JVC GY-HM200SP Additional Functions

Please read this together with the "INSTRUCTIONS".

Score Overlay

This camera recorder enables single-camera sports coverage producing real-time score overlays on
recorded or streamed HD video. It is available when a recording resolution is 1920×1080 or 1280×720.

Selecting the Scoreboard Type

Press [MENU] button of the camera recorder to display the menu screen, and then select a scoreboard
type in [Main Menu] → [Overlay Settings] → [Type]. Then press [MENU] button to close the menu
screen. There are following types for selection.

Type 1:
Possession Team Name

Type 2：
Team Name
Games Won

Football：
Possession Team Name

None： None-displayed

Inputting Scoreboard Data

1. According to "Connecting to the Network" in the "INSTRUCTIONS" stored in the CD-ROM or the
Mobile User Guide
(http://manual3.jvckenwood.com/pro/mobile/global/), connect a network device such as a
smartphone or a tablet with the camera recorder via network. And then, launch a web browser of
the network device.
2. Input the following URL in the address field of the web browser.
http://"IP address of the camera recorder"
Example: http://192.168.0.1
You can find the "IP address of the camera recorder" by the following procedures.
(1) Press [STATUS] button of the camera recorder to display the status screen.
(2) Use the cross-shaped button ( ) to display the [Network] status.
3. Input a username (jvc) and a password (default: 0000) on the login screen. And then, press the
[Overlay Control] button on the web page to move to a score input page.
4. The web browser displays the following screen corresponding to the [Type] of the camera menu.
Data other than numerical values will be updated immediately in the score overlay without need to
press the "Update" button.
GY-HM200SP Additional Functions
Points Scored Remain Time
Period
Points Scored Set
Period Remain Time
TOL Points Scored Down & Distance
Type 1
Football
1
①
②
③
④
Type 2
Memo：
① Time
The input initial time for count down is reflected to
①
the score overlay by pressing the [Set] button. (The
time on the web browser does not count down.)
②
② [Update] button
Reflects numerical values such as points scored and
a distance
③
③ [Overlay] button
Turns the score overlay on or off.
④ Team Name (for text input)
You can input numbers and letters. It is not
available when [Main Menu] → [Overlay Settings]
→ [Layout] is set to "User".
④

Press the [DISPLAY] button to switch the display
screen type if the score overlay is hard to see due
to the display screen.
