Geotech
Bladder Pumps
Installation and Operation Manual
Rev 02/17/2015 Part # 21150035

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bladder Pumps and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Geotech Bladder Pumps

Summary of Contents for Geotech Bladder Pumps

  • Page 1 Geotech Bladder Pumps Installation and Operation Manual Rev 02/17/2015 Part # 21150035...

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1: SYSTEM DESCRIPTION ................2 CHAPTER 2: SYSTEM INSTALLATION ................6 CHAPTER 3: SYSTEM OPERATION ................8 CHAPTER 4: SYSTEM MAINTENANCE ................. 11 CHAPTER 5: SYSTEM TROUBLESHOOTING ............... 17 CHAPTER 6: SYSTEM SPECIFICATIONS ..............18 CHAPTER 7: REPLACEMENT PARTS LIST ..............19 NOTES ..........................
  • Page 4 DOCUMENTATION CONVENTIONS This document uses the following conventions to present information: An exclamation point icon indicates a WARNING of a situation or condition that could lead to personal injury or death. You should not proceed until you read and thoroughly understand the WARNING message.

  • Page 5: Chapter 1: System Description

    Chapter 1: System Description Function and Theory Geotech’s pneumatic Bladder Pumps operate with a unique action, ideal for both gentle low-flow sampling and high flow rate purging. Timed on/off cycles of compressed air alternately squeeze the flexible bladder to displace water out of the pump to the surface and then exhaust allowing the pump to refill.
  • Page 6 *Optional: Drop Tube Intake Assembly Bladder Cartridge Assembly Geotech’s 1.66” (4 cm) Bladder Cartridge Assembly (for 18”/46 cm and 36”/91 cm lengths) is factory assembled and tested, and is designed to be field replaceable. The .850” (2 cm) and .675” (1.7 cm) Bladder Cartridge’s are easily replaceable see, Chapter 4: System Maintenance.
  • Page 7 Figure 2 – Basic* Bladder Pump Assembly *Example above is based on 1.66”/4 cm configuration...

  • Page 8: Chapter 2: System Installation

    Pump Tubing Lines Geotech’s Bladder Pumps are engineered for easy installation and use. Dedicated Bladder Pumps are available with the tubing attached. Well identifications (supplied by customer) are located on tags connected to the tubing, and on the tubing bags.
  • Page 9 Safety Cable Before deploying any sampling pump, secure a safety cable from an anchoring point at or near the well head to the top of the pump. The optional Bladder Pump Hanger is attached to the Quick Link on the safety cable. Carefully lower the Bladder Pump into the well using the Reverse Coil Method to avoid kinking, until the desired depth is achieved or until the well cap seats.

  • Page 10: Chapter 3: System Operation

    150 in³/ 300 in³/ 0.64 cm 10 cm³ 100 cm³ 492 cm³ 984 cm³ 2460 cm³ 4920 cm³ Volume of Bladder Pumps BP DIAMETER BP LENGTH VOLUME (in³) 78 in³/ 1.66 in/ 36 in/ 4 cm 91 cm 1278 cm³...
  • Page 11 Flowrates depend on pump size and pump depth. For example, a large pump at shallow depths will produce the most flow, and a small pump at maximum depths will product the least amount of flow. Speak with a Geotech representative to determine the best configuration to meet sampling needs.
  • Page 12 Figure 5 – Tank Volume vs. BP Consumption...
  • Page 13 Figure 6 – Cycles vs. Depth...

  • Page 14: Chapter 4: System Maintenance

    Chapter 4: System Maintenance Bladder Pump As with any pump, scheduled or periodic maintenance should be performed, according to your sampling program and specific site conditions. Generally, the more turbid or sandy the water, the more maintenance and cleaning are required. Replacement bladders, as well as other key components, can be found in Chapter 7: Replacement Parts List.
  • Page 15 Figure 7 – 1.66 BP Lower Cap Removal...
  • Page 16 .850 and .675 Models Pull pump from the well, it is not necessary to remove the air and sample lines from the pump. Take care, as the pump may be filled with fluid. Remove the lower screen and housing by turning the housing in a counter clockwise direction.
  • Page 17 To reassemble .850 and .675 Models: Install O-ring to upper end of the center tube weldment assembly. Slide bladder onto the center tube assembly and over the O-ring on the upper end of the center tube assembly. Be careful not to roll the O-ring when sliding the bladder over this end. Slide a PTFE compression ring over the bladder and push down over bladder and upper end of the center tube With the upper end of the bladder secured by the PTFE compression ring, slide the...
  • Page 18 Slide the bladder up, beyond the bottom of the center tube assembly, exposing the lower end of the center tube and install the O-ring into the groove on the lower end. Slide the bladder back down over the O-ring being careful not to roll the O-ring. Now slide the PTFE compression ring over the bladder until it seats flush with the bottom of the center tube assembly.

  • Page 19: Chapter 5: System Troubleshooting

     Check valve is compromised. Remove Hosebarb on pump discharge outlet. Check the check ball seat for debris. Clean and re-install. If you are experiencing other problems than mentioned above, please call Geotech Technical Support for immediate assistance, (800) 833-7958.

  • Page 20: Chapter 6: System Specifications

    Chapter 6: System Specifications 1.66, 36" 1.66, 18" 0.850 0.675 Pump Housing 316 SS 316 SS 316 SS 316 SS Pump Ends 316 SS 316 SS 316 SS 316 SS Bladder Material PTFE PTFE PTFE PTFE Bladder Collar PTFE PTFE PTFE PTFE Material...

  • Page 21: Chapter 7: Replacement Parts List

    Chapter 7: Replacement Parts List 1.66 Stainless Steel Bladder Pump Components (18” and 36” Models)
  • Page 22 ASSY,LOWER CAP,166 DROP TUBE 51150113 § TUBING, PE, 1/3 x 1/2, FTm, POLYETHYLENE 87050503 § HOSEBARB, SS6, 1/2 x 1/2 MPT 17200156 § ASSY,INTAKE,1.66SS,DROP TUBE,WITH 1/2" HOSE BARB 51150071 Not Shown: ASSY,HANGER,SS6,BP,SAFETY CABLE, 1.66 51150119 MANUAL, BLADDER PUMPS 21150035 § = Sold Separately...
  • Page 23 ASSY,LOWER CAP,166 DROP TUBE 51150113 § TUBING, PE, 1/3 x 1/2, FTm, POLYETHYLENE 87050503 § HOSEBARB, SS6, 1/2 x 1/2 MPT 17200156 § ASSY,INTAKE,1.66SS,DROP TUBE,WITH 1/2" HOSE BARB 51150071 Not Shown: ASSY,HANGER,SS6,BP,SAFETY CABLE, 1.66 51150119 MANUAL, BLADDER PUMPS 21150035 § = Sold Separately...
  • Page 24 .850 Stainless Steel Bladder Pump Components...
  • Page 25 51150069 HOSEBARB § INTAKE, DROP TUBE, .850 BP, CE, SS 21150111 Not Shown: MANUAL, BLADDER PUMPS 21150035 SPARE PARTS KIT, .85, BP, CE § 51150123 [Items 4 (2), 6 (2), 7 (2), 8 (4), 12, 13, 14] KIT, .85 BP, O-RING SET, CE, O-RING SERVICE KIT §...
  • Page 26 .675 Stainless Steel Bladder Pump Components...
  • Page 27 ASSY, INTAKE .675 BP, DROP TUBE CE 51150070 § INTAKE, DROP TUBE, .675 BP, CE, SS 21150112 Not Shown: MANUAL, BLADDER PUMPS 21150035 SPARE PARTS KIT, .675, BP, CE § 51150124 [Items 5(2), 6 (2), 7(2), 8, 10, 11, 13, 14, 15] KIT, .675 BP, O-RING SET, CE O-RING SERVICE KIT...
  • Page 28 DOCUMENT REVISIONS EDCF# DESCRIPTION REV/DATE Project Release, SP 3/11/2014 1375 EDCF # Corrected Replacement Parts List (Ch. 7) for 1.66 2/17/2015 1870 pump, SP...

  • Page 29: Notes

    Notes...
  • Page 30 Notes...

  • Page 31: The Warranty

    RMA form, the use of equipment, contaminants equipment was exposed to, and decontamination solutions/methods used. Geotech reserves the right to refuse any equipment not properly decontaminated. Geotech may also choose to decontaminate equipment for a fee, which will be applied to the repair order invoice.
  • Page 32 Geotech Environmental Equipment, Inc. 2650 East 40th Avenue Denver, Colorado 80205 (303) 320-4764 ● (800) 833-7958 ● FAX (303) 322-7242 email: sales@geotechenv.com website: www.geotechenv.com...
