Vendor: S000013
ASSEMBLY INSTRUCTIONS
VALENTINO 2 DRAWER 4'6 BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR VALENTINO 2
DRAWER 4'6 BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
www.birlea.com
Page 1 of 11

Advertisement

loading
Need help?

Need help?

Do you have a question about the VALENTINO 2 DRAWER and is the answer not in the manual?

Questions and answers

Related Manuals for Birlea VALENTINO 2 DRAWER

Summary of Contents for Birlea VALENTINO 2 DRAWER

  • Page 1 Vendor: S000013 ASSEMBLY INSTRUCTIONS VALENTINO 2 DRAWER 4’6 BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR VALENTINO 2 DRAWER 4’6 BED FRAME. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT jump on this bed frame.
  • Page 2 Vendor: S000013 Page 2 of 11...
  • Page 3 Vendor: S000013 Parts List Hardware List (Found in box 3) Part Description Part Description Headend 8 x 25 mm Plastic Dowel Footend M6 x 40 mm JCBC Side Rail M6 x 40 mm JCBC Solid Slats M6 x 60 mm JCBC Centre Rail M3.5 x 16 mm CSK Support Leg...
  • Page 4 Vendor: S000013 Step 2: Slide the drawer base (11) into position on both drawers. Secure with hardware part M and a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 3: Secure the drawer supports (13) using hardware part G and a screwdriver.
  • Page 5 Vendor: S000013 Step 5: Insert hardware parts A and N to the drawer frame back (14) using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 6: Attach the drawer runners from pack 2 (8) to the left drawer frame side (15) using hardware part E and a screwdriver (not provided).
  • Page 6 Vendor: S000013 Step 8: Attach the drawer runners from pack 2 (8) to both sides of the drawer frame divider (17) using hardware part E and a screwdriver (not provided). Insert hardware parts A and N using a small mallet (not provided).
  • Page 7 Vendor: S000013 Step 11: Insert the left drawer frame side (15), right drawer frame side (16) and drawer frame divider (17) to the drawer frame back (14). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 12: Secure using hardware parts B and O.
  • Page 8 Vendor: S000013 Step 14: Insert and secure the right drawer frame support (19) using hardware parts B and O. Secure the supports in the centre using hardware parts A, K, J and O. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 15: Insert hardware part A to the footend (2) using a small mallet (not provided), then insert hardware part J using a screwdriver (not provided).
  • Page 9 Vendor: S000013 Step 17: Secure the frame using hardware parts C, G, I and O with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 18: Insert hardware part J to the side rails (3) using a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
  • Page 10 Vendor: S000013 Step 20: Loosen the pre-inserted screws on the headboard (1) using hardware part O. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 21: Secure the frame using hardware parts L, K and O. DO NOT use any power tools as this may damage the frame and will invalidate any claim.

  • Page 11: Additional Information

    • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
