Kramer wp-20 Quick Start Manual

KRAMER
WP-20 Wall Plate Quick Start Guide
This guide helps you install and use your product for the first time. For more detailed information, g
http://www.kramerav.com/manual/WP-20 to download the latest manual or scan the QR code on the left.
Step 1: Check what's in the box
The WP-20 Wall Plate
Power Adapter (12v DC)
Step 2: Connect outputs
Always switch off the power to each device before connecting it to your
For best results, we recommend that you always use Kramer high-performance cables to connect AV equipment to the WP-20.
Remote
Switches
Note: When the receiver in use does not support Ethernet, you can replace the left hand side faceplate with an optional part
(WP-20-BLNK(W) P/N 68-80305099 or WP-20-BLNK(B) P/N 68-80305199) that does not have a cutout for the RJ-45 Ethernet
connector.
WP-20 Quick Start (P/N: 2900-300508QS REV 1)
Audio
Serial
Amplifier
Controller
1 Quick start guide
WP-20 .
P/N:
o to
TP-588D/
TP-580RXR
2 9 0 0 - 3 0 0 5 0 8 QS
Rev:
1
