  • Page 1: Operating Manual

    UNIPOWER Corporation NORTH AMERICA • 3900 Coral Ridge Drive, Coral Springs, Florida 33065, USA • Tel: +1 954-346-2442 • Fax: +1 954-340-7901 • sales@unipower-corp.com EUROPE • Parkland Business Centre, Chartwell Road, Lancing BN15 8UE, ENGLAND • Tel: +44(0)1903 768200 • Fax: +44(0)1903 764540 • info@unipower-europe.com...

  • Page 2: Table Of Contents

    CONTENTS SECTION TOPIC PAGE Introduction Features Product Line Safety Warnings Warranty Unpacking and Inspection Description of Operation Front Panel Description TMN/TMP Module Specifications 10.0 Description of Features and Options 11.0 Mechanical Specifications 12.0 Safety and Industry Standards 13.0 Operating Information 14.0 Parallel Operation 15.0...
  • Page 3 ILLUSTRATIONS FIGURE TITLE PAGE TMN/TMP Series Bulk Power Front End TMN/TMP Series Module Block Diagram Front Panel of TMN/TMP Series Module TMN/TMP Series Mechanical Dimensions Rear Rack Input and Output Connections Rated Output Current vs. Ambient Temperature Remote Sensing Connection Parallel Connection of TMN/TMP Racks TMN/TMP Series Module Connections Checking AC Good and DC Good Outputs...

  • Page 4: Introduction

    TMN/TMP SERIES OPERATING MANUAL OPERATING MANUAL TMN/TMP SERIES BULK POWER FRONT ENDS INTRODUCTION This operating manual should be read through carefully before installing and operating the TMN/TMP Series hot-swap power systems. The TMN/TMP Series hot-swap modules and rack form a bulk power front end with high-power outputs at 24, 28 or 48VDC.

  • Page 5: Tmn/Tmp Series Bulk Power Front End

    TMN/TMP SERIES OPERATING MANUAL Figure 1. TMN/TMP Series Bulk Power Front End. Figure 2. TMN/TMP Series Module Block Diagram.

  • Page 6: Product Line

    Hot-Swappable Modules u LED Operating Indicators u Control and Monitoring Interface Signals PRODUCT LINE Hot-Swap Modules MAX. OUTPUT OUTPUT MAX. MODEL CURRENT VOLTAGE WATTS TMN5000 1000 TMN6000 1000 TMN7000 1000 TMP5000 1200 TMP6000 1200 TMP7000 1200 Rack NUMBER OF WIDTH HEIGHT...

  • Page 7: Warranty

    Products returned without prior authorization will be returned to buyer. All products returned for repair must be shipped freight prepaid to UNIPOWER. If the buyer fails to fully comply with the foregoing, the buyer agrees that no other remedy (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property or any other incidental or consequential losses) shall be available to the buyer.

  • Page 8: Description Of Operation

    TMN/TMP SERIES OPERATING MANUAL inspection. UNIPOWER Corporation will cooperate fully in case of any shipping damage investigation. Always save the packing materials for later use in shipping the unit. Never ship the rectifier system without proper packing. DESCRIPTION OF OPERATION Block Diagram.

  • Page 9: Front Panel Description

    TMN/TMP SERIES OPERATING MANUAL FRONT PANEL DESCRIPTION The front panel of a TMN/TMP Series module is shown in Figure 3. On the right side of the panel are the voltage adjustment potentiometer, AC Good LED (green) and DC Good LED (green). TMN/TMP MODULE SPECIFICATIONS Specifications for a Single Module.

  • Page 10: Front Panel Of Tmn/Tmp Series Module

    TMN/TMP SERIES OPERATING MANUAL Figure 3. Front Panel of TMN/TMP Series Module HOT-PLUG MODULE MATING RACK-MOUNT RACK-MOUNT 3.50 (88.9) 17.20 (436.9) J1 SIGNAL AC CONNECTION DC OUTPUT CONNECTOR AREA BUS BARS Figure 4. TMN/TMP Series Mechanical Dimensions...
  • Page 11 TMN/TMP SERIES OPERATING MANUAL GENERAL SPECIFICATIONS Efficiency ..............85% at Full Load Switching Frequency..........150kHz Nominal Overtemperature Protection ........Power Shutdown Isolation, class I , min..........3000VAC Input-Output ............1500VAC Input-Ground ............50VDC Output-Ground Safety Standards ............. EN60-950, UL1950, CSA22.2-950 ENVIRONMENTAL SPECIFICATIONS Operating Temperature ...........

  • Page 12: Description Of Features And Options

    TMN/TMP SERIES OPERATING MANUAL 10.0 DESCRIPTION OF FEATURES & OPTIONS DESCRIPTION FEATURE / OPTION Power Factor Correction The input current is a sine wave in-phase with the input voltage to give a power factor of 0.99. Input current total harmonic distortion meets EN61000-3-2.

  • Page 13: Mechanical Specifications

    TMN/TMP SERIES OPERATING MANUAL DESCRIPTION FEATURE / OPTION Overvoltage Protection The output is protected from overvoltage due to fault conditions in the module. Overvoltage protection is set at approximately 29V for the 24V version, 34V for the 28V version and 59V for the 48V version. The result is a latched shutdown of the module.

  • Page 14: Operating Information

    TMN/TMP SERIES OPERATING MANUAL 12.2 The TMN/TMP modules and racks are CE marked to indicate conform- ance to the European Union’s Low Voltage Directive. 12.3 Input conducted EMI meets FCC20780 part 15J Curve B and EN55022 Curve B. 12.4 Input fast transient specifications meet EN61000-4-4 Level 3; input surges, line-to-line, meet EN61000-4-5 Level 2;...

  • Page 15: Rear Rack Input And Output Connections

    TMN/TMP SERIES OPERATING MANUAL J1 SIGNAL AC CONNECTION DC OUTPUT CONNECTOR AREA BUS BARS (a) Rear Connections to Rack MODULE NO. (b) Uncovered AC Input Connection Area (c) Top View of DC Output Bus Bars Figure 5. Rear Rack Input and Output Connections...

  • Page 16: Rated Output Current Vs. Ambient Temperature

    TMN/TMP SERIES OPERATING MANUAL Figure 6. Rated Output Current vs. Ambient Temperature Figure 7. Remote Sensing Connection...

  • Page 17: Parallel Operation

    TMN/TMP SERIES OPERATING MANUAL 13.6 Remote Sensing. Remote sensing connections are made to pins 11 (+Sense) and 23 (-Sense) of the rack J1 connector. Remote sensing is used to regulate the output voltage at the point of load by compensating for the voltage drop in the wires to the load.

  • Page 18: Rack Control & Supervisory Signal Connections

    TMN/TMP SERIES OPERATING MANUAL a failed module results in virtually infinite MTBF. Table 14-1 Redundant and Non-Redundant Operation TMP AMPS NOM. TMN AMPS NUMBER OF MODE VOLTS MAX. MODULES MAX. Redundant, 2+1 Non-Redundant Redundant, 2+1 Non-Redundant Redundant, 2+1 Non-Redundant 14.2 Non-Redundant Operation. Higher output current can be achieved by operating the rack in a non-redundant mode as seen in Table 14-1.

  • Page 19: Parallel Connection Of Tmn/Tmp Racks

    TMN/TMP SERIES OPERATING MANUAL Figure 8. Parallel Connection of TMN/TMP Racks. MATING CONNECTOR KIT CONNECTOR Mating Connector: Positronics PLC30F7000 Order Kit No.: 775-1427-000 $ 40.00 Positronics PLC30M8000 PIN CONNECTIONS FUNCTION FUNCTION FUNCTION AC Neutral N.C. AC Line N.C. AC Ground N.C.

  • Page 20: Tmn/Tmp Module Connections

    TMN/TMP SERIES OPERATING MANUAL 15.2 The pin connections to J1 are shown in the table. J1 SIGNAL CONNECTOR FUNCTION FUNCTION Remote Enable 14 AC Good-1 N.C. 15 DC Good-1 N.C. 16 AC Good-2 Standard subminiature N.C. 17 DC Good-2 D Connector N.C.

  • Page 21: Installation

    TMN/TMP SERIES OPERATING MANUAL SIGNAL DESCRIPTION These are analog voltage inputs to the designated modules by Remote Adjust - 1 which the output voltage is adjusted. A zero to + 5V input Remote Adjust - 2 represents approximately 45 to 58V output for a 48V module or Remote Adjust - 3 22.5 to 29V for a 24V module.

  • Page 22: Maintenance

    TMN/TMP SERIES OPERATING MANUAL nection to the bus bars should be made by means of ¼ - inch bolts with nuts. The output wires or bus bars should be sized in accordance with the load current and length of conductor. 18.4 Contact Resistance.
  • Page 23 TMN/TMP SERIES OPERATING MANUAL For the 24V TMP module the resistor should be between 1 and 4.8 ohms; for the 28V TMP module it should be between 1.3 and 6.5 ohms; and for the 48V TMP module it should be between 3.8 and 19 ohms. 20.4 Connect a color-coded, twisted pair (no.

  • Page 24: Checking Ac Good And Dc Good Outputs

    TMN/TMP SERIES OPERATING MANUAL Figure 10. Checking AC Good and DC Good Outputs Figure 11. Checking Remote Adjust Input...
  • Page 25 TMN/TMP SERIES OPERATING MANUAL 20.10 Checking the Other TMN/TMP Modules. Each module should be tested in the above manner to verify its operation. Go back to Section 20.5 and proceed through the tests one by one until all modules have been verified. 20.11 Checking the Complete Rack.

  • Page 26: Troubleshooting Guide

    LED off, AC Good too great for the LED on. number of modules. 21.3 If none of the above actions solves the problem, call UNIPOWER Corpo- ration at 954-346-2442 Ext. 400 for help and try to resolve the problem over the telephone.
