Summary of Contents for Sailor 6207
- Page 1 INSTALLATION GUIDE SAILOR 6207 Connection box for parallel handsets Drilling plan Thrane & Thrane A/S info@thrane.com www.thrane.com • •...
- Page 2 Cable, part no. 406209-941 Description Wire color NMEA in+ Brown Handset 1 Handset 2 VHF 62XX NMEA in- Blue NMEA HS in- White NMEA HS in+ Green Mike 2 / Line in Yellow Ear 2 / Line out Grey Hook_PTT Pink Bat_SW Supply voltage when on Internal GND = - Battery...
