- Page 1 USER MANUAL MODEL: VM-8UX 12G SDI 1:8 DA P/N: 2900-300751 Rev 1 www.KramerAV.com...
-
Page 4: Table Of Contents
Contents Introduction Getting Started Achieving the Best Performance Safety Instructions Recycling Kramer Products Overview Connecting the VM-8UX Technical Specifications Figures Figure 1: VM-8UX 12G SDI 1:8 DA Figure 2: Connecting to the VM-8UX VM-8UX – Content... -
Page 5: Introduction
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and GROUP 14: Collaboration. Congratulations on purchasing your Kramer VM-8UX 12G SDI 1:8 DA, which is ideal for the following typical applications: ... -
Page 6: Getting Started
Avoid interference from neighbouring electrical appliances that may adversely influence signal quality Position your VM-8UX away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building. -
Page 7: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling/. -
Page 8: Overview
Extended-reach – Input signal equalization and output signal reclocking to gain signal extension. Using Kramer high-quality coaxial SDI cables, supports extension of up to 80m (260ft) for 12G 4K signals. Reach depends on signal resolution, and quality of copper cable used. For further details, go to our website at www.kramerav.com/product/VM-8UX. -
Page 9: Figure 1: Vm-8Ux 12G Sdi 1:8 Da
(for NTSC), or 576i or 576p (for PAL) of interlaced or progressive video format LOCK LED (Green) Lights when the VM-8UX has detected the input signal and was able to lock on that signal ON LED (Green) Lights when receiving power... -
Page 10: Connecting The Vm-8Ux
Connecting the VM-8UX Always switch off the power to each device before connecting it to your VM-8UX. After connecting your VM-8UX, connect its power and then switch on the power to each device. You do not have to connect all the inputs and outputs, connect only those that are required. -
Page 11: Technical Specifications
Reach: 3Gbps and 6Gbps: Up to 100m (330ft) 1.5Gbps: Up to 200m (660ft) SD: Up to 300m (980ft) Note: The specs apply when using Kramer cables. Video: Up to 4K@60Hz (4:2:2) 30bpp resolution 270Mbps to 12Gbps data rate 800mVpp /75Ω... - Page 13 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
