SMC Networks VQ0000 Series Installation And Maintenance Manual

023a/eng
Installation and Maintenance Manual
Series VQ0000/1000/2000 Series Solenoid Valve,
Body Ported Type (Metal/Rubber Seal)
For future reference, please keep this manual in a safe place
This manual should be read in conjunction with the current valve catalogue
Safety Instructions 2. Only trained personnel should operate pneumatically
operated machinery and equipment.
These safety instructions are intended to prevent a hazardous situa-
Compressed air can be dangerous if an operator is unfamiliar
tion and/or equipment damage.These instructions indicate the level with it. Assembly, handling or repair of pneumatic systems should
of potential hazard by label of "Caution", "Warning" or "Danger". be performed by trained and experienced operators.
To ensure safety, be sure to observe ISO4414 (Note1) , JIS B 8370 (Note2)
and other safety practices. 3. Do not service machinery/equipment or attempt to
Note 1: ISO 4414: Pneumatic fluid power – Recommendations for the remove component until safety is confirmed.
application of equipment to transmission and control systems. 1) Inspection and maintenance of machinery/equipment should
Note 2: JIS B 8370: Pneumatic system axiom. only be performed after confirmation of safe locked-out
control positions.
CAUTION : 2) When equipment is to be removed, confirm the safety process
Operator error could result in injury or
as mentioned above. Switch off air and electrical supplies and
equipment damage.
exhaust all residual compressed air in the system.
3) Before machinery/equipment is re-started, ensure all safety
WARNING :
Operator error could result in serious
measures to prevent sudden movement of cylinders etc.
injury or loss of life.
(Bleed air into the system gradually to create back-pressure,
i.e. incorporate a soft-start valve).
DANGER :
In extreme conditions, there is a
possible result of serious injury or loss of life. 4. Contact SMC if the product is to be used in any of the
following conditions:
1) Conditions and environments beyond the given specifica-
WARNING tions, or if product is used outdoors.
2) Installations in conjunction with atomic energy, railway, air
1. The compatibility of pneumatic equipment is the respon- navigation, vehicles, medical equipment, food and beverage,
sibility of the person who designs the pneumatic system recreation equipment, emergency stop circuits, press
or decides its specifications. applications, or safety equipment.
Since the products specified here are used in various operating 3) An application which has the possibility of having negative
conditions, their compatibility for the specific pneumatic system effects on people, property, or animals, requiring special
must be based on specifications or after analysis and/or tests to safety analysis.
meet your specific requirements.
CAUTION
Ensure that the air supply system is filtered to 5 micron.
Standard specifications (Fig 2)
Type of seal
Fluid Air • Inert gas
Note3) Max. operating pressure
Single 0.1MPa (1.0 kgf/cm
Double 0.18MPa (1.8 kgf/cm
Min. operating pressure
(latching)
Valve specifications
3 position 0.1MPa (1.0 kgf/cm
Proof pressure
Ambient and fluid temperature -10~+50°C
Lubrication
Manual override
Protection structure
Coil rated voltage
Allowable voltage
Solenoid Type of coil insulation
specifications Power consumption 24VDC 1WDC (42mA),
(current value) 12VDC 1WDC (83mA),
Note 1: Use dry air to prevent dew condensation when operating at low temperature.
Note 2: Push-locking type (B) or (C) should be selected for double (latching) type.
Note 3: Value for low-wattage (0.5W) specifications.
Note 4: Value for high-pressure (1.5W) type specifications.
Installation
CAUTION Symbol
2 position single
Ensure all air and power supplies are isolated before commencing
installation.
WARNING
DO NOT INSTALL THESE VALVES IN EXPLOSIVE ATMOSPHERES.
If these valves are exposed to water or oil droplets, ensure that the
valves are protected. 2 position double (latching)
If it is intended to energise a valve for an extended period please
consult SMC.
Fig 1
Plug lead unit/flip type (Fig 3)
Connector
assembly
Type of
connection
Fig 3
Tube connection (push-in fitting) (Fig 5)
Ensure that the end of the tube is cut square. Push the tube firmly into
the fitting until it stops. Pull back on the tube to ensure that it is
engaged.
Metal seal Rubber seal
Air • Inert gas
0.7MPa (High pressure type: 0.8MPa)
2 ) 0.15MPa (1.5 kgf/cm 2 )
2 ) 0.18MPa (1.8 kgf/cm 2 )
2 ) 0.2MPa (2.0 kgf/cm 2 )
1.5MPa (15.3 kgf/cm 2 )
Note 1) -5~+50°C Note 1)
Not required
Note 2) Non-locking push type/push-locking
tool, lever types (option)
IP40
12, 24VDC
±10% of rated voltage
Class B
Fig 5
Note 3) 1.5WDC (63mA), Note 4) 0.5WDC (21mA)
Note 3) 1.5WDC (125mA), Note 4) 0.5WDC (42mA)
Replacement of cylinder port fittings
The cylinder port fittings are of a cassette type for easy replacement
(except for VQ0000). The fittings are blocked by a clip inserted from
the top of the valve. Remove the clip with a screwdriver to remove fit-
tings. To replace, insert the fitting assembly until it strikes against the
inside wall and then re-insert the clip to the specified position.
Disconnection
Push down on the collet flange, hold down, and withdraw the tube.
Electrical connection, plug lead only (plug connector) (Fig 4)
3 position closed centre
Push the connector onto the pins of the solenoid valve in a straight
line, ensuring that the lip of the lever is securely positioned in the
groove of the solenoid cover.
Groove
3 position exhaust centre
Cover
Metal
seal
Cover
3 position pressure centre
Rubber
seal
Fig 4
Connector
assembly
P port
Type of
R port
connection
A, B port
25-pin
VV5Q24
Connector
R port
assembly
Type of
A, B port
connection
P port
VV5Q04 VV5Q14
Disconnection (Fig 4)
Press the lever against the connector and pull the connector in a
straight line away from the solenoid.
NOTE
Plug-in units are factory pre-wired to specification (Fig 8).
Clip
Type of connection
Fittings assembly
25-pin
Fig 8
Electrical disconnection D-sub connector (Fig 8)
Loosen the two captive screws , pull off the connector
Electrical re-connection of D-sub connector (Fig 8)
Insert connector into the body .
CAUTION
Ensure that the connector enters directly onto the pins in the body.
Tighten the two retaining screws .
Electrical dis-connection flat cable connector (Fig 11)
Lift the two clamps outwards from the connector
Pin
Lever
DC indicator
Socket
Groove
DXT170-71-1
Pin
Lead wire
0.2~0.33mm 2
Hook
(Max. O.D.
Connector
: ø1.7mm)
AXT661-12
Cable Electrical wiring specifications
assembly
Fig 11
Remove the connector out of the body .
Re-fitting is the reverse of the above.
Wiring
Ensure that control wiring is separated from power wiring to prevent
noise generation.
Manual override
WARNING
Exercise extreme CAUTION when operating solenoid valve manual
overrides as connected equipment will commence operation.
Push non-locking type (Fig 6)
Push down on the manual override button until it stops (ON). Hold
this position whilst carrying out function checks. Release the manual
P port
override button and the override will re-set to the (OFF) position.
Push locking type manual override (Fig 6)
R port
Push down on the manual override button, using a small screwdriver
until it stops. Turn the button through 90° clockwise to lock. (180°
A, B port
VQ0000).
Non-locking push type
Bore: ø3.2
Push-locking tool type
Bore: ø3.2
P port
Push-locking lever type
R port
A, B port
Fig 6
CAUTION
. In this position the override will be mechanically 'locked' in the ON
position.
Un-locking
Turn the manual override using a small screwdriver through 90° (180°
VQ0000) anti-clockwise. Remove the screwdriver and the manual
override will re-set.
Manual override: Orange
.
Manual override: Green
Note 1: A-side energization: A light (orange) illuminates. B-side energization: B light (green) illuminates.
Equipped with a wiring error prevention (stop diode) mechanism and a surge absorption (ZNR/surge absorption
diode) mechanism.
Note 2: Applicable to negative COM specification models.
Note 3: In case of double (latching), the electromagnetic valve channel is, A- (set): P A, B R, (B- (reset): P B, A R
Fig 7
Raised button type locking override (Fig 6)
Push down on the raised button until it stops. Turn the button through
90° clockwise by hand.
CAUTION
In this position the override is mechanically 'locked' in the ON
position.
Un-locking manual override
Turn the raised button through 90° anti-clockwise by hand. Release
the button and the manual override will re-set to the OFF position.
Lamp and surge voltage suppressor (Fig 7)
All solenoid valves are equipped with lamp and surge protection as a
standard feature. The indicators are positioned on one end of the
valve, for both single and double solenoid types. The colours of the
indicator lamps match the colours of the manual override buttons.
D-sub connector/flat cable connector/terminal block
Wiring specification (Fig 12)
With the A side solenoid of the 1st station, as No. 1 (i.e. connected to
COM
COM
COM
COM
COM
F kit P kit T kit
D-sub connector
Flat cable Terminal block
(In case of 25-pin) connector (In case of
(In case of 26-pin) 16 terminals)
Fig 12
No. 1 terminal), wires are connected in the order indicated by the
arrow in Fig 12.
NOTE: No terminal should be left vacant.
Maintenance
WARNING
Before carrying out any maintenance work ensure that air and power
supplies are ISOLATED.
Plug lead unit/flip type
Removal of a Valve (Fig 5b)
1. Disconnect electrical connector. (See above.)
2. Slacken lower tie bolt 2~3 turns. Remove the upper tie bolt
and retain. Separate the valves either side of the valve to be
removed approximately 2mm. Lift the valve to be changed off the
manifold, in the direction of the arrow .
Replacing a valve (Fig 5b)
Reverse the above procedure to replace a valve.
Indicator light DC type circuit diagram
Orange
Double (latching) solenoid
Single solenoid type (DC)
type (DC)
Single A (-)
A -(Set)
solenoid type
SOL
C +(Com)
C(+)
B - (Reset)
Double ZNR
Light
(latching)
type
Indicator light
A: Orange
B: Green
SOL
