Kramer TBUS-203xl User Manual

Pop-up table connection bus

Advertisement

Quick Links

USER MANUAL
MODEL:
TBUS-203xl
Pop-up Table Connection Bus
P/N: 2900-300499 Rev 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TBUS-203xl and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer TBUS-203xl

  • Page 1 USER MANUAL MODEL: TBUS-203xl Pop-up Table Connection Bus P/N: 2900-300499 Rev 1...
  • Page 3: Table Of Contents

    Technical Specifications Figures Figure 1: TBUS-203xl Pop-up Table Connection Bus Figure 2: TBUS-203xl Pop-up Table Connection Bus – Right Side View Figure 3: TBUS-203xl Pop-up Table Connection Bus – Left Side View Figure 4: TBUS-203xl Connecting Surface Figure 5: Cut out Dimensions (not to scale)
  • Page 4: Introduction

    Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14: Collaboration. Thank you for purchasing the Kramer TBUS-203xl Pop-up Table Connection Bus, which is ideal for boardrooms, conference and training rooms! TBUS-203xl - Introduction...
  • Page 5: Getting Started

    This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. Do not place heavy objects on top of the TBUS-203xl. TBUS-203xl - Getting Started...
  • Page 6: Recycling Kramer Products

    To comply with the WEEE Directive, Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. TBUS-203xl - Getting Started...
  • Page 7: Overview

    Note that you cannot use cable pass-through inserts with this model. When not in use, you can lower the TBUS-203xl flush into the table. The example Figure 1 shows the TBUS-203xl in a table or podium top with a universal power socket.
  • Page 8: Defining The Tbus-203Xl

    Defining the TBUS-203xl Figure 2: TBUS-203xl Pop-up Table Connection Bus – Right Side View Feature Function Black anodized or brushed Covers the connecting surface, leaving the table surface anodized aluminum semi- neat and tidy automatic lid Connecting Surface Section 4.1...
  • Page 9: Figure 3: Tbus-203Xl Pop-Up Table Connection Bus - Left Side View

    For holding the clamps Power Socket Opening For installing/replacing the power socket Screw Holes (4) Figure 3: TBUS-203xl Pop-up Table Connection Bus – Left Side View Feature Function Cables securing panel For securing the cables so they do not accidently...
  • Page 10: The Tbus-203Xl Connecting Surface

    The TBUS-203xl Connecting Surface Figure 4 defines the connecting surface and includes the universal power socket (sold separately) for illustration purposes only: Figure 4: TBUS-203xl Connecting Surface Feature Function Blank inserts Blank inserts that can be replaced with wall plates as...
  • Page 11 100-240V AC, 50/60Hz, 5A Maximum 5A per power Maximum 5A per power outlet outlet Switzerland England TS-201CH (80-000049) TS-201GB (80-000048) 100-240V AC, 50/60Hz, 5A 100-240V AC, 50/60Hz, 5A Maximum 5A per power Maximum 5A per power outlet outlet TBUS-203xl - Defining the TBUS-203xl...
  • Page 12: Installing The Tbus-203Xl

    1. Before cutting the opening, confirm the dimensions of the cutout template and make sure that they have not changed. 2. Place the included cut out template (that is included with your TBUS-203xl) on the surface of the table exactly where you want to install the TBUS-203xl.
  • Page 13: Installing The Power Socket

    5. Unscrew and remove the template from the surface of the table and clean the table surface. Take care not to damage the table. If needed, you can download a full-scale template from our Web site. Kramer Electronics is not responsible for any damage caused to the table. Installing the Power Socket Figure 6...
  • Page 14: Figure 6: Tbus-203Xl Universal Power Socket Housing

    Figure 6: TBUS-203xl Universal Power Socket Housing To install the power socket: 1. Close the TBUS-203xl lid. 2. Carefully insert the power socket housing so that the power socket fits into the power socket opening on the connecting surface and the four standoffs fit the four screw holes on the TBUS-203xl.
  • Page 15: Inserting The Tbus-203Xl Through The Cut-Out Opening

    13). Do not keep the power cable too tight or too loose Inserting the TBUS-203xl through the Cut-Out Opening To install the TBUS-203xl, do the following: 1. Carefully insert the unit into the prepared opening. 2. Take the support clamps under the table and place them into the support clamp late slits at the desired height (on both the front and rear sides of the unit).
  • Page 16: Technical Specifications

    14.5cm x 13.2cm x 17.3cm (5.71" x 5.2" x 6.81") W, D, H WEIGHT: 1.4 kg (3.09 lbs) approx. 1.65kg (3.64 lbs) approx. with mounting brackets 1.9 kg (4.19 lbs) approx. packed product INCLUDED ACCESSORIES: Cut out metal template OPTIONS: Power socket kits, power cord TBUS-203xl - Technical Specifications...
  • Page 18 2900- 300499 P/N: Rev: SAFETY WARNING Disconnect the unit from the power supply before opening and servicing...
