- Page 1 Built under extractor Instruction manual INCH Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk...
-
Page 2: Table Of Contents
CONTENTS Safety Warnings Safety Instructions Electrical Shock Hazard Environmental Warranty Extraction Without Intrusion Installation Electrical Safety For Your Safety Cleaning Methods Of Extracting Operation Bulb Replacement Troubleshooting Technical Data Please keep this instruction manual for future reference Instruction manual INCH... -
Page 3: Safety Warnings
- Do not use any accessories or attachments not recommended by Caple as this may result in fire, electric shock or injury. - To protect against fire, electrical shock and injury to persons, do not immerse cords or plugs in water or any other liquid. -
Page 4: Safety Instructions
Caple cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that Caple reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. Under no circumstances... - Page 5 - The performance of your extractor will vary depending on a number of factors. These include type of extraction, room volume, length of ducting, ventilation available and the cleanliness of the filters. Please keep this instruction manual for future reference Instruction manual INCH...
- Page 6 • By clients in hotels, motels and other residential type environments. - To avoid all risk, if the power cable is damaged, it must only be replaced by a Caple appointed engineer. Please keep this instruction manual for future reference Instruction manual INCH...
-
Page 7: Electrical Shock Hazard
N.I.C.E.I.C who will comply with the I.E.E and local regulations. Electrical information can be found on the rating plate. Please keep this instruction manual for future reference Instruction manual INCH... -
Page 8: Environmental
Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. - Page 9 This appliance has been designed, constructed and marketed in compliance with safety requirements in force. This appliance has been manufactured to the strictest standards and complies with all applicable legislation. Please keep this instruction manual for future reference Instruction manual INCH...
-
Page 10: Extraction Without Intrusion
(A) upwards which will then release the grease filters. Once the grease filters have been removed the front door panel should also removed. Please keep this instruction manual for future reference Instruction manual INCH... - Page 11 If after installation there is a gap between the rear wall and the extractor a spacer is provided. This can be fixed to the rear of the extractor and cut to accommodate the gap. Please keep this instruction manual for future reference Instruction manual INCH...
-
Page 12: Electrical Safety
Under no ances should the exposed power supply cable come within 70cm of a direct source of heat. should be channeled into the wall, well out of harm’s way. Please keep this instruction manual for future reference Instruction manual INCH... -
Page 13: For Your Safety
(at least once every two months). These can be cleaned in warm soapy water or placed in the dishwasher (using the dishwasher may cause some slight discoloration, this is normal and not as fault with the product). Please keep this instruction manual for future reference Instruction manual INCH... -
Page 14: Methods Of Extracting
Extraction Via Ducting ely www.caple.co.uk.) Ducting your extractor negates the need for charcoal The very best method of cleaning the kitchen of unwanted odours is by connecting the appliance to an... - Page 15 (code: CAP73CF). Replacements can be purchased from www.caple.co.uk. Remember the re-circulation mode cannot be used without a charcoal filter. e wall, check for the pipes and power cables.
- Page 16 Operation replace the screws To switch on the light simply move the switch to position 1. NOTE: The light is not effected by opening or closing the front panel. Please keep this instruction manual for future reference Instruction manual INCH...
-
Page 17: Operation
To change the charcoal filter remove the old cassette by twisting an pulling off. Re- version my pushing onto the lugs and twisting to fixing in position. fit the new version my pushing onto the lugs and twisting to fixing in position. Please keep this instruction manual for future reference Instruction manual INCH... -
Page 18: Bulb Replacement
The wire which is colored blue must be connected to the terminal which is marked with the letter “N” or Instruction manual INCH colored black. The wire which is colored brown must be connected to the terminal which is marked with... - Page 19 This appliance has such technical particulars that it belongs to Class 2 insulation and therefore neither wire should be connected to the terminal marked with the letter E or by the earth symbol. Please keep this instruction manual for future reference Instruction manual INCH...
-
Page 20: Troubleshooting
Still not working? If, having consulted the above diagnostic chart you are still unable to Call the service remedy the situation, please call Caple service on 0117 938 7420 or email agent service@caple.co.uk. Please keep this instruction manual for future reference... -
Page 21: Technical Data
