Single solenoid type (DC) Latching solenoid type (DC)
A (-) Set
A (-)
C (+) COM
SOL.
B (-) Reset
C (+)
Note 1: Single type: non-polarity Note 3: The solenoid valve channel is,
ON: light (orange) illuminates.
Note 2: A (set) side energisation:
A light (orange) illuminates. Note 4: Applicable to negative COM
B (reset) side energisation:
B light (green) illuminates.
Equipped with a wiring error prevention
(stop diode) mechanism and a surge absorption.
Fig 6b
Wiring specification (Fig 6b)
WARNING
Latching solenoid
The latching solenoid is equipped with a self-holding mechanism,
which permits a moveable iron core (Fig 1), in the solenoid, to hold
the 'set' position.
CAUTION Body
Do not employ simultaneous ON and OFF signals, as a 10ms energi-
Ring
sation time is required for self-latching.
Avoid using these valves in applications involving excessive vibration
(10G or more).
Do not use in high magnetic fields.
At despatch the valve is set in the 'un-latched' mode. However it is
possible that it could move to the 'latch' position during transit. Before
operating this valve ensure that it is set to the 'un-latch' position.
See chart below (Fig 7).
Latching Passage Indicator light
A-C ON (Set) 1(P) 2(A) Orange
B-C ON (Reset) 2(A) 3(R) Green
Single Passage Indicator light
A-C ON 1(P) 2(A) Orange
OFF 2(A) 3(R) ––
Fig 7
Fittings
Fig 9
Tighten fittings into the valve using the following torque figures (Fig 8).
Removing a valve from the sub-base (Fig 11)
Mounting thread Correct clamping torque N-m (kgf-cm) Disconnect the electrical connector (Fig 3).
M5 1.5~2.0 (15~20) Remove the valve holding down screws
M3 0.3~0.5 (3~5) Lift off the valve.
Retain the gasket.
Fig 8
Multi-connector (Fig 9) Refitting a valve to a sub-base
Refit the gasket to the sub-base ensuring correct orientation.
Connection Replace the valve.
When fitting a connector align the positioning key grooves and Refit the valve holding down screws.
ensure that the connector is vertical when inserting and that it locks Torque screws to the following figure:
into position. 0.9 kgf/cm.
Disconnection Mounting/Removing from a DIN-rail (Fig 10)
To disconnect the connector, lift the locking ring and remove the
body in a straight line (vertically). Removing
Loosen the clamp screw of the end plate
manifold. Lift side (a) of the manifold base, slide the end plate in the
Maintenance direction of 2 to remove.
WARNING
Mounting
Hook side (b) of the manifold base onto the DIN-rail.
Before carrying out any form of maintenance ensure all air and power Press down side (a) and clip the end plate onto the DIN-rail.
supplies are isolated. Tighten the clamp screws to the following torque figures:
0.8 N-m~1.2 N-m (8~12 kgf/cm).
SOL.
A-(set): I (P) 2(A)
B-(reset) : 2A 3(R)
Fig 10
specification model.
Positioning key
Fig 11
Blanking plate (Fig 12) (VVQ100-10A-1)
This type of blanking plate is fitted to multi-connector manifolds.
Ensure that the gasket
Fit the blanking plate
Fit and tighten the holding down screws
figures as the valve holding down screws (see above).
Blanking plate with 2 damp screws and gasket
(Fig 1).
on both ends of the
Fig 12
DIN-rail mounting
bracket
DIN-rail mounting
bracket
Blanking plate (Fig 13) (VVQ100-10A-2)
This type of blanking plug is fitted to standard multi-connector
is correctly fitted. manifolds (plug lead).
onto the manifold station.
to the same torque
Blanking plate with 2 damp screws and gasket
Fig 13
Fitting as above.
Wiring specifications
Positioning key
Pin No.
Multi-connector pin arrangement
Pin No.
SOL.
1 station 1
SOL.
2 stations 2
SOL.
3 stations 3
SOL.
4 stations
4
SOL.
5 stations
5
SOL.
6 stations
6
SOL.
7 stations
7
SOL.
8 stations
8
SOL.
9 stations
9
SOL.
10 stations
10
SOL.
11 stations
11
SOL.
12 stations
12
SOL.
13 stations
13
SOL.
14 stations
14
SOL.
15 stations
15
SOL.
16 stations
16
SOL.
17 stations
17
SOL.
18 stations
18
COM
19
COM
20
Electrical wiring specifications
Terminal No./Lead wire colour
Lead wire colour
Terminal No.
Lead wire colour Dot marking
1 Black -–
2 Brown -–
3 Red -–
4 Orange -–
5 Yellow -–
6 Pink -–
7 Blue -–
8 Violet White
9 Grey Black
10 White Black
11 White Red
12 Yellow Red
13 Orange Red
14 Yellow Black
15 Pink Black
16 Blue White
17 Violet -–
18 Grey -–
19 Orange Black
20 Red White
Fig 14
