Summary of Contents for Birlea STOCKWELL 3 DOOR 2 DRAWER WARDROBE
-
Page 2: Health And Safety
Periodically check all screws & fixings to ensure they are secure. DO NOT push this product as this will cause damage. Always lift this product with two people to reposition. Keep any sharp objects away from this product . Page of 8 www.birlea.com... - Page 3 Vendor: S000350 Parts List Hardware List (BOX 4) Part Descripion Qty Part Description Top panel Cam lock Bottom panel Minifix screw Side panel ( Left ) Plastic cap Side panel ( Right ) M8 x 30mm Wood Dowel Center panel (Up) M6 x 60mm CSK Cap Wood screw Center panel (Down) Allen key M4...
- Page 4 Vendor: S000350 Step 1: Prepare these parts for assembly using hardware parts A1, A2, B, D, E, F, H, J1, K, L, P and R. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Page of 8...
- Page 5 Vendor: S000350 Step 2: Attach middle panel (7) to center panel (5) using hardware C and D. Attach back bone (8) to side panel (3) and center panel (5) then attach back bone (9) to side panel (4) and center panel (5) using hardware A1 and A2 with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 6 Vendor: S000350 Step 5: Attach bottom panel (2) to side panel (3), (4) and center panel (6) using hardware C and D. DO NOT use any power tools as this may damage the frame and will invalidate any claim. C x 6 Step 6: Attach hardware I1 into top panel (1), bottom panel (2), side panel (3) and (4) using hardware I2 with a screwdriver (not provided).
- Page 7 Vendor: S000350 Step 8: Attach door panel (13) to side panel (3), (4) and center panel (5) using hardware E with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Vertical Adjustment E x 18...
- Page 8 Vendor: S000350 Step 10: Assemble the drawer components using hardware E, G and J2. DO NOT use any power tools as this may damage the frame and will invalidate any claim. E x 6 G x 8 ( L/R ) J2 x 2 Step 11: Assemble the drawer components using hardware E, G and J2.
- Page 9 Ensure the head of any screw used has a diameter greater than the mounting hole and the fixing is safe and secure before use. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product.
