LNC230 LOREX PING SERIES
QUICK START GUIDE
1A
IPHONE / IPAD
® ®
1: Connect the power adapter to the camera
and connect the other end to a power outlet.
Do not connect the Ethernet cable.
2: Connect your smartphone or tablet to your WiFi
network.
3: Download the free Lorex Ping app, and
tap the Lorex Ping icon to open the app.
4:
Press Wifi Setup
Then
Press Next
5:
Enter the password
for your WiFi network
and press OK
A QR code appears on the screen with your WiFi
network details.
6:
Press the WPS button on the
camera. The LEDs will start flashing
www.lorextechnology.com
QUICK MOBILE GUIDE
/ ANDROID™ WIFI SETUP
7: Place your phone or tablet about 1ft (30cm)
away from the camera.
1ft (30cm)
The camera scans the QR code on your device to connect to the WiFi
network and beeps once it is successfully scanned. In a few seconds,
the connection starts and a message appears on your device.
NOTE: If the QR code does not scan, complete option 1B and then
complete the Optional WiFi setup instead.
8:
Enter a name for your
Lorex Camera
camera and press OK
9:
Tap the camera to
connect
You will be prompted to create
your own password. Tap OK
Enter a new password
and then tap OK/Done
10: Tap the name of the camera in Camera List again
to connect to the camera. Lorex Ping streams live
video from your camera.
NOTE For security, a separate admin user name and
password is required to change camera settings.
Default admin user name: admin
Default admin password: ______ (leave blank)
1B
IPHONE / IPAD
®
1: Connect the power adapter to the camera
and connect the other end to a power outlet.
OR
2: Connect an Ethernet cable (included) to the NET
port on the camera and connect the other end to
your router (not included).
Internet
LAN
Ethernet Cable
3: Download the free Lorex Ping app, and
tap the Lorex Ping icon to open the app.
4: Press + to add a camera.
5:
Enter a name for your camera
Press the QR code button and
scan the QR code on the back
of the camera
Alternatively, you can manually enter the
CamID found on the back of your camera.
/ ANDROID™ ETHERNET SETUP
®
6:
Lorex Camera
7:
8: Tap the name of the camera in Camera List
again to connect to the camera. Lorex Ping
streams live video from your camera.
For security, a separate admin user name and
NOTE
password is required to change camera settings.
Default admin user name: admin
Default admin password: ______ (leave blank)
OPTIONAL WIFI SETUP
1: From the Camera List, tap
2: Tap Camera Settings and enter the admin
user name/password above.
3: Tap Network>WiFi Network.
4: Slide Wi-Fi to ON or check Wi-Fi and select
your WiFi network. Enter the password and tap
CamID #
OK. Wait for the update to complete.
5: Remove the Ethernet cable from the camera and
it will connect to the WiFi network.
Enter the camera password.
The password is lorex the
first time you connect to the
camera. Press Done
Tap the camera to
connect
You will be prompted to create
your own password. Tap OK
Enter a new password
and then tap OK/Done
.
LNC230_Series_QSG_EN_R1
