Start-Up and Service Instructions
CONTENTS
SAFETY REMINDERS . . . . . . . . . . . . . . . . . . . . . . . . . 1
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,2
General Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Compressor Replacement . . . . . . . . . . . . . . . . . . . . . 2
PREVENTIVE MAINTENANCE . . . . . . . . . . . . . . . . 2-4
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
System Cleaning/Flushing . . . . . . . . . . . . . . . . . . . . 3
DISASSEMBLY INFORMATION . . . . . . . . . . . . . . . 5-8
Filter Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Front Grille Removal . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Discharge Air Deck Removal . . . . . . . . . . . . . . . . . . 5
Accessing Control Box Components . . . . . . . . . . 5
Capacitor Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Thermostat Removal . . . . . . . . . . . . . . . . . . . . . . . . . . 6
(008P Unit Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Mode Selector Switch Removal . . . . . . . . . . . . . . . . 6
Removal (008P Unit Only) . . . . . . . . . . . . . . . . . . . 6
Wing Panel(s) Removal . . . . . . . . . . . . . . . . . . . . . . . 6
Coil Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Exhaust Feature (008P Unit Only) . . . . . . . . . . . . . . 7
Fan Motor Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
SERVICE POINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 10

SAFETY REMINDERS

1. Carry a fire extinguisher in your truck. Keep it within reach
when using a torch. Check fire extinguisher periodically
to be sure it is fully loaded and functional.
2. Know how to handle oxyacetylene equipment safely. Lock
the equipment in an upright position in the truck and at
the job site.
3. Use dry nitrogen or carbon dioxide to pressurize the sys-
tem for leak checking. Always use a good regulator. Be
careful not to exceed 150 psig test pressure in the her-
metic compressor.
4. Wear safety goggles and gloves when recovering refrig-
erant from a system.
5. Attend shop safety meetings.
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 131
Tab
8a 10a
1993-1995 Room Air Conditioners
Page
Catalog No. 537-327
Printed in U.S.A.

START-UP

Refer to operating instructions in Owner's Guide pro-
vided with room air conditioner. Refer to Table 1 for specific
model number information to properly service, maintain, and
disassemble the unit.

SERVICE

General Notes -

These Start-Up and Service Instruc-
tions are provided to assist the trained and qualified service
technician in repairing or replacing components of Carrier
room air conditioner model offerings for 1993-1995. Room
air-conditioning models are cooling-only units. These in-
structions contain disassembly photos for Model 73TC
(Siesta I and Siesta II). A typical 73TC unit is shown in
Fig. 1. Unit physical data is found in Tables 2-8.
Fig. 1 - Model 008P
IMPORTANT: Repairing and servicing air condition-
ers can be hazardous for untrained individuals. The in-
structions printed in this publication are for properly
trained and qualified Carrier service technicians only.
Before working on any air conditioner, be sure to first
disconnect all electric power to the unit to avoid the pos-
sibility of electrical shock and personal injury.
Before disconnecting, discharge capacitors by shorting ca-
pacitors across terminals.
Shield coils with cardboard to protect hands against in-
jury from sharp metal edges when removing compressor and
other components.
When disassembling wiring, use numbered stickers to iden-
tify wire leads and terminals. This aids in quick, accurate
reassembly.
Form 73TC-1SS
Pg 1
73TC
1-96
Replaces: New

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 73TCA005101B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carrier 73TCA005101B

  • Page 1: Table Of Contents

    System Cleaning/Flushing ....3 technician in repairing or replacing components of Carrier room air conditioner model offerings for 1993-1995. Room DISASSEMBLY INFORMATION .
  • Page 2: Compressor Replacement

    NOTE: In Carrier Standard Service Techniques, refrigerant were removed. removal must always include recovering the refrigerant, not 8. For proper cleaning and flushing, use the Carrier allowing it to escape to the atmosphere. Totalclaim recovery system or a comparable refriger- ant recycling system.
  • Page 3: System Cleaning/Flushing

    System Cleaning/Flushing — For proper cleaning for possible air leakage. and flushing, use the Carrier Totalclaim recovery system, or CONTROLS — Check unit to ensure all controls are func- a comparable refrigerant recycling system. tioning correctly and unit operation is normal.
  • Page 4 0.036 16.0 0.036 CD-10 18.0 0.036 40.0 0.036 Table 4 — Thermistor Table 8 — Receptacles, Fuse Types, Wire Sizes KEY NO. CARRIER RESISTANCE UNIT NAMEPLATE VOLTAGE (See Table 2) (Ohms) MAXIMUM NAMEPLATE HC95XX006 AMPS OUTLET RATED VOLTS/ 125/15 125/20 AMPS Table 5 —...
  • Page 5: Disassembly Information

    DISASSEMBLY INFORMATION Before working on any air conditioner, be sure to first disconnect all electric power to unit to avoid the pos- sibility of electrical shock and personal injury. IMPORTANT: It is not necessary to totally disas- semble all sections of this air conditioner for every ser- vicing operation.
  • Page 6: Capacitor Removal

    2. Remove metal clip which connects bulb heater to ther- EXHAUST RETAINER LEVER mostat sensing bulb. See Fig. 7. 3. Carefully disconnect wires from thermostat terminals. Label wires to aid in reassembly. 4. Reverse above procedure for reassembly. Thermostat Bulb Heater Removal (008P Unit Only) —...
  • Page 7: Accessing Compressor, Fan Motor, Outdoor

    3. Remove unit rear outdoor grille. FAN CYCLE SLIDE PANEL FRAME SELECTOR SWITCH OUT OF UNIT TRACKS, 4. Remove ground screw in control box section. See SWITCH (008P MODEL ONLY) THEN LIFT UPWARD SCREWS (2) Fig. 11. 5. Remove compressor terminal cover. See Fig. 11. 6.
  • Page 8 COMPRESSOR TERMINAL COVER Fig. 13 — Removing Air Handling System FAN MOTOR FAN MOTOR SECURING SCREWS (3) EXHAUST DOOR LINKAGE GROUND GROUND SCREW WIRE Fig. 11 — Accessing Compressor OUTDOOR FAN CENTER NUT OUTDOOR EXHAUST BLOWER DOOR WHEEL CLIP Fig. 14 — Fan Motor Removal EVAPORATOR COIL ASSEMBLY INDOOR...
  • Page 9: Service Points

    SERVICE POINTS (Check Annually) 1. Clean indoor and outdoor coils. 7. Check refrigerant connections for evidence of leakage. Repair if necessary. Indoor Coil — Use a hooked wire or bristle brush to remove dirt from fins. 8. Check wires for deterioration. Outdoor Coil —...
  • Page 10: Troubleshooting

    TROUBLESHOOTING SYMPTOM AND PROBABLE REMEDY PROBABLE CAUSE COMPRESSOR DOES NOT RUN Opening in Power Circuit 1. Control off 1. Reset control button. 2. Blown fuse 2. Replace fuse. 3. Defective wiring 3. Replace wiring. 4. Defective service cord 4. Replace service cord. 5.
