ATTO Technology, Inc.
155 CrossPoint Parkway
Amherst, New York 14068 USA
www.attotech.com
Tel
(716) 691-1999
Fax
(716) 691-9353
Sales support:
sls@attotech.com
Technical support: Please visit
https://www.attotech.com/support/
techsupp@attotech.com (716) 691-1999 x242
© 2017 ATTO Technology, Inc. All rights reserved. All brand or product names are trademarks of their respective holders.
No part of this document may be reproduced in any form or by any means without the express written permission of ATTO
Technology, Inc.
3/2017
Thank you for purchasing the ATTO FastFrame 40Gb Ethernet Adapter. This guide gives you the basics for
installing and configuring your adapter. For more information, please visit our website at
1 Overview
This guide covers hardware and software
installation, setup procedures, and
troubleshooting tips for ATTO FastFrame 40Gb
Ethernet adapters.
Ensure you have the equipment and software
you need for the installation:
• FastFrame 40Gb Ethernet Adapter card
• A computer with an available PCIe 3.0
• Cables
2 System Requirements
Before installing the ATTO FastFrame 40Gb
Ethernet Adapter, please check your
system for the following minimum
configuration requirements:
for hours of operation.
PRMA-0470-000
FastFrame™ 40Gb Ethernet Adapter
Getting Started Guide
Note
This guide refers to drivers and features available on
IA-32-based computer platforms and platforms based
on Intel® Extended Memory 64 Technology. These
drivers are not compatible with Itanium®-based
computers.
expansion slot
www.attotech.com
Supported Operating Systems
• Microsoft Windows®
• Microsoft Windows Server®
• Mac OS®
• Linux®
• FreeBSD
Note
Please visit https://www.attotech.com/support/
interoperability/ for details on specific supported operating
systems
3 Installing Drivers
Configure your system to recognize and use
your FastFrame NIC by installing drivers for
your operating system. Current drivers can be
found and downloaded at
https://
www.attotech.com/downloads/
Windows
1 Power on your system and log in as the
administrator or a user with proper
administrative privileges
2 Go to
https://www.attotech.com/
downloads/
3 Register or log in if previously registered.
4 Click on Ethernet Adapters in the left
dialog.
5 Navigate to your HBA model/family in the
right dialog and click on it.
6 Scroll down to and click the desired driver
depending on the operating system.
7 A download window appears. Choose
Save File.
