audio Teile Team GmbH -
P.O. Box 1225 – 74899 Bad Rappenau
Phone + 49 / 7264 – 9136-0, Fax + 49 / 7264-9163-50
1
Advertisement
Related Manuals for Rainbow DPA 1.2500
Summary of Contents for Rainbow DPA 1.2500
- Page 1 Installation instruction for Digital Line Amplifier DPA 1.2500 Subwoofer Amplifier 1 x 2500 watt art.no.: 271023 Please read carefully the installation instructions before you start installing the amplifier! Audio Teile Team GmbH - P.O. Box 1225 – 74899 Bad Rappenau...
- Page 2 Technical specifications DPA 1.2500 • Digital power amplifier (class D) with integrated peak current MOSFET switch-mode power supply. • Double amplifier output for double voice coil-subwoofer, 1 Ω stable. • Amplification with very low noise. • Pre-amplification input dissymmetrical used for optimum interference suppression.
- Page 3 Front view and operating elements DPA 1.2500 Picture 1: 1 = Input jacks stereo „Line Input“ for the signal input from the CD-radio. 2 = Output jacks stereo „Line Out“ for additional amplifier. 3 = Controller „Level“ for the adjustment of the input sensitivity of „Line Input“.
-
Page 4: Installation
Installation DPA 1.2500 Install the amplifier on a suitable, well-aerated place in the vehicle possibly on the Chassis sheet metal with the included sheet metal screws. The heating of the amplifier can reach a very high surface temperature. Enough space to high temperature sensible elements is absolutely necessary. - Page 5 Remote Connection DPA 1.2500 Lay the cable with small diameter from the car-radio- or CD-player-Remote clamp to the amplifier and fix onto the amplifier connection „REM“ (12) using an end splice. When switching on- or off the car-radio/CD-player, the amplifier will be switched on- or off with a time-invariant of 2 seconds by a soft muting.
- Page 6 Picture 2: Connection of the amplifier with chinch cables. Connection of the loudspeaker DPA 1.2500 The subwoofer will be connected to the connecting terminal „SP“ (13), which are clearly marked with + and -. Please provide before connection the endings of cables with end splices. The use of a minimum cable diameter of 4 mm²...
- Page 7 Picture 3: Connection of one or two subwoofers. In case of subwoofers with double voice coils, you can use one connecting clamp each for the voice coils. Adjustment of the „subwoofer“ DPA 1.2500 Low Pass: This operation mode is only used for the operation of subwoofers. The internal active crossover will only pass according to the installations of the potentiometer „Low Pass“...
- Page 8 The amplifier DPA 1.2500 has no phase invert circuit. The adjustment of the phase can be effected through a change of the poles of the loudspeaker cables on the subwoofer (+ to – and – to +).
- Page 9 Notice for current supply DPA 1.2500 In order to avoid potential differences and disturbances, it has to be guaranteed that the minus line (-) has the same cable diameter as the positive line (+). The car body is due to the high potential differences not suitable as minus pole for this use.
- Page 10 → Remedy: Put electrical insulation filters into the antenna cable (Art.no.: 251001/251055). If the interruption still didn’t appear then make the following: 6. Disconnect the minus line (-) of the audio system from point 1 and connect to the motor block.
- Page 11 Picture 5: Principle of the circuit diagram Main fuse Equipotential bonding conductor generator body Connection if needed...
- Page 12 The guarantee is limited to the replacement of defective components, which have defect due to construction- or material fault, as well as to the guarantee repair. Accidents, acts of god or other causes, which Rainbow is not responsible for, in particular water and fire are not included in the guarantee.
