Locking and Unlocking the RC-52A Technical Specifications Figures F igure 1: RC-52A Front Panel for Europe (80 and 86mm) and the United States F igure 2: RC-52A Rear Panel for Europe (80 and 86mm) and the United States F igure 3: Connecting the RC-52A...
GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer RC-52A Room Controller, which is designed to let you control an A/V system with ease, in a multimedia classroom or conference room.
• Avoid interference from neighboring electrical appliances that may adversely influence signal quality • Position your Kramer RC-52A away from moisture, excessive sunlight and dust Caution: No operator serviceable parts inside the unit Warning: Use only the Kramer Electronics input power wall...
Overview The RC-52A is a 2 gang room controller with an analog volume control adjustment knob, an RS-232 port, an IR control port and six backlit and label capable buttons with three levels of lighting intensity available (set via the K-Config application). It sends an RS-232 or IR command—with the push of a button—to a device (such as...
Defining the RC-52A Room Controller Front Panel The RC-52A is available in three versions (see Figure 1): 80mm and 86mm for Europe and a version for the United States: Figure 1: RC-52A Front Panel for Europe (80 and 86mm) and the United States RC-52A - Overview...
D efining the RC-52A Room Controller Rear Panel Figure 2: RC-52A Rear Panel for Europe (80 and 86mm) and the United States Feature Function Audio Potentiometer pinout GND PIN: ground connection for the potentiometer LEVEL PIN: wiper of the potentiometer...
(for example, the Kramer 912 Power Amplifier, see Section 4.2 5. Connect the 5V DC power adapter to the RC-52A power socket and to the mains electricity. Figure 3: Connecting the RC-52A RC-52A - Connecting the RC-52A Room Controller...
The RS-232 9-pin D-sub port pinout is defined in F igure 4 Figure 4: RS-232 Pinout T he Audio Potentiometer Pinout 1 0 B The audio amplifier pinout is defined in F igure 5 Figure 5: Audio Potentiometer Pinout RC-52A – Connecting the RC-52A Room Controller...
Figure 6: IR Emitter Wiring Using the RC-52A as an IR Repeater Once the RC-52A is mounted and powered, and the IR emitter is connected to a piece of A/V equipment (for example, a DVD), you can use it as an IR signal...
Before you configure the RC-52A buttons: 1. Connect the RC-52A to your PC with the USB cable. There is no need to connect the RC-52A to a power supply for configuration since power is supplied over the USB cable. 2. Open the Configuration program.
WEIGHT: 0.3kg (0.67lbs) approx OPTIONS: RS-232 9-pin D-sub port to 3-pin terminal block connector cable (C-D9F/3PM-0.6); Kramer IR emitter cable (P/N: C-A35/IRE-10) Specifications are subject to change without notice Go to our Web site at http://www.kramerelectronics.com to access the list of resolutions...
Page 13
1. Any product which is not distributed by us or which is not purchased from an authorized Kramer dealer. If you are uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site www.kramerelectronics.com.
Page 14
For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
