Summary of Contents for Roberts Play M2
- Page 1 Play M2 / Play M3 DAB / DAB+ / FM RDS portable digital radio Please read this manual before use...
-
Page 2: Table Of Contents
Contents Play M2 controls ..............2 Language function .............19 Play M3 controls ..............3 System reset..............20 Using the buttons..............4 Headphone socket.............21 Battery operation ..............4 General ................22 Using the AC adaptor ............5 ..............22 Operating your radio - DAB ..........6 Circuit features ..............22 Selecting a station - DAB.............7 Guarantee.............Back page... -
Page 3: Play M2 Controls
Play M2 Controls (Top) (Side) 10 11 1. Telescopic aerial 7. Preset 2 button 13. Headphone socket 2. On / Off button 8. Preset 3 button 14. DC input socket 3. Volume Down button 9. Tuning Down button 15. Battery compartment 4. -
Page 4: Play M3 Controls
Play M3 Controls (Top) (Side) 10 11 1. Telescopic aerial 7. Preset 2 button 13. Headphone socket 2. On / Off button 8. Preset 3 button 14. DC input socket 3. Volume Down button 9. Tuning Down button 15. Battery compartment 4. -
Page 5: Using The Buttons
Using the buttons Most operations on the radio are performed by a simple short press of a button. A few operations require a longer press of a button. In this case the instructions will tell you to apply a long press, and the button should be held down for 2 or 3 seconds, until the radio has responded. -
Page 6: Using The Ac Adaptor
Use only the mains adaptor provided with the product, or a genuine replacement provided by Roberts Radio. The use of alternative adaptors will invalidate the guarantee. -
Page 7: Operating Your Radio - Dab
Operating your radio - DAB 1. Carefully extend the telescopic aerial located on the rear of your radio. The aerial should be fully extended and positioned vertically for optimum reception. 2. Press the On/Off button to switch on your radio. The display will show 'WELCOME' for a few seconds. -
Page 8: Selecting A Station - Dab
Selecting a station - DAB 1. Press the On/Off button to switch on your radio. 2. If you are listening in FM mode, give a long press on the Menu/Mode button until the 'DAB' mode is selected. 3. Press the Tuning Up or Down buttons to step through the list of available stations. -
Page 9: Finding New Stations - Dab
Finding new stations - DAB As time passes new stations may become available or you may have moved to a different part of the country. In this case you may need to cause your radio to scan for new stations. 1. -
Page 10: Manual Tuning - Dab
Manual tuning - DAB Manual tuning allows you to tune your radio to a particular DAB frequency in Band III. Any new stations found will be added to the station list. This function can also be used to assist the positioning of the aerial or the radio 1. -
Page 11: Dynamic Range Control - Dab
Dynamic Range Control (DRC) settings - DAB The DRC facillity can make quieter sounds easier to hear when your radio is used in a noisy environment. 1. Press the On/Off button to switch on your radio. 2. If you are listening in FM mode, give a long press on the Menu/Mode button until the 'DAB' mode is selected. -
Page 12: Prune Stations - Dab
Prune stations - DAB If you move to a different part of the country, some of the stations which were listed may no longer be available. Also, from time to time, some DAB services may stop broadcasting, or may change location or frequency. Stations which cannot be found, or which have not been received for a very long time are shown in the station list with a question mark. -
Page 13: Operating Your Radio - Fm
Operating your radio - FM 1. Carefully extend the telescopic aerial located on the rear of your radio. The aerial should be fully extended and positioned vertically for optimum reception. 2. Press the On/Off button to switch on your radio. 3. -
Page 14: Manual Tuning - Fm
Manual tuning - FM 1. Carefully extend the telescopic aerial located on the rear of your radio. The aerial should be fully extended and positioned vertically for optimum reception. 2. Press the On/Off button to switch on your radio. 3. If you are listening in DAB mode, give a long press on the Menu/ Mode button until the 'FM' mode is selected. -
Page 15: Scan Sensitivity Setting - Fm
Scan sensitivity setting - FM Your radio will normally scan for FM broadcasts which are strong enough to give good reception. However, you may wish the Auto-scan function transmitters. Your radio includes a local / distant option for the Auto-scan function. -
Page 16: Stereo/Mono Setting - Fm
Stereo / Mono setting - FM (Headphones only) Your radio will play stereo FM broadcasts in stereo (via headphones only) provided that the received signal is of adequate strength. However, as a stereo signal becomes weaker the audio signal will become poorer. -
Page 17: Display Options - Dab/Fm
Display options - DAB / FM Scrolling text (DAB and FM) Your radio has a range of display options when in DAB and FM modes:- 1. Press the Select/Info button to cycle through the various options. All displays except the text display will revert to the clock display after about 10 seconds. -
Page 18: Presetting Stations
Presetting stations You may store your preferred DAB and FM radio stations to the preset station memories. There are 6 memory presets in your radio, 3 for DAB and 3 for FM. Presets are remembered by your radio in the event of a power failure. The procedure for setting presets and using them to tune stations is the same for FM and DAB modes, and is described below. -
Page 19: Software Version
Software version The software version display cannot be altered and is just for your reference. 1. Press the On/Off button to switch on the radio. 2. Press the Menu/Mode button. The main menu will show on the display. 3. Press the Tuning Up or Down buttons until 'SYSTEM' appears on the display. -
Page 20: Language Function
Language function 1. Press the On/Off button to switch on the radio. 2. Press the Menu/Mode button. The main menu will show on the display. 3. Press the Tuning Up or Down buttons until 'SYSTEM' appears on the display. Press the Select button. 4. -
Page 21: System Reset
System reset If your radio fails to operate correctly, or some digits on the display are missing or incomplete carry out the following procedure. 1. Press the On/Off button to switch on the radio. 2. Press the Menu/Mode button. The main menu will show on the display. 3. -
Page 22: Headphone Socket
Headphone socket A 3.5mm Headphone Socket located on the right hand side of your radio is provided for use with either headphones or an earpiece. Inserting a plug automatically mutes the internal loudspeaker. Please be aware that the sensitivity of headphones can vary widely. We therefore recommend setting the volume to a low level before connecting headphones to the radio. -
Page 23: General
General • Your radio and AC/DC adaptor should not be exposed to dripping or placed on the radio or adaptor. Do not allow this radio to be exposed to water, steam or sand. Do not • It is recommended to operate the product such that there is a minimum leave your radio where excessive heat could cause damage such as in distance (10cm recommended) to adjacent objects in order to ensure a parked car where the heat from the sun can build up even though the... -
Page 24: Guarantee
Any claim under this guarantee should be made through the dealer from whom the product was purchased. It is likely that your Roberts dealer will be for attention. In the event that it is not possible to return the product to the Roberts dealer from whom it was purchased, please contact Roberts Radio using the contact details on the www.robertsradio.com website.
Need help?
Do you have a question about the Play M2 and is the answer not in the manual?
Questions and answers
my radio says Waiting when I turn it on
The Roberts Play M2 radio displays "WELCOME" for a few seconds when turned on. If your radio shows "Waiting," it may indicate that it is trying to find a station or complete an operation. Ensure the telescopic aerial is fully extended and positioned vertically for optimal reception. If no signal is found, try relocating the radio to a better position and perform a scan to find available stations.
This answer is automatically generated
