Summary of Contents for Roberts ecologic1
- Page 1 DAB/FM RDS digital portable radio with built-in battery charger Please read this manual before use...
-
Page 2: Table Of Contents
Contents Controls ... 2-3 Battery operation ... 4-5 Using the AC adaptor ...6 Lock switch ...6 Operating your radio - DAB ...7 Selecting a station - DAB ...8 Secondary services - DAB ...8 Display modes - DAB ...9 Finding new stations - DAB ...10 Manual tuning - DAB ...11 Autoselect - DAB ...11 Dynamic range control - DAB ...12... -
Page 3: Controls
Controls (Front) 1. Speaker 2. Band button 3. Auto Tune button 4. Info button If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) 5. Volume Down button 9. Charge / Battery Low indicator 6. -
Page 4: Controls
Controls (Back) 13. Battery compartment 14. Telescopic aerial DC 7.5V 800mA 15. Headphone socket 16. DC jack socket... -
Page 5: Battery Operation
Battery operation using alkaline batteries (also see page 21) 1. Remove the battery cover on the back of the unit by sliding the cover in the direction of the arrow. 2. Slide the switch inside the battery compartment to the Alkaline posi- tion. -
Page 6: Battery Operation Using Rechargeable Batteries
Battery operation using rechargeable batteries (also see page 21) 1. Remove the battery cover on the back of the unit by sliding the cover in the direction of the arrow. 2. Slide the switch inside the battery compartment to the NiMH posi- tion. -
Page 7: Using The Ac Adaptor
Using the AC adaptor Your radio is supplied with a Mains Adaptor. 1. Place your radio on a fl at surface. 2. Insert the adaptor plug into the DC socket located on the left hand side of your radio. 3. Plug the adaptor into a standard 13 amp mains socket outlet. Whenever the adaptor is used with the radio, it will take power from the mains rather than from the batteries. -
Page 8: Operating Your Radio - Dab
Operating your radio - DAB 1. Carefully extend the telescopic aerial. 2. Press the On/Off button to switch on your radio. The display will show "ROBERTS" for a few seconds and then "Welcome to DAB". 3. If this is the fi rst time the radio is used a quick scan of the UK Band III DAB channels will be carried out. -
Page 9: Selecting A Station - Dab
Selecting a station - DAB 1. The top line of the display shows the name of the station currently selected. 2. Press the Tuning Up/Down buttons to scroll through the list of available stations. 3. Press and release the Select button to select the station. The display may show "Now tuning..."... -
Page 10: Display Modes - Dab
Display modes - DAB Your radio has seven display modes:- 1. Press the Info button to cycle through the various modes. a. Scrolling text Displays scrolling text messages such as artist/track name, phone in number etc. b. Program Type Displays the type of station being listened to e.g. -
Page 11: Finding New Stations - Dab
Finding new stations - DAB As time passes new stations may become available. To fi nd new stations proceed as follows:- 1. Press and release the Auto Tune button. The display will show "Fast Scanning". Your radio will perform a scan of the UK DAB frequencies. As new stations are found the station counter on the right-hand side of the display will increase and stations will be added to the list. -
Page 12: Manual Tuning - Dab
Manual Tuning - DAB Manual tuning allows you to tune directly to the various DAB Band III channels. UK DAB stations are located in the range 11B to 12D. 1. Press and hold the Select button until the display shows "Manual tune". -
Page 13: Dynamic Range Control - Dab
Dynamic Range Control settings - DAB Dynamic Range Control (also known as DRC) can make quieter sounds easier to hear when your radio is used in a noisy environment. 1. Press the On/Off button to switch on your radio. 2. Press and hold in the Info button. The display will show “Station order.”... -
Page 14: Operating Your Radio - Fm
Operating your radio - FM 1. Carefully extend the telescopic aerial. 2. Press the On/Off button to switch on your radio. The display will show "ROBERTS" for a few seconds. 3. Press the Band button to select the FM band. 4. -
Page 15: Manual Tuning - Fm
Manual tuning - FM 1. Press the On/Off button to switch on your radio. 2. Press the Band button to select the FM band. Fully extend the Telescopic aerial. 3. Press and release the Select button until the display shows "Manual tune <... -
Page 16: Display Modes - Fm
Display modes - FM In FM mode the bottom line of the display can be set any of four display options. 1. Press the Info button to cycle through the various options. a. Radio text Displays scrolling text messages such as artist/track name, phone in number etc. -
Page 17: Presetting Stations - Dab And Fm
Presetting stations - DAB and FM There are 5 memory presets for each of the two wavebands. 1. Press the On/Off button to switch on your radio. 2. Tune to the required station as previously described. 3. Press and hold the required Preset button until the display shows, for example, "Preset 1 saved". -
Page 18: Stereo / Mono Setting - Fm
Stereo / Mono setting - FM Your radio will play stereo broadcasts in stereo (via headphones) so long as the received signal is of adequate strength. However, as a stereo signal becomes weaker the audio signal will become poorer. It may be preferable to force the radio to play the station in mono in order to reduce the level of audio noise. -
Page 19: Scan Sensitivity Setting - Fm
Scan sensitivity setting - FM Your radio will normally scan for FM broadcasts which are strong enough to give good reception. However, you may wish the Auto-scan function to also be able to fi nd weaker signals, possibly from more distant radio transmitters. -
Page 20: Software Version
Software version The software display cannot be altered and is just for your reference. 1. To view the software version on the display press and hold the Info button for 2 seconds. 2. Repeatedly press the Tuning Up/Down buttons until “SW Version” together with the version number appears on the display. -
Page 21: Headphone Socket
Headphone socket A 3.5mm Headphone Socket located on the left hand side of your radio is provided for use with either headphones or an earpiece. Inserting a plug automatically mutes the internal loudspeaker. IMPORTANT: Excessive sound pressure from earphones and headphones can cause hearing loss. -
Page 22: Rechargeable Batteries
A Few Words about Batteries… Your Roberts ecologic 1 radio has been designed to use a choice of power sources. You may plug it into the mains using the supplied high- effi ciency adaptor, or for listening away from the mains you may use either alkaline or rechargeable batteries. - Page 23 If you use the radio powered from the batteries, the battery light will be off until the batteries are exhausted. The battery light will then show red for a short while before the radio switches itself off. It does this in order that the batteries are not excessively discharged.
-
Page 24: General
General Do not allow this radio to be exposed to water, steam or sand. Do not leave your radio where excessive heat could cause damage such as in a parked car where the heat from the sun can build up even though the outside temperature may not seem too high. -
Page 25: Guarantee
In the event that it is not possible to return the instrument to the Roberts' dealer from whom it was purchased, please contact Roberts Radio Technical Services at the address shown on the rear of this manual. -
Page 26: Notes
Notes... - Page 27 If you need any further advice, please call our Technical Helpline on :- 020 8758 0338 (Mon-Fri) Notes...
- Page 28 ROBERTS RADIO TECHNICAL SERVICES 97-99 Worton Road Isleworth Middlesex TW7 6EG Technical Helpline :- 020 8758 0338 (Mon-Fri during offi ce hours) Website: http://www.robertsradio.co.uk Issue 1...
