- Page 1 VITA ZYRCOMAT ® 6000 MS Operating manual VITA shade taking VITA shade communication VITA shade reproduction VITA shade control Last updated: 01.12 VITA shade VITA made.
-
Page 2: Table Of Contents
VITA ZYRCOMAT 6000 MS ® Table of contents Introduction 1.1 General notes 1.2 Copyright Scope of delivery 2.1 Device supplied in a special box 2.2 Accessories (can be purchased separately) 2.3 Control unit 2.4 Sintering dish Technical Information 3.1 General description of the firing unit Technical Data 4.1 Dimensions / weights... -
Page 3: Introduction
Like all VITA furnaces, the VITA ZYRCOMAT 6000 MS also has a variety of technical features that help you achieve outstanding results over the long term. For example, high-quality temperature control and adjustment ensure an accuracy of +/- 2°C across the entire temperature range up to 1600°C. -
Page 4: Scope Of Delivery
The VITA ZYRCOMAT 6000 MS can be equipped with the following control units: • VITA vPad comfort with 7" color touch screen, photo viewer, memory for 500 firing programs for control of 1 or 2 VITA VACUMAT 6000 M / 6000 MP / ZYRCOMAT 6000 MS units • VITA vPad excellence with 8.5" color touch screen, photo viewer, memory... -
Page 5: Technical Information
VITA ZYRCOMAT 6000 MS ® 3 Technical Information 3.1 General description of the firing unit • High-performance technology – ultra-accurate temperature control for optimized sintering • Time-saving, user-friendly convenience and a small footprint • Casing made of coated or stainless steel plate • Fold-away cooling trays • Optical operating status display • High-quality material used to insulate firing chamber • 2 temperature sensors (platinum/rhodium-platinum) • Automatic temperature calibration in advance of program startup • Temperature accuracy +/- 2°C 4 Technical Data 4.1 Dimensions / weights... -
Page 6: Intended Use
VITA ZYRCOMAT 6000 MS ® 5 Intended use 5.1 Basic information on the device design The device is designed according to the state of the art and recognized safety standards. However, if it is used inappropriately, hazards for the health and safety of the user or third parties may arise as well as the risk of damaging the device and other material property. -
Page 7: Ambient Conditions
• Max. altitude: 3800 m above sea level • Fluctuations in nominal voltage: not greater +/- 10% of nominal voltage 8 Safety functions The furnace is operated with a VITA vPad comfort, VITA vPad clinical or VITA vPad excellence unit and has the following safety and monitoring features: • Temperature sensor monitoring • Temperature monitoring • Power supply failure protection • Lift monitoring... -
Page 8: Installation And First Use
VITA ZYRCOMAT 6000 MS ® 9 Installation and first use 9.1 Installation location • Install the device in a dry, heated room. The distance to the closest wall should be at least 25 cm (see Section 7. Ambient conditions). • When the temperature is below 15°C (e.g. after transport), leave the device to stand for approx. 60 minutes at room temperature before using it for the first time. -
Page 9: Status Display
VITA ZYRCOMAT 6000 MS ® 9.3 Status display The status display shows the following operating modes: • Blue – program active • Red – error – blinking mode • Blinking green / red – update is running 9.4 Fuses On the back of the device (see Section 9.2), there are 2 device fuses. The identification plates show information about the fuse ratings used in the device. -
Page 10: Connecting The Device To The Mains Voltage
VITA ZYRCOMAT 6000 MS ® 9.6 Connecting the device to the mains voltage. Before first use, please read Section 6 Safety Information! For information about the connections, refer to Section 9.2. • Attach the connection cable to the control unit and the furnace. • Plug in the status display. • Connect the device to the mains power supply using the mains power cable supplied. -
Page 11: Cleaning The Furnace
The cleaning firing is described in the operating manual of the VITA vPad comfort, excellence or clinical control unit. Consult the operating manual of the control unit for information about the cleaning firing. -
Page 12: Ce Mark
13 Mains power supply failure The VITA ZYRCOMAT 6000 MS is equipped with power supply failure protection. This component prevents a program interruption and hence any incorrect firing in the event of a brief failure of the mains power supply. The power failure protection is activated as soon as the mains power supply fails when a firing program is running. -
Page 13: Warranty And Liability
In the event of software modifications without the knowledge and approval of VITA Zahnfabrik H. Rauter GmbH & Co. KG, all liability and warranty claims are invalidated. Exception VITA only grants a 6-month warranty on the heating elements of the VITA ZYRCOMAT 6000 MS. 14.1 Spare parts Spare parts must comply with the technical requirements specified by the manufacturer. -
Page 14: Switching On The Device
Color Liquid Pre-dry Pre-Dry program for all manually 30 min colored VITA In-Ceram materials Materials All VITA In-Ceram YZ materials are approved for both the Universal as the Speed programs. All other materials must be processed and sintered according the manufacturer's specifications. - Page 15 VITA ZYRCOMAT 6000 MS ® Ambient conditions Authorized modes of operation CE mark Cleaning Cleaning firing Control unit Copyright Device connections Dimensions Fans Firing chamber insulation Foreword Fuses Installation and first use Liability Mains power supply failure Materials Safety information Scope of delivery...
- Page 16 With the unique VITA SYSTEM 3D-MASTER all natural tooth shades are systematically determined and completely repro- duced. Please note: Our products should be used according to the working instructions. We cannot be held liable for damages resulting from incorrect handling or usage.
