FLIR HM-Series Quick Start Manual

Display
Brightness
Power Button – The HM-Series camera has 3 power modes: On, Off, and
Standby.
• On - Takes approximately 90 seconds (during bootup there is a
fast-flashing red LED on the eyepiece display).
• Standby - After the camera is on, pressing the Power button will
toggle the camera between On and Standby mode. (In Standby
there is a slow-flashing red LED on the eyepiece display).
• Off - Push and hold the power button for 8 sec. to turn off.
Capture Button – Some models only; take snapshots (press and
release) or video clips (press and hold) to the SD memory card.
Display Brightness – Toggle through five brightness settings.
White/Black Hot/Instalert – In White Hot mode, hotter items appear as white
or light grey. In Black Hot, hotter items appear as black or dark grey. In Instalert,
hotter items in a scene are highlighted in red.
2× Zoom –Some models only; causes the image to zoom to 2X.
Diopter Control – Adjust the diopter setting for the sharpest image in
the viewfinder.
432-0004-31-12 Rev 100
HM-Series Quick Start Guide
White hot/
Black hot/
Marine Red
Lens Cap
2x zoom Capture Power
Eyepiece
Adjustable
Diopter
Jan 2013
