human care NSB-104-M Quick Reference Manual

Quick Reference Guide
– General Purpose Sling
Description
The General purpose sling is available in two versions, reusable and single patient use. Both slings have an easy fit with built
in flexibility to achieve proper leg and body positioning for patients with some upper body control.
Applying the sling from a seated position
1. Stand behind or to the side of the
patient and hold the sling with label
facing up and away.
Applying the sling from a lying position
1. Stand to side and turn the patient
to face you. Place gathered sling
behind back with label facing up
and away.
Part no:
Single patient use:
NSB-104-S
NSB-104-M
NSB-104-L
NSB-104-XL
Reusable sling:
NSB-103-S
NSB-103-M
NSB-103-L
NSB-103-XL
NSB-109-2XPH (bariatric)
Reusable with clips:
NSB-103C-S
NSB-103C-M
NSB-103C-L
NSB-103C-XL
2. Work the sling down the back
and the bottom edge must be
behind the coccyx.
2. Turn the patient on back and
pull gathered sling towards you.
Different color loops on reusable
and single use models. Color
coded loops* on lifting straps to
customize fit during lift.
3. Pull the leg sections through to
the front. Raise each leg and pull
the band under patient.
3. Bring the leg bands underneath
the thighs to achieve the desired
positioning of the legs.
Look for top of head to be 1-2"/2,5-
5,0 cm below top of sling for best fit.
Always position behind
the coxxyx, down to tip
of tailbone for proper fit.
4. Position legs. Lower lift carry bar and secure-
ly attach straps with appropriate loop. Reverse
steps above to unload patient from sling.
4. Lower lift carry bar and securely attach straps
with appropriate loop. As lift ensure straps
secure and clear of patient head. Reverse steps
above to unload patient from sling.
www.humancaregroup.com
Page 1
