- Page 1 XCELLENCE SERIES X-15LTP Pol. Ind. Norte - Perpinyà, 25 08226 TERRASSA (Barcelona-SPAIN) Copyright © 2012 info@master-audio.com All rights reserved master-audio.com Dec 12 User’s manual...
- Page 2 ENGLISH WARNING: CAUT ION To reduce the risk of fire or electric shock do not expose this equipment to rain or moisture RISK OF ELECTRIC SHOCK DON’T OPEN Safety Instructions 1. All safety instructions must be read before using this device. 2.
- Page 3 Master Audio 1. Introduction 1.1. General product information Master Audio thank you for the trust placed in our Xcellence loudspeaker system. The X15LTP incorporates the highest technology features that take this system to a new level of sound performance. More than 40 years’ experience in amplifier and acoustic cabinet design using the highest technology and components come together to give you a product ideal for a multitude of applications, from sound back-up systems for theatres, clubs or TV channels to even corporative events or concert halls.
- Page 4 Master Audio The lower surface incorporates a pole mount socket for a standard 35mm tripod and the top surface incorporates a M10 thread. 2.1. Technical description The X15LTP cabinet comes with full range sound delivery thanks to its direct radiation transducer and acoustic bass reflex cabinet. As a full range system, its response is 50-18kHz (+/- 3dB) with a usable bandwidth between 42Hz-19kHz (- 10dB).
- Page 5 Master Audio A) SPEAKON: The X15LTP uses two Speakon terminals. Each NL4 connector includes: PIN+1/-1: power signal from the amplifier. WARNING: Respect the polarity +/- PIN+2/-2: no connection It is strongly recommended to use a multi-conductor high quality wire, non- shielded.
- Page 6 Master Audio Fig.4. Full Range Stereo connection 5. Mounting and installation Whenever possible, mount the Full Range units in a high position (between 2 and 3 meters above ground), angled towards the audience. If the units are mounted close to the ground the back row listeners will receive low quality sound.
- Page 7 Master Audio Do not use the tripod on sloping surfaces nor mount the cabinets too high to avoid total instability of the system. The brand logo can be turned for use in the horizontal position. 6. Flying with ACRM10 The X15LTP provides M10 flying points. Their correct use will permit the flying in horizontal or vertical position Vertical Flying Points 1.
- Page 8 Master Audio 7. Technical specifications 7.1. X15LTP specifications Impedance 4 Sensitivity 1W/1m 99dB Frequency response (-10 dB) 42Hz-19kHz Power handling R.M.S 1000W Program 2000W Nominal directivity (-6dB) Horizontal 60º (rotative horn) Vertical 50º Components 1x15" neodymium woofer (4” voice coil) 1x neodymium driver, titanium diaphragm (3”...
- Page 9 Master Audio 8. APPENDIX POWER LOSSES (%) AND DAMPING FACTOR, RELATED TO WIRE LENGTH AND SECTION Wire Section Resistance Power losses Damping losses(*) length (Ohms) 8Ohms 4Ohms 2Ohms 8 Ohms 4 Ohms 0.75 0.042 0.53% 1.05% 2.10% 1.50 0.025 0.31% 0.63% 1.25% 2.50...
- Page 10 Master Audio PRESET1: FACTORY Parameters Out 1/ LEFT_1 Out 2/RIGH_1 Out3/LEFT_2 Out 4/RIGH_2 Out 5/LEFT_3 Out 6/RIGH_3 Level 0 dB 0 dB 0 dB 0 dB 0 dB 0 dB Delay 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms EQ1 Bypass Type Freq 53Hz 53Hz...
- Page 11 Master Audio PRESET2: NEARFIELD Parameters Out 1/ LEFT_1 Out 2/RIGH_1 Out3/LEFT_2 Out 4/RIGH_2 Out 5/LEFT_3 Out 6/RIGH_3 Level 0 dB 0 dB 0 dB 0 dB 0 dB 0 dB Delay 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms EQ1 Bypass Type Freq 53Hz 53Hz...
- Page 12 Master Audio PRESET3: LOUDNESS Parameters Out 1/ LEFT_1 Out 2/RIGH_1 Out3/LEFT_2 Out 4/RIGH_2 Out 5/LEFT_3 Out 6/RIGH_3 Level 0 dB 0 dB 0 dB 0 dB 0 dB 0 dB Delay 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms EQ1 Bypass Type Freq 53Hz 53Hz...
- Page 13 Master Audio PRESET4: SPEECH Parameters Out 1/ LEFT_1 Out 2/RIGH_1 Out3/LEFT_2 Out 4/RIGH_2 Out 5/LEFT_3 Out 6/RIGH_3 Level 0 dB 0 dB 0 dB 0 dB 0 dB 0 dB Delay 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms EQ1 Bypass Type HI-SHELF HI-SHELF HI-SHELF...
- Page 14 Master Audio PRESET5: XOVER Parameters Out 1/ LEFT_1 Out 2/RIGH_1 Out3/LEFT_2 Out 4/RIGH_2 Out 5/LEFT_3 Out 6/RIGH_3 Level 0 dB 0 dB 0 dB 0 dB 0 dB 0 dB Delay 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms 0.0ms EQ1 Bypass Type Freq 53Hz 53Hz...
