1
Install screen protector.
3
Place battery pack into the
compartment.
5
Plug charger into Tesla. Follow
on-screen instructions.
Quick Start Guide
2
Loosen quarter turn latches to
open battery compartment door.
4
Close battery compartment.
Replace door, tighten latches.
1
2
3
8
9
10
The anatomy of your Topcon Tesla Rugged Notepad
1
Stylus and Handstrap
2
Touch Screen
3
Power Button
4
Camera Lens
5
Battery Doors
6
SD Card Slot
7
SIM Card Slot
• English
• Deutsch
• Français
• Español
11
12
13
14
8
Handstrap Tethers
9
12V DC Jack
10
Mic/Speaker Jack
11
9-pin Serial Port
12
USB Host
13
USB Client
14
Antenna Bumper (Geo Model)
Documentation CD
part# 61149
part# 20503-00
4
5
6
7
