Step 1 — Check Required Hardware
Caution
: If using your own power supply, be certain that it is wired
correctly and supply voltage is 10 to 28 VDC. Incorrect wiring or volt-
age can cause software or equipment failures.
If connecting to a host with an IB-131 Interface Box, you will need
the following:
a
Item
1 FIS-0003-1XXXG
2 FIS-0001-0035G
3 99-000018-01
4
5 61-300026-03
97-100004-15
(90-264 VAC, 24VDC)
6
97-000002-01
(90-264 VAC, +5VDC)
7 99-000017-01
a. See "Connect the System" on page 3 for diagram of
system.
2
Part Number Description
MS-3 CCD Reader
IC-332 Adapter
IB-131 Interface Box
Host Computer
Null Modem Configuration
Cable
Power Supply
Optional Object Detector
MS-3 CCD Reader Quick Start Guide
