- Page 1 INCH Caple INCH Integrated Motor Technical Manual...
- Page 2 INCH Caple INCH Integrated Motor...
- Page 3 INCH - Caple Integrated Motor Item Part Number Description 09010100195058 Rotating board 09020100079 Rotating strip II 09020100073 Rotating bracket II 09020100072 Rotating bracket I 09020100078 Rotating strip I 09020200095 Blade 09020200099 Left blower 09020700053 Fan wheel 09040100139 Motor 09020200100 Right blower...
- Page 4 Caple INCH Wiring Diagram...
