Leviton Decora DI-N0X-ODS15-00A Installation Instructions

Compatible with electronic and magnetic ballasts, electronic and magnetic low-voltage ballasts, incandescent lamps, and fans.
WARNINGS AND CAUTIONS:
• TO AVOID FIRE, SHOCK, OR DEATH; TURN OFF POWER AT CIRCUIT BREAKER
OR FUSE AND TEST THAT THE POWER IS OFF BEFORE WIRING!
• To be installed and/or used in accordance with electrical codes and regulations.
• If you are not sure about any part of these instructions, consult an electrician.
• DO NOT control a load in excess of the specified ratings. Damage to the unit, fire,
electric shock, personal injury or death can occur. Check your load ratings to determine
suitability for your application.
FEATURES
• Leviton's Decora design
®
• Controls 15A of lighting load
• CEC Title 20 and 24 Compliant
• Time Delay: 30 seconds to 30 minutes
• LED (Red): Visible status indicator
for determining sensing technology
operation
INTRODUCTION
Leviton Cat. No. ODS15-TDx, Designer Wall Switch Vacancy Sensor, is designed to
detect motion from a heat-emitting source (such as a person in a room) within its field-
of-view (monitored space) and automatically switch lights OFF when motion is no longer
detected and the scheduled time-delay has expired. The Sensor adapts its time delay to
the occupancy patterns of a room. Cat. No. ODS15-TDx is UL listed, CSA certified and
conforms to California Title 20 and 24 requirements.
DESCRIPTION
The Vacancy Sensor senses motion within its coverage area of 2100 sq. ft (195.1 m
maximum and controls the connected lighting. This is a self-contained device which
provides sensing and light control. The Vacancy Sensor will turn the lights OFF when no
motion is detected, and keep the lights ON for as long as motion is detected.
The Vacancy Sensor uses a small semiconductor heat detector that resides behind a multi-
zone optical lens. This Fresnel lens establishes dozens of zones of detection. The Sensor is
sensitive to the heat emitted by the human body. In order to trigger the Sensor, the source
of heat must move from one zone of detection to another. The device is most effective in
sensing motion across its field-of-view, and less effective sensing motion towards or away
from its field-of-view (refer to Figures 1 and 1A). Keep this in mind when selecting the
installation location (refer to Figures 1 and 1A).
Note that vacancy sensors respond to rapid changes in temperature, so care should be
taken not to mount the device near a climate control source (i.e. radiators, air exchanges,
and air conditioners). Hot or cold drafts will look like body motion to the device and will
trigger it if the unit is mounted too close. It is recommended to mount the Vacancy
Sensor at least 6 ft. away from the climate control source. The device can be mounted
in a single gang wall box.
In addition, it is also recommended NOT to mount the Vacancy Sensor directly under a
large light source. Large wattage bulbs (greater than 100W incandescent) give off a lot
of heat and switching the bulb causes a temperature change that can be detected by the
device. Mount the Vacancy Sensor at least 6 ft. away from large bulbs. If it necessary to
mount the device closer, lower the wattage of the bulb directly overhead.
INSTALLATION
WARNING:
TO AVOID FIRE, SHOCK, OR DEATH: TURN OFF POWER AT CIRCUIT
BREAKER OR FUSE AND TEST THAT THE POWER IS OFF BEFORE WIRING.
NOTE: Cat. No. ODS15-TDx requires a ground connection in order to operate. Use the
ground wire in the electrical box for ground connection. If there is no ground wire, make
sure the electrical box is grounded and attach the ground wire to the box with a screw.
1. Connect wires per appropriate WIRING DIAGRAM as follows: BLACK lead to LINE.
BLUE lead to LOAD. GREEN lead to GROUND. Twist strands of each lead tightly and,
with circuit conductors, push firmly into the appropriate wire connector. Screw connector
on clockwise making sure that no bare wire shows below the connector. Secure each
wire connector with electrical tape.
2. Carefully position the wires into the wall box, then mount the Sensor Unit into the wall box.
3. Secure device using long mounting screws provided.
4. Restore power at circuit breaker or fuse.
NOTE: Cat. No. ODS15-TDx will beep once 5 seconds after power is applied. Allow
approximately 1 minute for charge-up. After approximately 1 minute the lights will
turn ON. If the lights turn ON and the LED blinks when a hand is waved in front of the
lens, then the Sensor was installed properly. If the operation is different, refer to the
Troubleshooting Section.
NOTE: Cat. No. ODS15-TDx is factory preset to work without any adjustments. If you
desire to change the factory settings, refer to the Settings section.
5. Attach the Control Panel cover, and a Decora
IS COMPLETE. Leave the room and the lights will turn OFF after the selected time-out
expires.
Designer Wall Switch Vacancy Sensor
California Title 20 and 24 Compliant
Single Pole (One Location) or Multi-Location
Rated: 120-277VAC, 50/60Hz
Incandescent - 1800W - 15A @ 120V
Fluorescent - 1800VA - 15A @ 120V - Fluorescent - 4000VA - 15A @ 277V
No Minimum Load Required
INSTALLATION INSTRUCTIONS
• Manual ON / Auto OFF
• Low Profile, tamper-resistant lens
• Adapting time
• Adjustable horizontal blinders for both left
and right PIR masking
• Vacancy Confirmation: a 30 second grace
period is enabled in case of False OFF
Wallplate (not included). INSTALLATION
®
Cat. No. ODS15-TDx
WARNINGS AND CAUTIONS:
• DO NOT install this unit to control a receptacle.
• Use this device with copper or copper clad wire only.
• Do not touch the surface of the lens. Clean outer surface with a damp cloth only.
• The Cat. No. ODS15-TDx vacancy sensor is intended to replace a standard light switch.
PROGRAMMING FEATURES
Factory Settings: The Sensor is shipped from the factory to work in almost all situations
without any added adjustments. The factory settings are: Blinders open and Base time-out
10 minutes.
Blinders: The blinders are two independent shutters that can narrow the field-of-view from
a maximum of 180° down to 60°. The blinders are operated by moving the blinder levers
towards or away from the center of the Sensor. The blinder levers can be found above the
control dials in the control panel (refer to Figure 2A).
Time-Outs: The Sensor has three types of Time-Outs: Walk-through, Base Time, and
Adapting.
• Walk-through Time-Out: The value of this time-out is preset to 2.5 minutes. It is used
by the Sensor as a starting point in adjusting the other types of time-outs.
• Base Time-Out: The value of this time-out is user selected through the use of the Time
Control Setting.
• Adapting Time-Out: When activated, the value of this time-out is changed by the
Sensor based on room occupancy.
Walk-Through: The walk-through feature is useful when a room is momentarily occupied.
With this feature, the Sensor will turn the lights OFF shortly after the person leaves the room.
The walk-through feature works in the following manner: The lights must be manually
2 )
turned ON. If the person leaves the room before the default walk-through time-out of 2.5
minutes, the Sensor will turn the lights OFF. If the person stays in the room for longer than
2.5 minutes, the Sensor will instead use the time-out per the Time Control Setting (refer to
Time Control Setting in the following sections).
The walk-through feature may be user disabled (refer to Non-Adapting Mode in the
following sections).
Audio Warning: The Sensor is equipped with a beeper to give the user feedback of unit
operation. During normal operation, the Sensor will issue three short beeps 20 seconds
before the time-out is over to alert the user that the lights are going to turn OFF. The
occupant must move in order for the lights to remain ON. The Sensor issues two short
beeps to let the occupant know that motion was detected and that the lights will stay ON.
Adapting Time Delay: The Sensor has built in adapting intelligence that changes the
adapting time-out duration in response to the occupancy conditions of the room it is
installed in.
If the Sensor detects "large" motions (as a person walking by), it will NOT change the time-
out duration. If the Sensor detects "small", infrequent motion (as a person sitting down and
writing), it will INCREASE the Adapting Time-Out duration. If the Sensor detects "small",
frequent motion (as in several persons in a room during a meeting), it will DECREASE the
Time-Out duration only if it was NEVER increased (this is because the built-in intelligence
will always proceed in the direction of "increasing" adapting time-out once it has increased
it for any of the occupancy conditions sensed).
If the room is occupied for longer than 2.5 minutes, the Sensor will enter the Occupied
Mode with the Time-Out duration specified by the Time Control Setting. This Time-Out is
used as the starting point for adapting. After a few days, the Time-Out value will adapt to
the "best" value based on the occupancy conditions detected in the room.
If the Sensor detects motion immediately after the audio warning beep, it will determine
that the existing Time-Out value is too short. The Sensor will thus increase the Time-Out
value by 1.5 times the existing value.
If the Sensor detects motion within 30 seconds after the lights turn OFF, it will turn the
lights ON and increase the Time-Out value by 1.5 times the existing value.
The adapted Time-out may be reset to the base value by rotating the Time Control to a
new time selection value (refer to Figure 2A).
Time Control Setting: The base Time-Out value is selected by rotating the Time
Control dial. There are four (4) values from which to choose. Each mark around the dial
corresponds to a different value as indicated below (refer to Figure 2A). The Sensor will
beep once to indicate that a new time value has been selected.
Face Marking Value of Time
(/) Slash Mark 30 second test mode, NO walk-through
1 5 minutes base-time out
2 10 minutes base-time out
3 20 minutes base-time out
NOTE: All time durations is approximate within ±10 seconds.
Manual ON: The lights will not automatically turn ON. They need to be manually turned
ON by the push-button, and will turn OFF when motion is no longer detected and the
scheduled time-delay has expired.
RANGE: To decrease detection range and sensitivity, rotate the Range dial CCW (refer to
Figure 2A). The detection range can be adjusted from 100% down to 36%.
DI-N0X-ODS15-00A
