GY-HM200/GY-HM170 INSTRUCTIONS
Notification of Changes
This is a notification on the addition of new features, feature
modifications and onscreen display changes. Please read this together
with the "INSTRUCTIONS".
K, M: Feature available on the model or series name only.
"High-Speed" added to menu item [System]
"High-Speed" is added to [System] → [Record Set] → [Record Format]
→ [System].
A moving subject can be effectively portrayed by shooting smooth slow
motion images.
Frame
System Format Resolution Bit Rate
Rate
120/60p
100/50p
120/30p
High- Quick 60/30p 50M (XHQ)
1920x1080
Speed Time 100/25p 35M (UHQ)
50/25p
120/24p
60/24p
Memo :
● The [Rec Mode] is fixed at "Normal".
● The following functions cannot be used when "High-Speed" is selected.
Network, Time Stamp Recording, Flicker Correction, Shading, Face
Detection and WDR
● The settings for slot B are fixed at the same as slot A.
● For the "TC Generator" setting, only "Rec Run" and "Regen" can be
selected.
● It is not possible to set a shutter speed that is slower than the frame
rate.
(Example: When 120/60p is selected, 1/120 to 1/10000 can be set.)
● The angle of view shifts to telephoto.
(35 mm conversion: [Normal] 29.6 mm to 355 mm → [High-Speed]
49.3 mm to 592 mm)
● The sensitivity of high speed shooting is lower than normal shooting. In
order to capture more beautiful images, it is recommended to perform
shooting in a lighted environment.
● The remaining space on the media (recordable time to a SD card) runs
out faster than usual.
(Example: For 120/60p, as the recording speed is twice as fast as
usual, the remaining space on the media is reduced by approximately
double the speed.)
Bit Rate added to System "4K"
"70M" is added to [System] → [Record Set] → [Record Format] → [Bit
Rate].
Bit Rate
Frame
System Format Resolution (new values are in
Rate
bold)
30p 150M
Quick
4K 3840×2160 25p 70M
Time
24p
Memo :
● When 4K is set, the network function cannot be used. (K)
Usable Cards
Format Setting and Usable SD Card Combinations
System Format Bit Rate Usable SD Card
Quick 50 M (XHQ), UHS-I U3 or higher
High-Speed
Time 35 M (UHQ)
150M
4K
70M Class 10 or higher
50 M (YUV422),
50 M (XHQ)
HD
35 M (UHQ) Class 6 or higher
AVCHD − Class 4 or higher
SD
− −
Web − −
Estimated Recordable Time of SD Cards
● When [System] → [Record Set] → [Record Format] → [Format] is set
to "QuickTime".
System 4K HD SD
480i/
Resolution 2160p 1080i/1080p 960p
576i
Bit Rate 150M 70M XHQ UHQ HQ
−
4 GB 3 6 9 12 47 130
8GB 6 13 18 25 95 270
16GB 12 26 36 50 190 540
32GB 25 52 72 100 380 1080
64GB
50 105 145 200 760 2160
(SDXC)
128GB
100 210 290 400 1520 4320
(SDXC)
(Unit: minute)
Histogram feature added
The histogram shows the brightness distribution, and is employed
mainly for checking the exposure of the image.
1. Set the histogram feature to ON.
● Set [Main Menu] → [LCD / VF] → [Display Settings] →
[Histogram] to "On".
● You can also press the user button that is assigned with
"Histogram.
2. Set the upper and lower limits of the histogram display.
After setting, the brightness level is displayed in red color.
Item Settings Options
Top Sets the maximum brightness 5% to 110% (in 5% increments)
limit for changing the histogram Default value: 80%
display color
Bottom Sets the minimum brightness 0% to 105% (in 5% increments)
limit for changing the histogram Default value: 20%
display color
Example 1) Top 110%, Bottom 0% Example 2) Top 90%, Bottom 10%
00:00:00.00 00:00:00.00
282min 282min 282min 282min
100min 100min 100min 100min
50min 50min
50min 50min
Jan 24,2015 Jan 24,2015
12:34:56 12:34:56
5. 5.6 f t
ND 1/16 ND 1/16
AE+6 AE+6
0dB 0dB
F1.6 F1.6
P P 13000K 13000K 1/100 1/100
Bottom Top
* The area in red is not displayed.
How to read the histogram
● The vertical axis denotes the number of pixels.
● The horizontal axis denotes the pixel brightness.
Icon display added when zebra function is "On"
During zebra pattern display,
display screen in Camera mode.
"98%" added to [Top] and [Bottom] of menu item
[Zebra]
"98%" is added to the setting values for specifying the upper and lower
limits of the luminance level in [LCD/VF] → [Shooting Assist] →
[Zebra]/[Top] and [Bottom].
This convenient setting is to keep the video level with 100% during the
video production for playback, screening and broadcasting on
nonlinear devices and PC.
[Top] [Setting Values: 5% to ● 80% to 95%, 98%, 100%, Over]
[Bottom] [Setting Values: 0% to ● 70% to 95%, 98%, 100%]
[Adjust] added to menu item [Color Matrix]
[Adjust] is added to [Camera Process] → [Color Matrix].
Web
● The color matrix of the camera recorder can be adjusted to a color of
the user's preference.
480p
● When shooting is performed using multiple cameras, the colors of the
different cameras can be adjusted, and a color of the user's
LP
preference can be set on this camera recorder.
285
● The saturation, hue and brightness of the primary and complementary
580 colors (6 colors in total) can be set individually.
● Adjust the color on the vector scope and waveform monitor using the
1160
DSC color chart.
2320
* The adjusted values of "Standard", "Cinema Vivid", and "Cinema
Subdued" in [Color Matrix] can be stored individually.
4720
1. Select [Camera Process] → [Color Matrix]/[Adjust].
9440
2. Adjust the "Hue". [Setting range: -5 to +5] (roughly ± 5%)
● Select the color using the cross-shaped button (JK) and confirm
using the cross-shaped button (I). (The cursor moves to "Hue".)
● Pressing the cross-shaped button (J) rotates the hue in the
clockwise direction on the vector scope.
● Pressing the cross-shaped button (K) rotates the hue in the anti-
clockwise direction on the vector scope.
Yellow
Red
R
Mg
I
Y
B
G
Cy
Cyan Blue
R
Mg
I
Y
B
G
Cy
3. Adjust the "Saturation". [Setting range: -10 to +10] (roughly ± 10%)
● Press the cross-shaped button (I) to move the cursor to
"Saturation".
● Each of the colors changes in the direction indicated by the arrow
on the vector scope.
● Pressing the cross-shaped button (J) moves the color outward
from the center of the circle on the vector scope.
● Pressing the cross-shaped button (K) moves the color toward to
the center of the circle on the vector scope.
00:00:00.00 00:00:00.00
Yellow
Red
Jan 24,2015 Jan 24,2015 R
Mg
I
12:34:56 12:34:56
Y
B
5. 5.6 6 f f t t
ND 1/16 ND 1/16
G
AE+6 AE+6 Cy
0dB 0dB
F1.6 F1.6
Cyan Blue
P 13000K 1/100 1/100
R
Mg
I
Y
B
G
Cy
4. Adjust the brightness. [Setting range: -10 to +10] (roughly ± 10%)
● Pressing the cross-shaped button (J) brightens; and pressing the
cross-shaped button (K) darkens.
● Press the cross-shaped button (I) to return the cursor to "Hue".
Setting items changed or added to menu item [Rec
Trigger]
(zebra icon) is displayed on the
Setting items in [A/V Set] → [Video Set] → [HDMI/SDI Out] → [Rec
Trigger] are changed. (K)
Setting items are added to [A/V Set] → [Video Set] → [HDMI Out] →
[Rec Trigger]. (M)
● HDMI (K):
Superimposes the trigger signals in tandem with the [HDMI] terminal
as well as the [REC] button on the camera body and outputs the
recording/stop control signals to the compatible device.
● On (M):
Superimposes the trigger signals in tandem with the [HDMI] terminal
as well as the [REC] button on the camera body and outputs the
recording/stop control signals to the compatible device.
● SDI (K):
Superimposes the trigger signals in tandem with the [SDI OUT]
terminal as well as the [REC] button on the camera body and outputs
the recording/stop control signals to the compatible device.
● HDMI+SDI (K):
Superimposes the trigger signals in tandem with the [HDMI/SDI Out]
terminal as well as the [REC] button on the camera body and outputs
the recording/stop control signals to the compatible device.
[Setting Values: R Off, HDMI, SDI, HDMI+SDI] (K)
[Setting Values: R Off,On] (M)
Memo :
● When [A/V Set] → [Video Set] → [HDMI/SDI Out] (K) or [HDMI Out]
(M) is set to "Off", [Rec Trigger] is fixed at "Off" and selection is
disabled.
● When [System] → [Record Set] → [Rec Mode] is set to "Interval Rec"
or "Frame Rec", [Rec Trigger] is fixed at "Off" and selection is disabled.
● Set to "Off" when connecting to a device that does not support record
trigger.
Setting Values added to menu item [LCD Backlight]
The brightness is improved by changing the setting value of [LCD/VF]
→ [LCD Backlight].
A brightness setting that is 2 times the existing brightness setting has
been added.
Green This improves the visibility and allows for more delicate focusing.
R R
Mg Mg
I I
Increasing the value increases the brightness.
Y Y [Setting Values: -1, ● 0, +1]
B B
G
G
Cy Cy
Bit Rate added to live streaming
Magenta
R R
Mg Mg
I
I
Setting values are added to [System] → [Network]/[Settings] → [Live
Y Y
Streaming Set] → [Frame & Bit Rate].
B B
G
G
Cy No. of Frames
Cy
for Frame &
Bit Rate
60i, 60p, 1920×1080 60i (12 Mbps), ● 60i (8 Mbps),
30p
1280×720
720×480
640×360
Green
R R
Mg Mg 50i, 50p, 1920×1080 50i (12 Mbps), ● 50i (8 Mbps),
I I
25p
Y Y
B B 1280×720
G
G
Cy Cy
Magenta 720×576
R
R
Mg Mg
I
I
Y YI
640×360
B B
G
G
Cy
Cy
( K )
Resolution New values are in bold
60i (5 Mbps), 60i (3 Mbps),
30p (8 Mbps), ● 30p (5 Mbps),
30p (3 Mbps), ● 30p (1.5 Mbps)
60i (8 Mbps), 60i (5 Mbps), ● 60i (3 Mbps),
60i (1.5 Mbps), 60i (0.8 Mbps), 60i (0.3 Mbps)
30p (3 Mbps), ● 30p (1.5 Mbps),
30p (0.8 Mbps), ● 30p (0.3 Mbps)
50i (5 Mbps), 50i (3 Mbps)
25p (8 Mbps), ● 25p (5 Mbps),
25p (3 Mbps), 25p (1.5 Mbps)
50i (8 Mbps), 50i (5 Mbps), ● 50i (3 Mbps),
50i (1.5 Mbps), 50i (0.8 Mbps), 50i (0.3 Mbps)
25p (3 Mbps), ● 25p (1.5 Mbps),
25p (0.8 Mbps), 25p (0.3 Mbps)
B5A-1631-00
